Monogram ZVB36 Installation Instructions Manual
Downdraft vent systems
Hide thumbs
Also See for ZVB36:
- Owner's manual (20 pages) ,
- Owner's manual (13 pages) ,
- Installation instructions manual (24 pages)
Subscribe to Our Youtube Channel
Related Manuals for Monogram ZVB36
Summary of Contents for Monogram ZVB36
- Page 1 Installation Instructions If you have questions, call 800.GE.CARES or visit our website at: www.monogram.com Downdraft Vent Systems 36" Wide Models: ZVB36 30" Wide Models: ZVB30...
-
Page 2: Safety Information
A. Utiliser cet appareil uniquement de la manière prévue par le constructeur. Contacter le constructeur pour toute question concernant For Monogram local service in your area, cet appareil. 1.800.444.1845. For Monogram service in Canada, B. -
Page 3: Table Of Contents
Parts Supplied ..............10 MODELS AVAILABLE PRODUCT DIMENSIONS 30” Models 30” 28-1/2” 36” Models 36” 34” ZVB36 36” Wide Downdraft Vent in white, black and stainless steel 27" ZVB30 30” Wide Downdraft Vent in white, black and stainless steel 2" 8-1/2"... -
Page 4: Advance Planning
For accurate planning, this book provides individual burner box, the vent and the cutout clearance dimension drawings for the vent and the Monogram from the front. cooktop combined installation. 4. When countertop and cabinet depth present a Countertop Requirements: problem, review Creative Solutions. - Page 5 3/16” thick covered with 28 • The vent and a Monogram gas cooktop combination gauge sheet steel or .02” thick copper. can operate from the same 120 volt standard duplex •...
-
Page 6: Installation Preparation
Installation Preparation CUTOUTS AND CLEARANCES • Measure carefully when cutting the countertop. • Identify the cutout illustration for the cooktop model Make sure sides of the opening are parallel and rear you are installing. and front cuts are exactly perpendicular to sides. •... -
Page 7: Zeu30R Combination Cutout
Installation Preparation ZEU30R DIGITAL COOKTOPS WITH 30" VENT 2-1/2" to 1-7/8" Cutout 1-3/4" Min. Cooktop Cutout to Rear Vertical Combustible Surface ZEU30 3/4" 29-7/8" (SS) 20-3/8" 1/4" Overlap Thick 29-3/4" (B,W) 3/4" Support 1/8" Gap Rail 23-1/2" (SS) 23-3/8" (B,W) 22-1/4"... -
Page 8: Zgu36K Combination Cutout
Installation Preparation ZGU36K GAS COOKTOPS WITH 36" VENT 2-1/2" to 1-7/8" 2-1/4" Min. Cooktop Cutout to Rear Cutout Vertical Combustible Surface ZGU36 3/4" 36" 1/4" Overlap 20-1/16" Thick 3/4" Support 1/8" Gap Rail 23-1/2" (SS) 21-3/4" 23-3/8" (B,W) Cutout 34" Cooktop and Vent Cutout Vent Total Flat Depth... -
Page 9: Zgu384 Combination Cutout
Installation Preparation ZGU384 GAS COOKTOPS WITH 30" VENT 2-1/2" to 2-7/8" Min. Cooktop Cutout to Rear 1-7/8" Cutout Vertical Combustible Surface ZGU384 3/4" 30-3/4" 20-3/8" Thick 3/4" Support 1/4" Overlap Rail 1/8" Gap 2-3/4" 22-3/8" Vent Cutout 28-1/2" 23-7/8" Depth 19-5/8" Cooktop and Vent Cutout Total Flat Cooktop... -
Page 10: Clearances
Installation Preparation CLEARANCES CAUTION Wall coverings, countertops and cabinets should Gas - 6" to 12" withstand 200° heat generated by any cooktop. Electric - 2" Clearance to Side Walls PRUDENCE Les revêtements muraux, les dessus de comptoir et les armoires de cuisine doivent résister à la température de 95 °C (200 °F) créée par toute table de cuisson. -
Page 11: Power Supply
Gas Cooktops DO NOT USE AN EXTENSION CORD. If this vent is installed in combination with a Monogram gas cooktop, it may operate from the same duplex outlet. Electric Cooktops If this vent is installed in combination with a Monogram electric cooktop, the vent must operate from a separate 120V outlet. -
Page 12: Venting Options
Installation Preparation Loosen Screws VENTING OPTIONS to Adjust 3-1/2" to Left or Right • The downdraft vent is shipped with the discharge outlet pointing straight down and can be changed to the left or right side. • The blower outlet is sized for 3-1/4” x 10” and can be transitioned to 6”... -
Page 13: Ductwork
Ductwork Use this form to com- Duct Total pute maximum permis- Equivalent Quantity Equivalent Fittings Duct Piece Dimensions Length* Used Length sible lengths for duct runs to outdoors. 1 ft. Use 3-1/4" x 10" duct. 6" round, (per foot It can transition to Note: Do not exceed straight length) -
Page 14: Installation Instructions
Installation Instructions STEP 2 INSTALL THE DUCTWORK STEP 1 INSTALL DOWNDRAFT VENT Place the downdraft vent into the countertop cutout, • The downdraft blower system is designed for use against the back side. with 3-1/4" x 10" ductwork. It can be transitioned to 6"... -
Page 15: Step 3 Install Raise/Lower Switch
Installation Instructions STEP 3 INSTALL RAISE/LOWER SWITCH WARNING: AVERTISSEMENT Disconnect electrical power from unit before Il faut débrancher l’alimentation électrique de beginning switch installation. Failure to do so could l’appareil avant de commencer l’installation de result in personal injury or damage to the electrical l’interrupteur. -
Page 16: Step 4 Connect Power
Installation Instructions STEP 4 CONNECT POWER CLEANING Cleaning a Stainless Steel Downdraft Vent Plug power cord into properly grounded receptacle. Stainless steel has some unique cleaning characteristics. In order to keep your vent looking like new, we suggest cleaning it with Stainless Steel Magic or similar product. - Page 17 Notes...
- Page 18 Notes...
- Page 19 Notes...
- Page 20 Note: While performing installations described in this book, safety glasses or goggles should be worn. For Monogram ® local service in your area, call 1.800.444.1845. Note: Product improvement is a continuing endeavor at General Electric. Therefore, materials, appearance and specifi cations are subject to change without notice.
