RoyalTek RGM-3000/REB-3000
GPS Module Operational Manual)
REB-3000
RGM-3000/REB-3000 Series System Block Diagram
The RGM-3000/REB-3000 series consists of SiRF star II chipsets technology, RoyalTek LNA and
proprietary software. The system is described as follows.
RGM-3000M/RGM-3000E
Patch ANT
LNA
SAW
Filter
Flash
Memory
SIRF
SiRF
GRF2I
GSP2e
3
RS232 port (TTL) x 2
Programming I/O port x 7
Control line x 4
