3.18.2 DIGITAL INPUT CHANNEL ALLOCATIONS

CHANNEL # FUNCTION
1 AUTO SWITCH
2 MANUAL SWITCH
3 ALARM ACKNOWLEDGE
4 ESTOP
5 REMOTE START
6 BATTERY CHARGER FAIL
7 USER CONFIGURABLE 07
8 USER CONFIGURABLE 08
9 USER CONFIGURABLE 09
10 USER CONFIGURABLE 10
11 USER CONFIGURABLE 11
12 USER CONFIGURABLE 12
13 USER CONFIGURABLE 13
14 USER CONFIGURABLE 14
15 USER CONFIGURABLE 15
16 USER CONFIGURABLE 16
17 USER CONFIGURABLE 17
18 USER CONFIGURABLE 18
19 USER CONFIGURABLE 19
20 USER CONFIGURABLE 20
21 USER CONFIGURABLE 21
22 USER CONFIGURABLE 22
23 AUX INPUT G
24 AUX INPUT H
25 MODEM SELECTED
26 GENERATOR OVERSPEED
27 AUX INPUT A
28 AUX INPUT B
29 AUX INPUT C / LINE POWER
30 AUX INPUT D / GEN POWER
31 AUX INPUT E
32 AUX INPUT F

3.18.3 DIGITAL OUTPUT CHANNEL ALLOCATIONS

CHANNEL #
1 User assigned 1
2 User assigned 2
3 Fault Relay
4 User assigned 4
5 User assigned 5
6 User assigned 6
7 Auto Led On
8 User assigned 8
9 Fault Led On
10 User assigned 10
11 User assigned 11
12 User assigned 12
13 User assigned 13
14 User assigned 14
15 User assigned 15
16 User assigned 16
17 Load Shed 0
18 Load Shed 1
19 Load Shed 2
20 Permissive (ATS) 0
21 Permissive (ATS) 1
22 Permissive (ATS) 2
23 All Running Relay
24 Exercise With Transfer Relay
25 PWM 5
26 PWM 6
27 Reserved
28 Reserved
29 Reserved
30 Watchdog toggle output
31 Reserved
32 Reserved
Operation
FUNCTION
Free for customer use
Free for customer use
For customer status connection
Free for customer use
Free for customer use
Free for customer use
Front Panel Led
Free for customer use
Front Panel Led
Free for customer use
Free for customer use
Free for customer use
Free for customer use
Free for customer use
Free for customer use
Free for customer use
For transfer switch connection
For transfer switch connection
For transfer switch connection
For transfer switch connection
For transfer switch connection
For transfer switch connection
For transfer switch connection
For transfer switch connection
For diagnostics
For diagnostics
Do not use
Do not use
Do not use
Output to watchdog module
Do not use
Do not use
19
