Installation

Read this section to learn how to connect and configure the equipment of the M4 system.

Installing the System

Marport technicians or dealers need to connect the different components of the system.
Procedure
1. Check that you have all the items needed for the installation (See
2. Install the hydrophones and their cables, or find the cables from hydrophones that have already
been installed.
3. Route the hydrophone cables toward the junction boxes.
4. Put the receiver in a dry and clean area, as close as possible to the hydrophones. If the receiver
is in a closed environment, make sure it is enough ventilated and that the ambient temperature
does not exceed 55 °C (131 °F).
Note: Make sure that the cables from the junction box are long enough to reach the
receiver.
5. Put the Mac mini mounting brackets in a dry and ventilated area, without dust, in the
wheelhouse.
6. Connect Mac minis and receiver according to
Cabling on page 31.
7. Remove the lock screw from the Mac mini mounting bracket, and slide the Mac mini into it. Put
the lock screw back and fasten it.
8. Install the monitor(s).
9. Install loudspeakers, if applicable.
10. You can switch on the computers.
11. Connect the hydrophone cables to the junction boxes according to
47 and connect the junction boxes to the hydrophone connectors on the receiver.
12. When adding sensors to the system, refer to the
help you allocating frequencies.
M4 System - 2 Mac Minis | V2 | Installation
Equipment List
Mac Mini Cabling on page 32 and
Hydrophone Cabling
Appendix A: Frequency Plan
on page 9)
M4 Receiver
on page
on page 95 to
| 30
