Installation
Instructions
If you have questions, call 800-GE-CARES or visit our website at: www.monogram.com
Downdraft Vent Systems
36" Wide Models:
ZVB36
30" Wide Models:
ZVB30
Monogram.
We bring good things to life.
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZVB36 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Monogram ZVB36

  • Page 1 Installation Instructions If you have questions, call 800-GE-CARES or visit our website at: www.monogram.com Downdraft Vent Systems 36" Wide Models: ZVB36 30" Wide Models: ZVB30 Monogram. ® We bring good things to life.
  • Page 2: Table Of Contents

    Step 2, Install the Ductwork ........14 Installation Preparation Step 3, Install Raise/Lower Switch ......15 Cutouts for Monogram Cooktops ...... 6, 7, 8 Step 4, Connect Power ..........16 Clearances ..............9 Step 5, Install Filters, Check Operation ....16 Tools and Materials Required ........
  • Page 3: Models Available

    Design Information Downdraf t Vent Systems These downdraft vents systems can be Models retracted when not in use. Available ZVB36 ZVB30 36" Wide Downdraft Vent 30" Wide Downdraft Vent in white, black and stainless steel in white, black and stainless steel •...
  • Page 4: Advance Planning

    For accurate planning, this to be sure you will have enough flat book provides individual dimension drawings countertop surface. for the vent and the Monogram cooktop 2. Check to be sure that the total countertop installation. depth required (including min. cutout to...
  • Page 5 • Install a standard electrical outlet within reach of the vents’ two foot long power cord. – The vent and a Monogram gas cooktop combination can operate from the same 120 volt standard duplex outlet. – Electric cooktops must operate from a...
  • Page 6: Installation Preparation

    Installation Preparation Downdraf t Vent Systems • Measure carefully when cutting the • Identify the cutout illustration for the Cutouts and countertop. Make sure sides of the opening cooktop model you are installing. Clearances are parallel and rear and front cuts are –...
  • Page 7: Cutouts For Monogram Cooktops

    Installation Preparation Downdraf t Vent Systems ZEU30R 2-1/2" to 1-7/8" Cutout 1-3/4" Min. Cooktop Cutout to Rear Digital Cooktops Vertical Combustible Surface with 30" Vent 29-7/8" (SS) ZEU30 Cooktop 1/4" Overlap 3/4" 29-3/4" (B,W) 20-3/8" Thick 3/4" Support 1/8" Gap Rail 23-1/2"...
  • Page 8 Installation Preparation Downdraf t Vent Systems ZGU36GG 2-1/2" to 1-7/8" 2-1/4" Min. Cooktop Cutout to Rear Cutout Gas Cooktops Vertical Combustible Surface with 36" Vent ZGU36 Cooktop 36" 3/4" 1/4" Overlap 20-1/16" Thick 1/8" Gap Support 3/4" Rail 23-1/2" (SS) 21-3/4"...
  • Page 9: Clearances

    Installation Preparation Downdraf t Vent Systems Caution: Wall coverings, Clearances countertops and cabinets should withstand 200° heat generated by any cooktop. Gas - 8-13/16" min. Electric - 2" Clearance to Sidewall 13" 13" Max. Max. 30" 30" Min. 18" Min. 18" Min.
  • Page 10: Remove Packaging

    15 or 20 ampere circuit breaker or time delay fuse. Gas Cooktops If this vent is installed in combination with a Monogram gas cooktop, it may operate from IMPORTANT: (Please read carefully). the same duplex outlet. The power cord of this appliance is equipped...
  • Page 11: Venting Options

    Installation Preparation Downdraf t Vent Systems Venting Loosen Screws to Adjust Options Blower Left to Right Location Inside the Blower Discharge Loosen Screws to Rotate 30° to Left or 30° to Right 30° Rotation Left or Right Side to side adjustments: •...
  • Page 12 Installation Preparation Downdraf t Vent Systems • A left or right 90° direction adjustment To locate the ductwork holes in the cabinet Venting should be performed before dropping into floor or side walls: Options the countertop opening. • Temporarily, place vent into the countertop •...
  • Page 13: Ductwork

    Ductwork Downdraf t Vent Systems Use this form to Duct Total compute maximum Equivalent Quantity Equivalent Fittings permissible lengths Duct Piece Dimensions Length* Used Length for duct runs to 1 ft. outdoors. 6" round, (per foot straight length) Note: Do not exceed 1 ft.
  • Page 14: Installation

    Installation Downdraf t Vent Systems Optional Method Step Secure to Cabinet Side With Top Screw on Case Install Or Use Second Screw Preferred Method Secure the Upper Downdraft Brackets With Screws Located on the side of Vent Case and Attach to Back Wall of Cabinet Secure the Lower Brackets to Blower Housing...
  • Page 15: Step 3, Install Raise/Lower Switch

    Installation Downdraf t Vent Systems WARNING: Disconnect electrical power from unit before beginning switch installation. Step Failure to do so could result in personal Trim injury or damage to the electrical controls. Install Determine the location for the RAISE/ Raise/Lower LOWER switch.
  • Page 16: Step 4, Connect Power

    Installation Downdraf t Vent Systems • Plug power cord into properly grounded Step receptacle. Connect Power To raise the vent, press the RAISE/LOWER switch. Step – On 30" models, the switch is located on the top right side of the vent. Install Filters, –...
  • Page 17: Jxrb57 Kit For Indoor Remote Blower Locations

    JXRB57 Kit For Indoor Remote Blower Locations Tools and Materials required: • Pencil • Measuring tape • Drill with appropriate bits • Nut driver • Junction box • Wire nuts • Safety glasses • 3-1/4" x 10" to 6" round transition. •...
  • Page 18 JXRB57 Kit For Indoor Remote Blower Locations Important: Save any • Remove the 4 nuts holding the blower to the Step unused parts. If the mounting plate. One nut is hidden inside appliance is relocated at the outlet. Remove blower. a later time, parts may be •...
  • Page 19 JXRB57 Kit For Indoor Remote Blower Locations Step Downdraft Connect Ductwork Duct Adapter Outlet Cover • The downdraft plenum can discharge from • Connect the plenum to the ductwork. A either the right or left side. Select the side transition is required to connect the 3-1/4" that provides the best alignment to x 10"...
  • Page 20: Jxbc57 Kit For Outdoor Remote Blower Locations

    JXBC57 Kit For Outdoor Remote Blower Locations Materials Required (not supplied) • Approved liquid tight service connections for use between the wire compartment on the base and inside the structure. • 7 wire nuts or other approved connectors. • Six 5/16" dia. fasteners compatible with the type of material the base is being fastened to.
  • Page 21 JXBC57 Kit For Outdoor Remote Blower Locations • The base is designed to be mounted to studs 16" 6 Holes on 16" centers. Use the dimensions shown to For 5/16 6-11/16" Step determine the location of the ducting and Fastners wiring through the wall.
  • Page 22 JXBC57 Kit For Outdoor Remote Blower Locations • Remove the 4 nuts holding the blower to the mounting plate. One nut is hidden inside Step the outlet. Remove blower. • Remove the blower mounting plate. (continued) • Remove 2 screws along the bottom of the blower box which are visible once blower Hidden plate is removed.
  • Page 23 JXBC57 Kit For Outdoor Remote Blower Locations Plenum • Use electrical cable and connectors that Provided conform to local codes (14 gauge min. is Mounting Step recommended). Use a length to reach Screws between the vent and the blower/motor Blower Connect Wire location.
  • Page 24 NOTE: While performing installations described in this book, safety glasses or goggles should be worn. For Monogram local service in your area, call 1-800-444-1845. NOTE: Product improvement is a continuing endeavor at General Electric. Therefore, materials, appearance and specifications are subject to change without notice.
