Eaton Powerware BladeUPS Configuration Instructions page 2

UPS ProdUctS and acceSSorieS
Power
Configuration Parts Qty Description
36kW N+1 ZC122P060100000 4 Powerware BladeUPS
12 kW 400V w/parallel cord,
7.7 min battery @ 36 kW
103005913 1 Powerware 42U enclosure
with BladeBar and
Bottom WW
116750221-001 1 ConnectUPS-X WEB/SNMP
Communications Card
Total U space remaining for UPS expansion to 60 kW N+1
Input power wireway uses bottom 6U of enclosure
For additional 103005747-6591 4 Battery increase to 18 minutes 12U
battery runtime* 8 Battery increase to 28 minutes 24U
12 Battery increase to 37 minutes 36U
16 Battery increase to 47 minutes 48U
* Each UPS requires same number of external batteries
UPS ProdUctS and acceSSorieS
Power
Configuration Parts Qty Description
48kW N+1 ZC122P060100000 5 Powerware BladeUPS
12 kW 400V w/parallel cord,
6.9 min battery @ 48 kW
103005913 1 Powerware 42U enclosure
with BladeBar and
Bottom WW
116750221-001 1 ConnectUPS-X WEB/SNMP
Communications Card
Total U space remaining for UPS expansion to 60 kW N+1
Input power wireway uses bottom 6U of enclosure
For additional 103005747-6591 5 Battery increase to 17 minutes 15U
battery runtime* 10 Battery increase to 26 minutes 30U
15 Battery increase to 34 minutes 45U
20 Battery increase to 44 minutes 60U
* Each UPS requires same number of external batteries
UPS ProdUctS and acceSSorieS
Power
Configuration Parts Qty Description
60kW N+1 ZC122P060100000 6 Powerware BladeUPS
12 kW 400V w/parallel cord,
6.9 min battery @ 48 kW
103005913 1 Powerware 42U enclosure
with BladeBar and
Bottom WW
116750221-001 1 ConnectUPS-X WEB/SNMP
Communications Card
Total U space remaining for UPS expansion to 60 kW N+1
Input power wireway uses bottom 6U of enclosure
For additional 103005747-6591 6 Battery increase to 15 minutes 18U
battery runtime* 12 Battery increase to 22 minutes 36U
18 Battery increase to 29 minutes 54U
24 Battery increase to 37 minutes 72U
* Each UPS requires same number of external batteries
BELGIUM
Tel: +32 (0) 2 348 4410
CZECH
Tel: +420 272 760 365
UPSInfoCzech@eaton.com
DENMARK
Tel: +45 3686 7910
UPSSalesDenmark@eaton.com
FINLAND
Tel: +358 9 452 661
PowerwareMyynti@eaton.com
FRANCE
Tel: +33 1 60 12 74 00
powerware.france@eaton.com
GERMANY
Tel: +49 7841 6040
infogermany@eaton.com
Six (6) rackS @ 6 kw Per rack
Rack Space
Required Parts Qty
Y032420CD100000 1 Powerware Rack Power Module
24U
(RPM), 12 kW, 12xIEC320-C13 and
6xIEC320-C19 out, BladeUPS Plug, 10 ft
Y032440CD100000 2 Powerware Rack Power Module
6U
(RPM), 12 kW, 12xIEC320-C13 and
6xIEC320-C19 out, BladeUPS Plug, 20 ft
PW107BA0UC08 6 Vertical (0U) ePDU 7 kW, 16A 230V
-
(24 x C13) / (8 x C19)
1052736 6 42U Enclosure (Rack) Split Rear &
12U
Casters no Sides
1052754 5 Powerware Baying Kit,
to attach two racks together
Total U space remaining for IT equipment
Additional batteries can be installed in IT enclosures,
subtract from usable space or order additional enclosure(s)
eiGht (8) rackS @ 6 kw Per rack
Rack Space
Required Parts Qty
30U Y032420CD100000 1 Powerware Rack Power Module
12 kW, 12xIEC320-C13 and
6xIEC320-C19 out, BladeUPS Plug, 10 ft
6U Y032440CD100000 3 Powerware Rack Power Module (RPM),
12 kW, 12xIEC320-C13 and
6xIEC320-C19 out, BladeUPS Plug, 20 ft
- PW107BA0UC08 8 Vertical (0U) ePDU 7 kW, 16A 230V
(24 x C13) / (8 x C19)
1052736 8 42U Enclosure (Rack) Split Rear &
6U
Casters no Sides
1052754 7 Powerware Baying Kit,
to attach two racks together
Total U space remaining for IT equipment
Additional batteries can be installed in IT enclosures,
subtract from usable space or order additional enclosure(s)
**ten (10) rackS @ 6 kw Per rack
Rack Space
Required Parts Qty
Y032420CD100000 1 Powerware Rack Power Module
36U
(RPM), 12 kW, 12xIEC320-C13 and
6xIEC320-C19 out, BladeUPS Plug, 10 ft
Y032440CD100000 4 Powerware Rack Power Module
6U
(RPM), 12 kW, 12xIEC320-C13 and
6xIEC320-C19 out, BladeUPS Plug, 20 ft
PW107BA0UC08 10 Vertical (0U) ePDU 7 kW, 16A 230V
-
(24 x C13) / (8 x C19)
1052736 10 42U Enclosure (Rack) Split Rear &
0U Casters no Sides
1052754 9 Powerware Baying Kit,
to attach two racks together
Total U space remaining for IT equipment
Additional batteries can be installed in IT enclosures,
subtract from usable space or order additional enclosure(s)
** When supporting more than eight racks it is recommended to place UPS in center of configuration
to make power distribution wiring easier.
ITALY
Tel: +39 02 95542 309
info@powerware.it
NORWAY
Tel: +47 23 03 65 50
SalesNorway@eaton.com
POLAND
Tel: +48 22 331 85 24
upssalespoland@eaton.com
RUSSIA
Tel: +7 495 981 37 70
UPSRussia@eaton.com
SLOVAKIA
Tel: +421 2 4463 7046
InfoSk@Eaton.com
Racks and Power Distribution
three (3) rackS @ 12 kw Per rack
Rack Space
Description Required Parts
3U Y032420CD100000
0U Y032420CD100000
0U PW107BA0UC08
- 1052736
- 1052754
243U Total U space remaining for IT equipment
Additional batteries can be installed in IT enclosures,
subtract from usable space or order additional enclosure(s)
Racks and Power Distribution
FoUr (4) rackS @ 12 kw Per rack
Rack Space
Description Required Parts
3U Y032420CD100000
9U Y032440CD100000
0U PW107BA0UC08
- 1052736
- 1052754
324U Total U space remaining for IT equipment
Additional batteries can be installed in IT enclosures,
subtract from usable space or order additional enclosure(s)
Racks and Power Distribution
Five (5) rackS @ 12 kw Per rack
Rack Space
Description Required Parts
3U Y032420CD100000
12U Y032440CD100000
0U PW107BA0UC08
-
1052736
- 1052754
405U Total U space remaining for IT equipment
Additional batteries can be installed in IT enclosures,
subtract from usable space or order additional enclosure(s)
SPAIN
Tel: +34 475 32 03
infoespana@eaton.com
SWEDEN
Tel: +46 8 598 940 00
infosweden@eaton.com
THE NETHERLANDS
Tel: 0800–8774636
UAE
Tel: +971 4 881 19 33
Fax: +971 4 881 1939
UNITED KINGDOM
Tel: +44 1753-608 700
acukpowerware@eaton.
com
Eaton, Powerware, and BladeUPS are trade names, trademarks, and/or
Qty Description
2 Powerware Rack Power Module
(RPM), 12 kW, 12xIEC320-C13 and
6xIEC320-C19 out, BladeUPS Plug, 10 ft
1 Powerware Rack Power Module (RPM),
(RPM), 12 kW, 12xIEC320-C13 and
6xIEC320-C19 out, BladeUPS Plug, 15 ft
6 Vertical (0U) ePDU 7 kW, 16A 230V
(24 x C13) / (8 x C19)
3 42U Enclosure (Rack) Split Rear &
Casters no Sides
2 Powerware Baying Kit,
to attach two racks together
Qty Description
1 Powerware Rack Power Module
(RPM), 12 kW, 12xIEC320-C13 and
6xIEC320-C19 out BladeUPS Plug, 10 ft
3 Powerware Rack Power Module
(RPM), 12 kW, 12xIEC320-C13 and
6xIEC320-C19 out, BladeUPS Plug, 20 ft
8 Vertical (0U) ePDU 7 kW, 16A 230V
(24 x C13) / (8 x C19)
4 42U Enclosure (Rack) Split Rear &
Casters no Sides
3 Powerware Baying Kit,
to attach two racks together
Qty Description
2 Powerware Rack Power Module
(RPM), 12 kW, 12xIEC320-C13 and
6xIEC320-C19 out, BladeUPS Plug, 10 ft
3 Powerware Rack Power Module (RPM),
12 kW, 12xIEC320-C13 and
6xIEC320-C19 out, BladeUPS Plug, 20 ft
10 Vertical (0U) ePDU 7 kW, 16A 230V
(24 x C13) / (8 x C19)
5 42U Enclosure (Rack) Split Rear &
Casters no Sides
4 Powerware Baying Kit,
to attach two racks together
service marks of Eaton Corporation and its subsidiaries or affiliates.
© 2008 Eaton Corporation, All Rights Reserved.
