PowerTec MT4008 Owner's Manual

Miter saw stand
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
MITER SAW STAND
QUESTION...
1•847•780•6120
Visit us on the web at www.southerntechllc.com
You will need this manual for safety instructions, operating procedures, and warranty.
Put it and the original sales invoice in a safe, dry place for future reference.
Model No. MT4008
17-1109

Advertisement

Table of Contents
loading

Related Manuals for PowerTec MT4008

Summary of Contents for PowerTec MT4008

  • Page 1 Model No. MT4008 Owner’s Manual MITER SAW STAND QUESTION... 1•847•780•6120 Visit us on the web at www.southerntechllc.com You will need this manual for safety instructions, operating procedures, and warranty. Put it and the original sales invoice in a safe, dry place for future reference.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PRODUCT SPECIFICATIONS SECTION PAGE SAFETY RULES Height ......33-1/4" (846 mm) Extended Width ... 42–65-1/4 (1067–1657 mm) Maximum Load Capacity .

  • Page 3: Safety Rules

    SAFETY RULES SAFETY FOR WORK STAND WARNING • Do not attempt to assemble or operate your miter saw For your own safety, read all of the rules and precautions stand until you have read the safety instructions in this before operating tool. section.

  • Page 4: Assembly

    ASSEMBLY UNPACKING TOOLS NEEDED Refer to Figure 1 The following tools (not included) are needed to assemble Check for shipping damage. Check immediately whether the miter saw stand: all parts and accessories are included. Phillips screwdriver ITEM DESCRIPTION 13 mm wrench or socket Miter Saw Stand Quick Release Mounting Brackets ASSEMBLE HANDLE...

  • Page 5: Assemble Wheels

    ASSEMBLY ASSEMBLE WHEELS Figure 5 Roller Bar Refer to Figure 4 • Slide the axle through the axle bracket, turn the axle until the machined end fits into the inside bracket hole. Place one small (Ø8) washer and nut onto axle. Tighten nut.

  • Page 6: Operations

    • The quick release mounting brackets hook onto the miter saw stand frame. Using the handles on the quick release mounting brackets, lift the miter saw and position the quick release mounting brackets onto the miter saw stand as shown in Figure 7 (SAW IS NOT SHOWN TO ALLOW VISIBILITY OF THE RAILS AND BRACKETS).

  • Page 7: Transportation

    TRANSPORTATION • To move the stand, use handle to lift and tilt the miter saw stand onto the wheels. Move miter saw stand as Refer to Figure 8, 9 shown. WARNING Figure 9 Risk of unsafe operation. Ensure proper footing and use caution when rolling the miter saw stand to prevent tipping or loss of balance.

  • Page 8: Parts Illustration

    MITER SAW STAND PARTS ILLUSTRATION...
  • Page 9 MITER SAW STAND PARTS LIST Key# Part# Description Specifications Qty Key# Part# Description Specifications Qty MT4008001 Body Tube MT4008029 M6 Nut MT4008002 Storage Box MT4008030 Saw Mounting Bracket MT4008003 Legs Fixing Housing MT4008031 Mounting Bracket End Cap MT4008004 Nylon Fixing Nut MT4008032 Nylon Fixing Nut MT4008005...

  • Page 10: Warranty

    30- DAY SATISFACTION GUARANTEE POLICY During the first 30 days after the date of purchase, if you are dissatisfied with the performance of this POWERTEC tool for any reason, you may return the tool to the retailer from which it was purchased for a full refund or exchange. You must present proof of purchase and return all original equipment packaged with the original product.
  • Page 11 NOTE...
  • Page 12 Southern Technologies, LLC 3816 Hawthorn CT, Waukegan, IL 60087...
