Promax -12 User Manual page 68

SCAN
Span
Reference level
TILT
Indication
Analysed band
Number of pilots
Pilots frequency
Pilots resolution
SPECTRUM ANALYSER
Span
Reference level
Analysed band
Detector
Bandwidth
Resolution
Peak detector
Full Span (5-1005 MHz)
Span 100 MHz
Span 15 MHz
Span 5 MHz
Span 1 MHz
Average detector
Span 15 MHz
Span 5 MHz
Span 1 MHz
6-62
Variable: 10, 30, 100, 300 MHz and full band (from 5 to
1005 MHz, according to the channel plan).
Variable from 60 to 120 dBµV in 10 dB steps.
Numerical and by level bar.
Forward (5 to 1005 MHz) or Return path (5 to 80 MHz).
4 per band.
From 5 to 1005 MHz.
10 kHz.
From 1 to 1005 MHz (1, 5, 15, 100 MHz, full span).
Variable from 60 to 120 dBµV in 10 dB steps.
Forward (5 to 1005 MHz) or Return path (5 to 80 MHz).
Peak or average.
200 kHz.
9 MHz.
900 kHz.
140 kHz.
50 kHz.
10 kHz.
140 kHz.
50 kHz.
10 kHz.
January 2015
