SBC81821 Socket478 All-in-One CPU Card Series User's Manual


% 1  " *+










1. Make sure the power is OFF.
2. Set the configuration jumpers according to the jumper
settings on Chapter 2.
3. Install the SBC81821 CPU card into one of the slots on
the passive backplane. You may allow the SBC81821
to stand alone as a single board computer.
4. Connect the I/O cables and peripherals, i.e. floppy
disk, hard disk, monitor, keyboard, power supply and
etc. to the CPU board.
NOTE:
The color of pin one is usually red or blue,
while others are gray.
5. Turn ON the system power.
!&

Installation
