RoyalTek GPS Module: REB-3310 Operational Manual Introduction RoyalTek REB-3310 low power and small form factor board is the newest generation of RoyalTek GPS Receiver. The GPS receiver is powered by SiRF Star III technology and RoyalTek proprietary navigation algorithm that providing you more stable navigation data.
REB-3310 Operational Manual REB-3310 Series System Block Diagram REB-3310 engine board consists of SiRF star III chipset technology; 4/8/16Mbits flash memory, and proprietary software. The system is described as follows. a. Support external active patch antenna b. Support 4/8/16 Mega bits flash memory...
REB-3310 Operational Manual Application Circuit (1) Ground Planes: REB-3310 GPS receiver needs two different ground planes. The GND_A pin(11、 12、13、14、15、16、18) shall be connect to analog ground. The GND pin(2、10、30) connect to digital ground. (2) Serial Interface: The Serial interface pin(RXA、TX1、TXB、RXB) is recommended to pull up(10KΩ).
REB-3310 Operational Manual antenna. The bias voltage will through RF_IN pin to provide active antenna bias voltage from Vcc_RF pin. If your bias voltage of active antenna isn’t 3.0V, you can input bias voltage to V_ANT_IN pin (pin 19). And input bias voltage of you need. It can open if you use passive antenna.
REB-3310 Operational Manual Hardware interface Definition of Pin assignment Pin # Signal Name I/O Description Characteristics DC Supply Voltage DC +3.3V±5% input Ground Digital Reference Ground Boot select Boot mode ≥ ≤ ≥ ≤ Serial port A Serial port A ≥...
Page 14
REB-3310 Operational Manual RF_ON This pin indicates state of RF voltage. RF_IN This pin receiver signal of GPS analog .due to the RF characteristics of the signal the design has to certain criteria. The line on the PCB from the antenna(or antenna connector) has to be a controlled impedance line (Microstrip at 50Ω).
REB-3310 Operational Manual Software Interface NMEA V3.0 Protocol Its output signal level is TTL: 4800 bps (default), 8 bit data, 1 stop bit and no parity. It supports the following NMEA-0183 Messages: GGA, GLL, GSA, GSV, RMC and VTG. NMEA Output Messages: the Engine board outputs the following messages as shown in Table...
Page 16
REB-3310 Operational Manual Units meters Geoid Separation meters Units meters Age of Diff. Corr. second Null fields when DGPS is not used Diff. Ref. Station ID 0000 Checksum End of message termination <CR><LF> Table 3 Position Fix Indicators Value Description...
Page 17
REB-3310 Operational Manual GSA-GNSS DOP and Active Satellites Table 4 contains the values of the following example: $GPGSA, A, 3, 07, 02, 26, 27, 09, 04, 15, , , , , , 1.8,1.0,1.5*33 Table 4 GSA Data Format Name Example...
Page 18
REB-3310 Operational Manual Table 5 GGA Data Format Name Example Units Description Message ID $GPGSV GSV protocol header Number of Range 1 to 3 Messages Messages Number Range 1 to 3 Satellites in View Satellite ID Channel 1(Range 1 to 32)
Page 19
REB-3310 Operational Manual Course Over 309.62 degrees True Ground Date 120598 ddmmyy Magnetic Variation degrees E=east or W=west Checksum End of message termination <CR><LF> VTG-Course Over Ground and Ground Speed Table 7 contains the values of the following example: $GPVTG, 309.62, T, , M, 0.13, N, 0.2, K*6E...
