soundsation MHL-12W-36Z-RGBWAPV Product Instructions

Product Profile:

Power supply: 110-230V AC 50/60Hz
Power consumption: 420W
Light source: 36 peaces 12W six in one LED (Red, Green, Blue, White,
Amber, Purple)
DMX control channel: 17
DMX 512 connection: 3-pin XLR
Flash-rate: 25Hz
Maximum PAN-movement 630°: In 2.5s
Maximum TILT-movement265°: In 1.5s
Number of LED: 36
Beam angle: approx. 40°
Dimensions: 33*22*45 cm

DMX Values and Functions

CH1 Pan
CH2 Tilt
CH3 Dimmer
CH4 Strobe
CH5 Red
CH6 Green
CH7 Blue
CH8 White
CH9 Amber
CH10 Purple
CH11 Pan / Tilt Speed
CH12 Manual RGBWAP Mixing
Colors
CH13 Pan Fine
CH14 Tile Fine
CH15 Auto Function
CH16 Zoom
CH17 Reset
Weight: 9 kg
0—255 Pan
0—255 Tilt
Dimmer
0－255
0—255 Strobe
0—255 Red
0—255 Green
0—255 Blue
0—255 White
0—255 Amber
0—255 Purple
0—255 Pan / Tilt Speed
0—255 Manual RGBWAP Mixing
Colors
0—255 Pan Fine
0—255 Tile Fine
0—255 Auto Function
0—255 Zoom
0—255 Reset
Product Instruction
MHL-12W-36Z-RGBWAPV
36*12W (six in one) (RGBWAP)
LED Moving Head Light
