  • Page 1 Keysight 16034G Test Fixture Operation Manual...
  • Page 4 WARNINGS elsewhere in this manual may impair the protection provided by the equipment. Such noncompliance would also violate safety standards of design, manufacture, and intended use of the instrument. Keysight Technologies assumes no liability for the customer’s failure to comply with these requirements.
  • Page 5 To avoid the danger of introducing additional hazards, do not install substitute parts or perform unauthorized modifications to the instrument. Return the instrument to a Keysight Technologies Sales and Service Office for service and repair to ensure that safety features are maintained in operational condition.
  • Page 6 Instruments are warranted for a period of one year. Fixtures and adapters are warranted for a period of 90 days. During the warranty period, Keysight Technologies will, at its option, either repair or replace products that prove to be defective.
  • Page 7 Assistance Product maintenance agreements and other customer assistance agreements are available for Keysight Technologies products. For any assistance, contact your nearest Keysight Technologies Sales and Service Office. Addresses are provided at the back of this manual. Safety Symbol General definitions of safety symbols used on the instrument or in its manuals are listed below.
  • Page 9: Table Of Contents

    Connecting the 16034G ........
  • Page 10 Contents...
  • Page 11: Overview

    Overview...
  • Page 12: Product Overview

    Overview Product Overview Product Overview The 16034G is designed for chip type components whose sizes range from 0201 to 1306. This test fixture can take measurements of the chip type L,C,R. Figure 1-1 Product Overview Chapter 1...
  • Page 13: Incoming Inspection

    Inspect the shipping container for damage. If the shipping container or cushioning material is damaged, it should be kept until the contents of the shipment have been checked for completeness and the 16034G has been checked mechanically and electrically. The contents of the shipment should be as listed in Table 1-1.
  • Page 14: Functions

    Overview Functions Functions Figure 1-2 16034G Parts Part FUNCTION Contact Pin Contact for DUT electrode. LOW side Contact Pin connected to a instrument’s L and HIGH side Contact Pin connected to a instrument’s H Knob For lateral adjustment of HIGH side Contact Pin.
  • Page 15: Operation

    Operation This chapter describes the proper methods for open and short correction and DUT measurement.
  • Page 16: Performing Open And Short Correction

    The following procedure shows correction and measurement by the 16034G. Take care to avoid rough handling and never allow any mechanical shock to the 16034G, especially against the contact pins from the sides or any to the parts mounted on top of the fixture.
  • Page 17: Performing Short Correction

    Operation Performing Open and Short Correction Performing Short Correction The short correction procedure is as follows. 1. Push the HIGH side contact pin’s knob to the left to make firm contact with the LOW side contact pin (Figure 2-2). Tighten the contact pin locking screw to secure the HIGH side contact pin.
  • Page 18: Performing Open Correction

    Operation Performing Open and Short Correction Performing Open Correction The open correction procedure is as follows. 1. Push the HIGH side contact pin so that the distance between the HIGH and the LOW contact pins matches the DUT’s width (Figure 2-3).
  • Page 19: Dut Measurement

    Operation DUT Measurement DUT Measurement Before performing DUT measurement, open and short correction should be done as described in the previous sections. If measurement frequency is over 3 MHz, perform load correction before the DUT measurement described later onwards. 1. Adjust the HIGH side contact pin so that the DUT is positioned on the center of the measuring stage and secure the contact pin with the contact pin locking screw.
  • Page 20: Dut Measurement Over 3 Mhz

    Operation DUT Measurement Measurement values can vary depending on contact pressure when measuring ferrite inductors or multi-layer ceramic capacitors with high permittivity. When measuring this kind of device, removing the E-ring can weaken the spring pre-load. However, this technique may increase contact resistance and thus degrades the accuracy of D parame- ter measurements.
  • Page 21: Specifications And Supplemental Performance Characteristics

    Specifications and Supplemental Performance Characteristics This chapter provides specifications and supplemental performance characteristics of the 16034G test fixture.
  • Page 22: Specifications

    Specifications and Supplemental Performance Characteristics Specifications Specifications Applicable Instruments LCR meters and impedance analyzers with four-terminals Applicable DUT Type Chip components Applicable DUT dimensions Maximum Voltage ± 40 V peak max. (AC+DC) Operating temp. 0°C to +55°C Environment 15% to 95%RH (@ wet bulb temp. 40°C) humidity Non Operating temp.
  • Page 23: Supplemental Performance Characteristics

    Specifications and Supplemental Performance Characteristics Supplemental Performance Characteristics Supplemental Performance Characteristics This section provides useful data on the 16034G. These supplemental performance characteristics should not be considered specifications. Frequency Range With OPEN/SHORT correction  3 MHz  With OPEN/SHORT/LOAD correction...
  • Page 24 Specifications and Supplemental Performance Characteristics Supplemental Performance Characteristics where Dx is the measured value of D. It is necessary for Ze to be below 10 %. D is not expressed as a percentage but as an absolute value. Rs (ESR) Measurement Additional error Rse[%] of the Rs measurement is calculated by additional error Ze [%] of |Z| measurement as follows.
  • Page 25: Contact Pressure

    Specifications and Supplemental Performance Characteristics Supplemental Performance Characteristics Contact Pressure The following data are supplemental performance characteristics for the spring that applies contact pressure. Spring constant ± 10 % 37 gf/mm Spring pre-load Approximately 400 g (without E-ring, approximately 20 g) Chapter 3...
  • Page 26 Specifications and Supplemental Performance Characteristics Supplemental Performance Characteristics Chapter 3...
  • Page 27 This information is subject to change without notice. © Keysight Technologies 1999, 2001, 2015, 2016 Edition 6, November 2016 *16034-90011* 16034-90011 www.keysight.com...
