RoyalTek RGM-3000/REB-3000
GPS Module Operational Manual)
message section for <data>...<data>
definition
3
CKSUM is a two-hex character checksum
as defined in the NMEA specification . Use
of checksums is required on all input
messages.
4
Each message is terminated by using
Carriage Return (CR) Line Feed (LF) which
is \r\n which is hex 0D 0A. Because \r\n are

SIRF NMEA Input Messages

Message

Set Serial Port

Navigation Initialization

Set DGPS Port

Query / Rate Control
LLA Navigation
Initialization
Development Data On/Off
Input coordinates must be WGS84.
Set Serial Port
This command message is used to set the
protocol (SiRF Binary or NMEA) and/or the
communication parameters (baud , data bits,
stop bits, parity). Generally, this command is
used to switch the module back to SiRF
Binary protocol mode where a more
Table 8 Set Serial Port Data Format
Name Example
Message ID $PSRF100
Protocol
Baud
Data Bits
Stop Bits
Parity
Checksum
<CR><LF>
1
SiRF protocol is only valid for 8data bits, 1 stop bit,
and no parity.
LLA Navigation Initialization
This command is used to initialize the
Message
Identifier
(MID)
100 Set PORT A Parameters and protocol
101 Parameters required for start using X/Y/Z
102 Set PORT B parameters for DGPS input
103 Query standard NMEA message and/or set output rate
104 Parameters required for start using Lat/Lon/Alt1
105 Development Data messages On/Off
Units
PSRF100 protocol header
0 0=SiRF Binary, 1=NMEA
9600 4800,9600,19200,38400
8 8,7 1
1 0,1
0 0=None ,1=Odd,2=Even
*0C
End of message termination
not printable ASCII characters , they are
omitted from the example strings, but must
be sent to terminate the message and cause
the receiver to process that input message.
Note – All fields in all proprietary NMEA
messages are required, none are exceptional.
All NMEA messages are comma delimited
Description
extensive command message set is
available. When a valid message is received,
the parameters are stored in battery-backed
SRAM and then the Evaluation Unit restarts
using the saved parameters.
Table 8 contains the input values for the
following example:Switch to SIRF Binary
protocol at 9600,8,N,1
$PSRF100,0,9600,8,1,0*0C
Description
module for a warm start, which provide
current position (in X, Y, Z coordinates),
16
