Burgundy
Oil burning stove
174 10 25
174 10 31
EN1 - NF D 35-385
Description of the appliance
Installation instructions
Operating instructions
Spare parts
Warranty certificate
Document n° 809-5EN ~ 15/04/1999
Français p. 1-12
English p. 13-24
Nederlands bl. 25-36
Technical manual
to be saved
by the user
for future reference
Les Fonderies Franco-Belges
59660 MERVILLE
Phone : 03.28.43.43.43
Fax : 03.28.43.43.99
RC Hazebrouck 445750565B
Subject to modifications
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FRANCO BELGE Burgundy 174 10 25
Summary of Contents for FRANCO BELGE Burgundy 174 10 25
- Page 1 Burgundy Document n° 809-5EN ~ 15/04/1999 Français p. 1-12 English p. 13-24 Oil burning stove Nederlands bl. 25-36 174 10 25 174 10 31 EN1 - NF D 35-385 Technical manual to be saved by the user for future reference Description of the appliance Installation instructions Operating instructions...
-
Page 2: Table Of Contents
Burgundy Oil burning stove CONTENTS Page Description of the unit ....15 Package ......15 Specifications . -
Page 3: Description Of The Unit
Oil burning stove Burgundy 1. Description of the unit 1.1. Package SAFETY NOTICE : Read carefully all instructions before starting the installation. If the stove is not properly installed, a house fire may result. For your - 1 package : Stove complete safety, follow the installation directions. -
Page 4: Installation Instructions
Burgundy Oil burning stove 2. Installation instructions 2.1. Position of the unit - The position of the appliance must be chosen very care- fully in order to obtain the best possible results for heat distribution. - Position the unit to comply with the minimum clearances to combustible material. -
Page 5: External Tank
Oil burning stove Burgundy Ill. 3 - Adjustment screws and bracket 1 - Feet adjustment screws and caps. Ill. 6 - Fitting the tray 2 - Appliance fixing bracket (Canada). Ill. 4 - Burner level check Ill. 7 - Gravity or pumped oil supply 1 - 8 ft maxi 5 - Suction pump with reserve and filter... -
Page 6: Chimney Draught
Burgundy Oil burning stove setting screw # 3 counter clock-wise. - If the flame is too high ; reduce the flame by turning the setting screw clock-wise. Please note - Very important : The adjustments of the float regulator are very sensitive. The hight and the low setting screws must never be turned more than a 1/4 of a turn at a time in any direction from their initial setting. -
Page 7: Operating Instructions
Oil burning stove Burgundy 3. Operating instructions 3.1. Fuel Warning : Your stove is fitted with a specific carburettor for a specific oil. The fuel oil must be free from any dirt and water which could disturb the stove in operation. 174 10 25 : Use only kerosene (28 seconds). -
Page 8: Trouble Shooting
Burgundy Oil burning stove ¤ At least once a year / End of heating season : Clean with oil using a soft brush, never a wire-brush, or replace all the oil filters in the oil supply line. - replace the filter in the regulator, install the cover plate and secure with the screw. -
Page 9: Spare Parts
C = 174 10 31 L D = 174 10 31 K ber and colour index of the part. Example : Burgundy 174 10 25 Y, top plate 352124 76. N° Code Description ... . . Type ..A ..B ..C ..D ..Qty 100956 Axle . - Page 10 Burgundy Oil burning stove Ill. 10 - Stove - exploded view Document n° 809-5EN ~ 15/04/1999 Technical manual...
- Page 11 Oil burning stove Burgundy 310821 76 L. side panel ..........D ..01 310821 77 L.
- Page 12 FRANCO BELGE. Name and address of installer :_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ __ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Téléphone :_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...
