SMART-AVI D2H-4P-Quad Quick Start Manual

TECHNICAL SPECIFICATIONS

VIDEO
Format DisplayPort 1.2, HDMI
Input Interface (16) DisplayPort (female)
Output Interface (1) HDMI (female)
Resolution Up to 4K (3840x2160 @
Video Bandwidth 10.2 Gbps
USB
Input (4) USB Type B (female)
Output (2) USB Type A for keyboard/
mouse; (2) USB Type A
Transparent
CONTROL
Front Panel Tactile Switches
RS-232 Via SmartControl @ 9600
Hot Keys Via Keyboard
OTHER
External 100-240
Power
VAC/5VDC4A @10W
10W
Consumption
12"W x 3.5"H x 6"D
Dimensions
3.5 lbs.
Weight
40 ft.
Max. Cable Length
UL, CE, ROHS Compliant
Approvals
32-131°F (0-55°C )
Operating Temp.
Operating Humidity Up to 80%
WHAT'S IN THE BOX
PART NO. QTY DESCRIPTION
D2H-4P-Quad 1 16-Port DisplayPort IN and
HDMI OUT KVM Switch.
[Includes D2H-4P-Quad]
PS5VD4A 1 Wall Mounted 5V Power
Supply
Quick Start 1 Installation Setup/Part listing
Guide
