Chapter 12
12.1 OTDR Specifi cations
Wavelength
Dynamic Range
Pulse Width
Units of Measurement
Event Dead zone
Attenuation Dead Zone
Resolution
Distance Uncertainty
Full Scale Distance Range
Typical Real-time Refresh Rate
Group Index of Refraction (GIR)
Linearity
Memory Capacity
Memory Type
Power Supply / Charger
Battery
Storage Temperature
Operating Temperature Range
Dimensions (without rubber boot)
Weight
Communications ports
Connector Styles
12.3 Power Meter Specifi cations
Detector Type
Connector Type
Dynamic Range
Calibrated Wavelengths
Power Measurement Uncertainty
Units of Measurement
Resolution
12.2 Light Source Specifi cations
Fiber Type
Wavelengths
Output Power
Laser Safety Classifi cation
Modulation Modes
* Light source wavelengths present are determined by the OTDR confi guration
FTE-7000A User's Guide Rev A 5/2014
Specifi cations
850, 1300, 1310, 1490, 1550, and 1625nm (±20nm)
±(0.75m + 0.005% x distance + sampling resolution)
± 0.18 dB under reference conditions, ± 0.25 dB from 0 to -65 dBm,
± 0.35 dB from 0 to +5 dBm and from -65 to -77 dBm
Class I Safety Per FDA/CDRH and IEC-825-1 Regulation
26/27dB MM,36/35/35/35dB SM
5 - 20,000 ns
Kilometer, Kilo feet and Mile
1m
4m
.125 - 32m
0.25-64km MM , 0.25-240km SM
2 Hz
1.024 - 2.048
± .05 dB/dB
~1000
Internal
Universal
4hr typ.
-20 to 60 C
-10 to 50 C
8.07" L x 3.89" W x 1.57" H
(205mm L x 99mm W x 40mm H)
1.6 lbs.
USB
FC, ST or SC Interchangeable
InGaAs
2.5mm Interchangeable
+5 to -77dB (CATV - +25 to -57dB)
850,1300,1310,1490,1550,1625nm
dBm, dB
.01 dB
Single mode, Multimode
850, 1300, 1310, 1550, 1625 nm ±20nm *
0 dBm (-3dBm @ 1625nm)
CW, 270 Hz, 1000 Hz, 2000 Hz
TTI reserves the right to change specifi cations without notice.
