- Page 1 MP -124U PA AMPLIFIER WITH USB/SD/MP3 PLAYER INSTRUCTION MANUAL...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. -
Page 4: Controls And Functions Front Panel
DESCRIPTION - PA amplifier with USB/SD/MP3 player. - Selector with 3 aux inputs and microphones with selectable priority. - Different chimes and alarm. Output for priority in 24 V attenuators. - 180 W maximum, 120 W RMS. CONTROLS AND FUNCTIONS FRONT PANEL 1.- MIC 2: microphone 2 input, XLR connector. -
Page 5: Rear Panel
REAR PANEL 1.- 24 V DC power supply terminals. In order to operate the amplifier with 24 V DC power supply, batteries, emergency power supply system, etc. Make the connection with 2.5 mm cable section to the - negative and + positive terminals. 2.- AC socket: for connection of AC power supply cable. -
Page 6: Remote Control
13.- Contact closures. 4-TONE CHIME and GROUND: short-circuits these two contacts to activate a 4-tone chime warning. The volume of the chimes can be adjusted with the CHIME VOL control. DIN ALARM and GROUND: short-circuits these two contacts to activate an alarm. The alarm volume can be adjusted with the ALARM VOL control. -
Page 7: Input Priority
CONNECTION Make the connections with the amplifier and all the components of the audio system switched off and disconnected from the power supply. Firstly, connect the audio sources through the AUX inputs 1-2-3. Connect the microphones to the MIC inputs 1 to 4, and select if you need to apply 48 V phantom power supply (for condenser microphones) or not (dynamic microphones). -
Page 8: Technical Specifications
TECHNICAL SPECIFICATIONS MPA-124U CHARACTERISTICS PA amplifier. USB/SD/MP3 player. Phantom power supply. Selectable priority paging. Chimes and alarm. 3 aux input selector. POWER 180 W maximum, 120 W RMS RESPONSE 50-16,000 Hz ±3 dB DISTORTION Harmonic: < 0.5% at 1 kHz INPUTS 1 remote mic. -
Page 9: Warranty
2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it. - Page 10 - 10 -...
- Page 11 - 11 -...
- Page 12 www.fonestar.com...
