Ads1X7Xevm Bill Of Materials - Texas Instruments ADS1x7xEVM-PDK User Manual

www.ti.com
Item No. Qty Value
28 1
29 5
30 1
31 4
32 2
33 5
34 1
35 1
36 4
(2)
37 1
38 1
39 1
40 1
41 1
42 1
43 2
44 1
45 1
46 4
47 4
(2)
Installed for ADS1278EVM-PDK. For other EVM-PDKs, the appropriate device will be installed.
SBAU197A – February 2012 – Revised January 2016
Submit Documentation Feedback
Table 11. ADS1x7xEVM Bill of Materials (continued)
Ref Des
S2 Switch, 6 POS, SPST, Low Profile, SMT,
0.50 centers
S3-5 S7-8 Switch, Slide DPDT, Low Profile
S6 CONN HEADER 12POS DUAL 2MM T/H
TP1 TP4 TP7 Test Point, Black, Thru Hole Color Keyed
TP11
TP6 TP8 Test Point, White, Thru Hole Color Keyed
TP2 TP3 TP5 TP9 Test Point, Red, Thru Hole Color Keyed
TP10
U1 IC, Precision Voltage Reference, 2.5V
U2 IC, Op Amp, High-Speed, Single-Supply, R-
R
U3 U5 U9 U11 IC, Negative R-R Input, R-R Output, Fully
Differntial Amplifier
U4 IC, Quad/Octal, Simultaneous Sampling, 24-
Bit A-D Converter
U6 Single 2 line To 1Line Data
Selector/Multiplexer
U10 IC, Single Inverter
U12 IC, single Positive-Edge-Triggered D-Type
Flip-Flop With Clear And Reset
U13 IC, Configurable Multiple-Function Gate
U14 IC, 256K CMOS Serial EEPROM
U7-8 IC, Low Voltage 16-BIT I2C and SMBus
Low-Power I/O Expander With Interrupt
Output and Configuration Registers
Y1 Clock Oscillator, 27MHz
PCB, 3.31 In x 2.88 In x 0.062 In
Shunt, 100-mil, Black
SHUNT JUMPER
