- Page 1 CYBER PAK User Instructions Elation Professional 4295 Charter Street Los Angeles CA. 90058 www.elationlighting.com...
-
Page 3: Table Of Contents
Contents Features 1 General Instructions 2 1. Overview 3 1.1 Front Panel 3 1.2 Rear Panel 4 2. Operation Guide 5 2.1 Receive Mode 5 2.1.1 Receive Enable 5 2.1.2 MIDI Channel 5 2.1.3 Note Number 6 2.1.4 DMX Fail mode 7 2.1.5 Channel DMX Address 7 2.1.6 1CH./ 2CH./ 4CH. -
Page 4: Features
Features Thank you for your purchase. This product features include: 4 channel chaser with 16 built-in chase programs 4 channel dimmer pack with 4 individual DMX channel Serves as a MIDI pack to receive MIDI Note Number(001-128) Dimmer pack and Switch pack can be selectable 1,2, 4 channel dimmer pack depending on your adjustments Fade-in or Fade-out of the chase programs DMX fail allows to set HOLD/OFF/ON of output... -
Page 5: General Instructions
General Instructions Please read through this operating instructions before installing or using your new product. After you have finished reading the instructions, put them away in a safe place for future reference. Safe and Efficient Use This product must be earthed. Do not make any inflammable liquids, water or metal objects enter the unit. -
Page 6: Overview
1. Overview 1.1 Front Panel Loading: 5A/CH, Total 20A Max. CHANNELS MONITOR MODE MENU DISPLAY Midi Channel Note number Remote type Dimmer/Switch RECEIVE DMX Signal Receive Total channel 8 8 8 8 Dmx fail mode Stand by Channel Dmx address MIDI Signal Chase Channel preset... -
Page 7: Rear Panel
1. Overview 1.2 Rear Panel 1/4"stereo jack Stand By REMOTE 1 - Ground Full on 2 - Data- MIDI IN MIDI THRU 3 - Data+ DMX IN DMX OUT AC 120V~ 50/60Hz, 15A max. CAUTION Risk of Electric Shock Disconnect Input Power Before Opening N'ouvrez pas..risque de choc electrique POWER... -
Page 8: Operation Guide
2. Operation Guide 2.1 Receive Mode This function allows you to turn on and control the intensity of the fixture with the use of a DMX controller or MIDI sequencer. On, off and dimming functions can be performed through this pack. This dimmer has 4 individual DMX address, DMX fail mode allows you to assign output when DMX signal is interrupted. -
Page 9: Note Number
2. Operation Guide 2.1.2 MIDI Channel 2. Tap the Up or Down button to select MIDI Receive CH:03 channel from CH 01-16. Make sure your Stand by MIDI Chase MIDI channel matches that on the MIDI sequencer. MODE MENU 2.1.3 Note Number 1. -
Page 10: Dmx Fail Mode
2. Operation Guide 2.1.4 DMX Fail mode 1. Enter Receive mode, tap MENU until the Segment Receive Stand by Display shows HOLD/ OFF/ ON. DMX fail mode MIDI Chase allows you to set the output when DMX signal is interrupted. MODE MENU 2. -
Page 11: 1Ch./ 2Ch./ 4Ch. Dimmer Pack
2. Operation Guide 2.1.5 Channel DMX Address 3. Tap UP/DOWN to select DMX address from Receive Stand by 001-512 for the channel. MIDI Chase MODE MENU 4. Continue steps 2-3 until each of the four channels has a DMX address. 2.1.6 1CH./ 2CH./ 4CH. -
Page 12: Chase Mode
2. Operation Guide 2.2 Chase Mode If you set 4 channel output for this dimmer, this unit can be used as a 4 channel chaser. This function allows you to select any of these 16 built-in programs or set the pack to chase as desired to get a more dramatic light show. You may control the speed at which the programs will chase. -
Page 13: Chase Effect
2. Operation Guide 2.2.2 Chase Program 2. Tap UP/DOWN to select from 1-16 programs. Receive Stand by MIDI Chase MODE MENU 2.2.3 Chase Effect 1. In Chase Mode, tap MENU until Chase Effect Receive Stand by is activated. MIDI Chase MODE MENU 2. -
Page 14: Chase Speed
2. Operation Guide 2.2.4 Chase Speed 1. Enter Chase mode. 2. Tap the Menu button until the Segment Display Receive s p 0 2 show "SP" followed by two numbers. Stand by MIDI Chase MODE MENU 2. Tap UP/DOWN to select desired chasing speed. Receive s p 0 3 Stand by... -
Page 15: Dimmer Pack/Switch Pack
2. Operation Guide 2.2.5 4 Channel Chaser 2. Tap UP/DOWN to select 4ch mode. The Receive programs will chase only when this unit Stand by MIDI Chase serves as a 4 channel chaser. MODE MENU 2.3 Dimmer pack/Switch pack 1. In Receive or Chase mode, tap MENU until the Receive Segment Display shows "DI"... -
Page 16: Channel Dimmer Mode
2. Operation Guide 2.4 Channel Dimmer Limit 1. In Receive or Chase mode, tap MENU until the Segment Display shows channel dimmer limit, Receive Stand by DMX LED will be off or flash. MIDI Chase MODE MENU 2. Tap UP/DOWN to adjust the value between 000- Receive Stand by 100. - Page 17 2. Operation Guide 2.5 Remote Type 2. Tap UP/DOWN to change between FOOT and Receive RF modes. Stand by MIDI Chase If FOOT is selected, a foot control(sold separately) is used to control this unit. If RF is selected, a detector and a RF control(sold MENU MODE separately) are required to be used.
-
Page 18: Technical Specifications
3. Technical Specifications Power Input ............. AC 120V ~ 50-60Hz, 20A max. Channel Output ............5A/CH., Total 20A max. Channel Fuse ..............F6A 250V 5x20mm DMX In/Out ..........3-pin XLR male & female socket MIDI In/Thru ................ 5-pin multi socket Dimensions ................ - Page 20 Elation Professional A Division of the American DJ Group of Companies 4295 Charter Street Los Angeles, CA 90058 USA T el: 323-582-3322 Fax: 323-582-3311 Web: www.elationlighting.com 24-004-1253 E-mail: info@elationlighting.com Rev 1.0 March, 2004...
