CHAPTER 3

MOD-RTC BOARD DESCRIPTION

3. Introduction to the chapter

Here you get acquainted with the main parts of the board. Note the names used on the board differ
from the names used to describe them. For the actual names check the MOD-RTC board itself.

3.1 Layout (bottom view)
