To change a given parameter turn the rotary selector
activated (this will appear shadowed) and then press. The value of the parameter
will be activated and may be changed by turning the rotary selector. When the
value you want appears, press the rotary selector
BAND
►
It permits to select between the FORWARD mode (5 to 1005 MHz) and the
REVERSE mode (5 to 80 MHz). When selecting one of these modes, the user
can define the associated frequency.
PILOT 1
►
It defines a frequency belonging to the forward or the reverse band where the
first measurement of level will be done. This parameter, and the rest of pilots,
is defined digit by digit, by pressing repeatedly and turning the rotary selector
.
PILOT 2
►
It defines the second pilot frequency belonging to the forward or reverse
band.
PILOT 3
►
It defines the third pilot frequency belonging to the forward or reverse band
PILOT 4
►
It defines the fourth pilot frequency belonging to the forward or reverse band.
IMPORTANT:
3-46
Figure 48. TILT configuration. (REVERSE mode).
To leave the configuration menu of the TILT mode, just
press the key of the operating mode you wish to access.
until the field is
to validate it.
