Chapter 8 Project Management
8.1 Project Management Description
Project Management allows the user to save a set of parameters to be recalled for use at a later time. It also
incorporates the fi le management system to save traces to the active project folder. When the OTDR is turned
on, the default project is [NONE]. If an existing project is not open or a new one not set, all traces will be saved
to the [NONE] folder.
Note
In project and file management screens, the down button opens drop-down menus when and moves
the cursor down through the drop-down menus and the up button hides the menu or moves the cursor
up through the drop-down menus.
Note
It is necessary to create the project prior to taking a trace as the file will not be available to save after
going through the project creation sequence.
Project Management Screen
Project Management Menu
The menu for project management may be operated with the touch screen, however, this manual describes
the manner of operation with the keypad. To open the menu press the menu button. There are four tabs
available, File, Edit, View and Help. Use the left or right buttons to move to a desired tab and use the select or
the down button to open the drop-down menus. Pressing the menu button again or the up button will hide the
operations menu.
Touch Screen Tip
The menu may be pulled down with the stylus the same as the menu on the main trace screen. Once
the file menu is open, it is fully operable with the touch screen function.
FTE-7000A User's Guide Rev A 5/2014
Project Folder
List
Project
Details/Properties
Fig 8.1
Fig 8.2
