TierTime UP300 Quick Start Manual page 2

A. Download UP300 Touchscreen Upgrade Kit
1. Download the UP300 Touchscreen Upgrade Kit
from https://www.tiertime.com/download.
2. Save the file to the root directory of the USB stick
which comes with the UP300, making sure the file
is named as "up300_x.x.x_update.tt" (Case
sensitive), x.x.x being the version number.
B. Unbox the UP300
Cut open the tape on the top of the cardboard box, and
1.
open the box from the top.
2.
Take out the two boards on the top foam, and remove the
top foam.
3. Remove the plastic cover and the square shaped foam
wrapping around the machine.
4. Lift the printer out of the cardboard box using two handles
on both sides of the printer, and place it on a flat surface.
5. Open the Top Lid and remove all the tights and foams
inside the printer. There are six tights in the machine.
6. Open the Front Door, and take out the two foams and two
extruders beneath the build platform. As figures show
below:
b. Turn the foam 90
a. Take out the extruder.
degrees and then take it
out of the machine.
Take out the roll of filament, the accessory box and the
7.
power cord at the bottom of the cardboard box.
Put all the foams back to the box, and keep the box for
8.
the future use.
C. Printer Installation
1. Upgrade Touchscreen 2. Install Build Plate
Insert the USB stick Make sure it is pushed
storing the update kit. all the way to the end.
3. Load Filament 4. Power On
Hold the filament straight Connect the printer with
up, feed it into the the power cord and plug
guiding tube, and make the cord into a wall
sure it sticks out from socket.
the other end of the
guiding tube.
D. Install Software
1. Download the latest software from the offical Tiertime
website.
For Windows: https://www.tiertime.com/download
*
Operating System requirement: Windows 7 SP1 or
above.
* For Mac OS: Go to Apple APP Store and search for
UP Studio.
Operation System requirement: macOS X 10.10 or
above.
Install the software on your computer.
2.
E. Start a Print
1. Power on the printer, and follow the instructions on the
screen to finish the upgrade.
You can connect your printer with USB cable, ethernet
2.
cable or wireless via Wi-Fi.
To set up Wi-Fi on your printer, go to "Config", click
"Network", toggle on "Wi-Fi" , and select a network to
connect.
3. Initialize the printer: Click "Initialize" on the touchscreen.
The printer will start to initialize.
4. Extrude the Filament: Push the filament into the inlet of the
Extruder, select from the touch screen "Material", select
the matching material type, and then click "Extrude".
5. Calibration: Press "Calibration", and click "AUTO", then
wait for the printer to finish the auto calibration process.
6. Open UP Studio software on your computer. Click UP on
the left menu, load a 3D model, edit the model settings
and print settings, and then click "Print". Wait for the data
sent to the printer and printer will start printing.
[Cautious]
：The default nozzle height of a
new printer is set to 0mm. Calibrate your
printer before the first time use.
F. Cautions
Flex/Perf Glass Broad: Glass boards are easy to
1.
break. Please handle with care.
2.
Extruder Removal/ Replacment: Always withdraw
filament first, turn off the machine, unplug the
extruder cable before removing or replacing the
nozzle.
3. Cable Removal: Always turn off the machine
before removing any internal cables.
4. HOT: Never touch the extruder and the build
board while the printer is operating.
5. Safety First: Always wear safety gloves when
using the scraper.
Adult Supervision: Adult supervision is required in
6.
the presence of children. Small printed parts are
a choking hazard, and always keep sharp tools
away from children.
