- Page 1 MPZ-5125 P. A. AmPlifiER WiTH 5 OUTPUT ZONES N Instruction Manual...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURiTY AND THE ENViRONmENT ElECTRiCAl SECURiTY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. -
Page 4: Controls And Functions Front Panel
DESCRIPTION P. A. amplifier with 5 x 100 V line output zones and independent volume control per zone, with the possibility of remote paging through the zone selector microphone model m-512. 120 W RmS, 4 mic. inputs, 2 auxiliaries and 1 emergency. Chimes. -
Page 5: Back Panel
17.- PWR: system lED on/off indicator. 18.- AC: lED indicator which lights up when the system is connected to 230 V AC. BACK PANEL 1.- AC socket: for connecting the AC power supply cable. 2.- ON/OFF + 48 V PHANTOM: switches which allow you to activate or deactivate the 48 V DC Phantom for each one of the microphone inputs 1 to 4. -
Page 6: Input Priority
switchboard characteristics in order to adjust it to the amplifier input level. 15.- TEL. VOLUME: volume control for the TEl. iNPUT. it allows you to adjust the volume of the telephone switchboard which is connected to the TEl. iNPUT terminal. 16.- CHIME: for selecting between the 2 and 4 tone chimes. - Page 7 The second level of priority corresponds to the TEl. iNPUT, together with the microphone model m-512 signal, which have priority over the rest of the inputs. The priority of both inputs is activated when a signal is detected in the input connector and therefore automatically weakening the miC1 to 4 and liNE 1 and 2 inputs so that the message can be heard clearly.
- Page 8 CONNECTION make the connections with the amplifier and all the audio system components switched off and disconnected from the power supply. Connect the microphones through the miC 1 to 4 inputs and select if you want to activate phantom (for condenser microphones) or not (dynamic microphones).
-
Page 9: Block Diagram
BLOCK DIAGRAM - 9 -... -
Page 10: Specifications
SPECIFICATIONS MPZ-5125 CHARACTERISTICS P. A. amplifier. 5 zones of selectable loudspeakers with independent volume control. microphone input with zone selector. Phantom power supply, priority, chimes, siren and emergency paging. POWER 120 W RmS RESPONSE 20-20 000 Hz ±3 dB DISTORTION Harmonic: <... -
Page 11: Declaration Of Conformity
2 months after being conscious of the problem. it is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it.
