- Page 1 NetworkHD™ Technical Reference Guide NetworkHD™ 100 | 200 | 400 | 600 Series Document Revision: v1.1 Document Date: April 9 2018 Supported Firmware: v1.0.0 or higher Copyright © 2018 WyreStorm Technologies | Product specifications or appearance subject to change without notice.
-
Page 2: Table Of Contents
Contacting Technical Support ...................... 22 Appendixes ..........................23 Revision History ........................... 27 Publication Disclaimer ......................... 27 © Copyright 2018 WyreStorm Technologies | wyrestorm.com Outside UK: 844.280.WYRE (9973) | UK: +44 (0) 1793 230 343 2 of 28 NetworkHD™ Technical Reference Guide | 180409... -
Page 3: Overview
Whether using the NetworkHD Console configuration software, the built in Web UI, NetworkHD touch, or 3 party control system all communications to NetworkHD traverse through the CTL. Only a single CTL is required per system. © Copyright 2018 WyreStorm Technologies | wyrestorm.com Outside UK: 844.280.WYRE (9973) | UK: +44 (0) 1793 230 343 3 of 28 NetworkHD™... -
Page 4: Encoders
Every NetworkHD Encoder supports the direct connection of HDMI devices and DVI-D (via adapter), while other connection types are available on other products. • NetworkHD 200 series adds Component (YPbPr) and VGA (RGBHV) video sources. • NetworkHD 600 series also introduces native DisplayPort connectivity. -
Page 5: Networkhd Series Encoder/Decoder Comparison
Video Wall 10x10 (NHD-210-RX) 16x16 Image Flip/Rotate/Scale No/No/Yes No/No/Yes Multi-View NHD-220-RX/NHD-250-RX Power © Copyright 2018 WyreStorm Technologies | wyrestorm.com Outside UK: 844.280.WYRE (9973) | UK: +44 (0) 1793 230 343 5 of 28 NetworkHD™ Technical Reference Guide | 180409 support@wyrestorm.com... -
Page 6: Networkhd Touch
Multiview configurations for use with capable NetworkHD components. NetworkHD Console is part of the WyreStorm Management Suite configuration tool which contains other tools for configuring NetworkHD as well as other WyreStorm products. It is available on the website via the product pages. Visit the Management Suite page for more information. -
Page 7: Application Scenarios
Using NetworkHD components for one to many installations dramatically decreases the amount of equipment required at the source location. NetworkHD can be used to form a virtual “distribution amplifier” for source equipment. © Copyright 2018 WyreStorm Technologies | wyrestorm.com Outside UK: 844.280.WYRE (9973) | UK: +44 (0) 1793 230 343 7 of 28 NetworkHD™... -
Page 8: Many To Many Scenario - Multiple Encoders And Decoders
Arbitrary Layouts Note: Multiview functionality is not available on NHD-600 upon initial release. Functionality will be added via a future firmware update. © Copyright 2018 WyreStorm Technologies | wyrestorm.com Outside UK: 844.280.WYRE (9973) | UK: +44 (0) 1793 230 343 8 of 28 NetworkHD™... - Page 9 Note: Video Wall functionality is not available on NHD-600 upon initial release. Functionality will be added via a future firmware update. Video Wall Wiring © Copyright 2018 WyreStorm Technologies | wyrestorm.com Outside UK: 844.280.WYRE (9973) | UK: +44 (0) 1793 230 343 9 of 28 NetworkHD™...
-
Page 10: System Design Guidelines And Requirements
NetworkHD components to ensure adequate airflow is maintained. Software/Firmware Where possible WyreStorm ships all components with the most up to date firmware, however before starting any installation the firmware in the components should be verified to be the latest. This will allow for the components to operate properly and ensure that the latest features are available. -
Page 11: Mounting/Installation
For AV and IT racks, WyreStorm offers rack mount kits to allow for quick and easy installation that provides a clean properly ventilated installation. All rack mount kits provide a steel housing that can be used in a central and secure location for the components. -
Page 12: Control Signal Compatibility
RS-232, Infrared, CEC and Ethernet. Refer to Appendix A.3 for the control signal attributes available for the NetworkHD family. © Copyright 2018 WyreStorm Technologies | wyrestorm.com Outside UK: 844.280.WYRE (9973) | UK: +44 (0) 1793 230 343 12 of 28 NetworkHD™... -
Page 13: System Infrastructure Guidelines And Requirements
NetworkHD 600 Series requires a 10Gb infrastructure rather than the typical 1Gb. This means that the WyreStorm recommended switches for 100/200 & 400 may not be common to the 600 Series and a separate list of recommendations exist. -
Page 14: Required Network Switch Features
Required Network Switch Features Switch Ports The WyreStorm NetworkHD family devices utilize twisted pair cable Ethernet standards. The Ethernet switch port connecting directly to a NetworkHD device therefore must support the following: NHD-000-CTL: 1Gb/s Full-duplex 1000Base-T IEEE 802.1ab NHD 100, 200 and 400 Series:... -
Page 15: Ethernet Switch Configuration
Ethernet switch configuration The following list includes all network switch configuration options that WyreStorm engineers have come across so far. NetworkHD data is typically contained in one VLAN. Look for these or similar options when configuring your switch. Feature Setting •... -
Page 16: Using Multiple Network Switches
Often, switch vendors will utilize special port modes for use with stacking and some switches make use of dedicated stacking ports and cables. These will have a finite bandwidth. © Copyright 2018 WyreStorm Technologies | wyrestorm.com Outside UK: 844.280.WYRE (9973) | UK: +44 (0) 1793 230 343 16 of 28 NetworkHD™... - Page 17 Forwarding unknown multicast to multicast router port X Must be enabled on all switches that do not contain the only IGMP Querier function © Copyright 2018 WyreStorm Technologies | wyrestorm.com Outside UK: 844.280.WYRE (9973) | UK: +44 (0) 1793 230 343 17 of 28 NetworkHD™...
- Page 18 Disable Router port only* multicast Port which connects the extended switch back to the switch running an IGMP Querier © Copyright 2018 WyreStorm Technologies | wyrestorm.com Outside UK: 844.280.WYRE (9973) | UK: +44 (0) 1793 230 343 18 of 28 NetworkHD™...
-
Page 19: Networkhd Stream Bandwidth
For example, when using a core/extended topology, the link speed between switches must exceed the bitrate sum of the total number of NetworkHD encoders required by decoders on a link segment. © Copyright 2018 WyreStorm Technologies | wyrestorm.com Outside UK: 844.280.WYRE (9973) | UK: +44 (0) 1793 230 343 19 of 28 NetworkHD™... -
Page 20: Multiple Vlan Networkhd
NetworkHD. A final conclusion can be made through practical function verification and pressure testing. WyreStorm cannot offer detailed support on switches that are not documented by our library of switch configuration guides, therefore choosing to use other switch models is done so at the installers own risk. -
Page 21: Installation Checklist
8. Evaluate if PoE will be utilized ............................9. Evaluate if an existing WyreStorm Network Switch Guide exists for a preferred Network switch vendor and model 10. Select Network switch(es) based on steps 1 – 9 and other information provided in this TRG ...... -
Page 22: Troubleshooting
Verify that the Network adapter settings on the administration PC are set to the same subnet as the target NetworkHD devices. • Verify that all WyreStorm software is correctly allowed to traverse any firewall on the administration PC. • If IP address details are unknown, restore a NetworkHD device to the factory default IP address. -
Page 23: Appendixes
Not NHD 100 Series. Only applicable to 200 Series products with analog video input. Other HDR standards supported with firmware upgrade Only applicable to 200 Series with analog video input. © Copyright 2018 WyreStorm Technologies | wyrestorm.com Outside UK: 844.280.WYRE (9973) | UK: +44 (0) 1793 230 343 23 of 28 NetworkHD™... - Page 24 On 400 Series, 25fps conversion when connected encoder receives 50fps source video content and decoder scaling is set to “pass-through”. Other HDR standards supported with firmware upgrade © Copyright 2018 WyreStorm Technologies | wyrestorm.com Outside UK: 844.280.WYRE (9973) | UK: +44 (0) 1793 230 343 24 of 28 NetworkHD™...
- Page 25 (if used). When utilizing the NetworkHD API to generate RS-232 data, the UART attributes in the API command and subsequently generated RS-232 data can be different from the statically assigned, default values. © Copyright 2018 WyreStorm Technologies | wyrestorm.com Outside UK: 844.280.WYRE (9973) | UK: +44 (0) 1793 230 343 25 of 28 NetworkHD™...
- Page 26 Appendix A.3.3 Infrared Compatibility Using WyreStorm infrared emitters and receivers is the best way to ensure that most IR coding formats are transmitted and received by the NetworkHD system. Other 3 party emitters and receivers can be used; however, these devices must operate in the same manner as the WyreStorm devices.
-
Page 27: Revision History
WyreStorm reserves the right to change software, control codes and specifications without notice. WyreStorm will not be liable for any use of this information or any changes it may make to those products. The use of this information constitutes an agreement by the user to these limitations and exclusions. - Page 28 Tel: +1 518-289-1293 UK/EMEA: Unit 22, Ergo Business Park, Swindon, Wiltshire, SN3 3JW, UK Tel: +44 (0) 1793 230 343 WyreStorm Technologies reserves the right to change the physical appearance or technical specification of this product at any time. Visit wyrestorm.com...
