modway MOD-5044 Assembly Instructions page 2

STEP 4
Screw 2 center support leg [G] into corresponding holes on
center rail [D]. Insert center rail [D] into its corresponding
brackets on the headboard [A] & footboard [B].
D
G
STEP 6
Insert bed slats [H] into bed slat side fitter [6] & fix it to the
corresponding holes on the side rails [C].
6
H
ASSEMBLY INSTRUCTIONS
A
Slot first slat [H] into bed slat center
fitter [7] & insert second bed slat [H]
into bed slat center fitter [7] on
opposite side. Attach bed slats side
fitter [6] to bed slat before pressing the
caps into corresponding holes on
center rail [D] & side rails [C].
Palm
H
H
7
STEP 5
Attach 2 center support [E]
D
to side rail [C] with 4 screw
[5]. Repeat the same
procedure to secure the
other side.
STEP 7
Your bed is assembly complete.
1. Note : When moving the bed
position please ensure center
support legs are vertically aligned
to avoid any broken problems.
2. Note : Hardware may loosen over
time. Periodically check that all
connections are tight.
PAGE 2 OF 2
C
E
5
