- Page 1 1ST PRINTING SEPT 01 Universal Kit Kit Installation Instructions & Service Manual Switchable FROM High Resolution 31K TO Standard (Low) Resolution 15.75K. 1 - 2 PLAYER GAME SEGA ENTERPRISES, INC. USA MANUAL NO. 999-1318...
- Page 2 VISIT OUR WEBSITE!
- Page 3 Capcom vs SNK 2 Sega Naomi System Kit Contains List Desc Part # NAOMI POWER SUPPLY 400-5397-01 AUDIO POWER AMP 2 CH 838-13616 AUDIO XFORMER 120V 560-5407-UL JAMMA I/O BD (NAOMI) 838-13683-93CV1 USB CABLE 600-7141-200 VGA VIDEO CABLE 600-7009-2500 ASSY CASE PC1 DIMM BD...
- Page 4 Capcom vs SNK 2 Sega Naomi System Kit Contains List Desc Part # MARQUEE ART 999-1330 INSTR. SHEET (PLAYER) 999-1331 INSTR. SHEET #2 (CNTRL) 999-1332 SIDE ART 999-1333 CTRL PNL OVERLAY 999-1334 DECAL BTTN (LIGHT)PNCH-RED 999-1335 DECAL BTTN (MIDDLE)PNCH-GRN 999-1336...
- Page 5 DESIGNED RELATED PARTS MARQUEE ART 999-1330 CTRL PNL OVERLAY 999-1334 INSTR. SHEET #2 (CNTRL) 999-1332 www.seuservice.com...
- Page 6 SIDE ART 999-1333 INSTR. SHEET (PLAYER) 999-1331 DECAL BTTN (LIGHT)PNCH-RED[999-1335] DECAL BTTN (MIDDLE)PNCH-GRN[999-1336] DECAL BTTN (HEAVY)PNCH-BL[999-1337] NOT PICTURED DECAL BTTN (LIGHT)KICK-RED [999-1338] DECAL BTTN (MIDDLE)KICK-GRN [999-1339] DECAL BTTN (HEAVY)KICK-BL [999-1340] www.seuservice.com...
-
Page 7: Service Bulletin
ALL SEGA NAOMI KITS PROBLEM: The SEGA Naomi Game kits are actually ‘JAMMA Dependent’. What this means exactly is they will only install into existing JAMMA Cabinets. If an operator tries to install these kits into a Non-JAMMA cabinet, they will first have to bring the wiring up to JAMMA Standards. - Page 8 INSTALLATION INSTRUCTIONS 1) First. Remove all access panels from the game. Locate the original game Logic PCB’s & Power Supply and remove from the Cabinet by first disconnecting all harnesses from the boards. (You need only to splice in the Main Power (110v AC) into the 3-Pin Connector (GRN/WHT/BLK).) 2) Remove all existing game harnesses (we suggest using New Jamma Harnesses (NOT contained in the kit) to ensure reliability).
- Page 9 INSTALLATION INSTRUCTIONS 9) Proceed to place new decals on the sides of the cabinet. Locate a new monitor bezel, if needed, and replace glass, if required (due scratches). Install Instruction Placard to the back of the Monitor Glass. NOTE: As a precaution, disconnect the JAMMA Harness from the I/O Boards and turn power on. With a Multi-Meter, measure the 5v and 3.3v.
- Page 10 Sega Naomi System Switch Bracket and Speaker Installation Diagrams (Figure 3) To CN1 of Amplifier Board JAMMA Pin 8 Pin 1 Yellow Wire from Extra Pin 4 Harness (+5v) Pin 5 Coin Meter Test Service JAMMA Pin Volume JAMMA Pin...
- Page 11 Sega Naomi System JAMMA Harness Wiring (JAMMA I/O BD) (Figure 4) Ground Ground Ground Ground +5v (Not Used) +5v (Not Used) +5v (Not Used) +5v (Not Used) (Not Used) (Not Used) +12v (Not Used) +12v (Not Used) Coin Meter 1...
- Page 12 Sega Naomi System Filter Board Information Connector Description etc. PSW2 PSW1 DIPSW1 Service Test Switch Switch Preamp Level VGA Level Power Connectors Audio Out Video Out Setting for High Resolution 31KHZ 1 -4 off Setting for Standard Resolution 15KHZ 1 on 2-4 off.
- Page 13 SOFT KIT PART NO. DESCRIPTION 1 + 2 + 3 610-0624-0003 GD SOFT KIT CAPCOM VS.SNK 2 GDS-0003 NAOMI GDROM CAPCOM VS.SNK 2 KEY CHIP 253-5507 DISK CASE WITH IC HOLDER Handling the GD-ROM Disk Do not contaminate the disks with your fingerprints or dust particles. Contaminated disks may lower audio and video quality.
- Page 14 © CAPCOM CO., LTD. 2001 ALL RIGHTS RESERVED. © SNK 2001 MANUAL WARNING U.S.A. version of this game is for the North American countries only. Europe version of this game is for the European countries only. Sales, export, or operation outside these countries may b construed as copyright and trademark infringement and is strictly prohibited.
- Page 15 CAUTION For your safety, please read and abide by the following instructions when handling the P.C. board. Make sure the power is off before installing the board or changing the settings of the board. Do not damage the wiring cables. Do not disassemble the case.
- Page 16 CONTROL PANEL LAYOUT Jump Lever Buttons SHOT 3 SHOT 3 SHOT 2 SHOT 2 Moves the player to the SHOT 1 SHOT 1 jump/crouch, left/right Heavy Punch of the screen. Middle Punch Light Punch SHOT 6 SHOT 6 Left Right * Please use the SHOT 5 SHOT 5...
- Page 17 HOW TO ENTER THE TEST MODE Press the Test Button inside the cabinet and the "NAOMI SYSTEM MENU" will appear on the screen. Press the Service Button to move the "g " cursor and press the Test Button to enter various test modes. (For the details on "NAOMI SYSTEM MENU", please refer to "NAOMI SERVICE MANUAL".) To enter the GAME TEST MODE, move the "g "...
- Page 18 GAME TEST MODE On this screen, you can test "input signal" of the lever/buttons and can also set the game's difficulty. Your setting will be saved in the backup RAM. CONTROLS IN GAME TEST MODE Decide an item * Use the lever and the buttons Select an item as illustrated.
- Page 19 GAME CONFIGURATION SOUND MODE STEREO DEMO SOUND HALF GAME TEST MODE CONTINUE INPUT TEST GAME DATA DIFFICULTY EASY * 2 * * * * ]HARD GAME CONFIGURATION DAMAGE LEVEL LOW [ * 2 * * * * ]HIGH PASSWORD TIMER SPEED SLOW * 2 * * * * ]HIGH EXIT...
- Page 20 To exercise its maximum performance, it is indispensable to install the board in the cabinet equipped with 31K monitor that is capable of high resolution graphics. (Ex. "BLAST CITY" "MEGALO 410" etc. from Sega) To enjoy NAOMI's graphics at its best, please use the cabinet with 31K monitor.
- Page 21 According to your DIMM BD type, attach the correct sticker as follows. 442-00084B-01 (STICKER 840-0084B-01) Attached place PART NO. DESCRIPTION 840-0001F ASSY CASE NAO DIMM BD COM KEY CHIP 1 + 2 840-0084B-01 DIMM BD NAO CPvsSNK2 442-00084B-02 (STICKER 840-0084B-02) Attached place PART NO.
- Page 22 SOFT KIT STOP Handling the GD-ROM Disc Do not contaminate the discs with your IMPORTANT fingerprints or dust particles. Contaminated discs may lower audio and video quality. When cleaning the discs, do not use volatile chemicals (benzine, thinner, etc.), cleaning sprays, and antistatic agents.
- Page 23 When you order the GD-ROM disc only, please mention the Part No. 610-0625- **** . PART NO. DESCRIPTION 1 + 2 + 3 + 4 610-0630-0008 GD SOFT KIT CPvsSNK2 ENG NAOMI GDROM CPvsSNK2 KEY CHIP 420-6620-01 SERVICE MANUAL CPvsSNK2 ENG 253-5507 DISC CASE WITH IC HOLDER 1 + 4...
- Page 24 GAME BOARD Do not expose the Game Board so as to avoid causing an accident or malfunctioning. Static electricity discharge can damage electronic parts on the IC Board. Before starting work by opening the Shield Case Lid, be sure to touch grounded metallic surfaces to discharge physically charged static electricity.
- Page 25 TRANSFORMER 838-13616 120 Vac Input 120V AUDIO POWER AMP 2CH 560-5407 JST VH 4P [Extra] [GD ROM DRIVE] 5k pot Phono plugs SPEAKER OUTPUTS COIN COUNTER To Extra 400-5397 Yellow Wire SW REGU FOR JVS To PIN 8 of Jamma 600-6743-050 600-7141-050 JAMMA CONNECTIONS USED ARE:...
- Page 26 Warranty Your new Sega Product is covered for a period of 90 days from the date of shipment. This certifies that the Printed Circuit Boards, Power Supplies and Monitor are to be free of defects in workman- ship or materials under normal operating conditions. This also certifies that all Interactive Control Assemblies are to be free from defects in workmanship and materials under normal operating condi- tions.
