3.4.3 Energy Chain
The Energy Chain (E-Chain) is attached to the back side of the carriage and moves with the carriage when it is in motion during printing
operations. The E-Chain continuously supplies the moving carriage with the following:
• White Ink
• CMYK Ink
• Electrical Power
• Positive and Negative Pressure
• Communication Signals
• Printing Data
Document ID: OMM-00148 Rev. B
1
3
Figure 3-15: Energy Chain (E-Chain)
1
E-Chain
2
Internal Tubes and Wiring
3
E-Chain Trough Cover
4
E-Chain Trough
2
4
27
