- Page 1 Digital Ear Thermometer 424 Digital Ear Thermometer Instruction Manual PLEASE NOTE: THIS MEDICAL INSTRUMENT MUST BE USED ACCORDING TO INSTRUCTIONS TO ENSURE ACCURATE READINGS. Questions? Call ADC toll free at 1-800-232-2670...
-
Page 2: Table Of Contents
Adtemp 424 Digital Ear Thermometer 1. Introduction ..........3 2. -
Page 3: Introduction
Now, you too can enjoy the benefits of ADC ® engineering and quality in the home. This feature rich instrument was designed to simplify use and deliver consistent, dependable results. -
Page 4: Important Safety Instructions
Always use the thermometer with a new undamaged Probe Cover for each meas- urement to prevent infection. Readings taken without probe covers will not be accurate. Only ADC ® brand probe covers can ensure that you get an accu- rate measurement from the 424 Digital Ear Thermometer. -
Page 5: Product Description
(7) Probe Cover Applicator Hole 4. How to Measure Body Temperature The ADC ® 424 Digital Ear Thermometer measures the heat radiated from the eardrum and the surrounding tissue. This energy is collected through the lens and converted to a temperature value. -
Page 6: How To Read The Display
To avoid an inaccurate measurement: Use ONLY ADC ® probe covers, as this unit is calibrated to work with probe covers. Straighten the ear canal by gently pulling the middle of the ear back and up. This ensures measurement of heat from the eardrum. (Please note: Pull outer ear out for newborns - age 1) Place the probe firmly into the ear canal. -
Page 7: How To Apply A New Probe Cover
(4) After feeling a slight click, take out the cover holder hole. Push firmly. probe. The cover should be securely attached. Please Note: Unit is calibrated to work with probe covers. Only use of ADC ® probe covers ensures accuracy and hygienic use. -
Page 8: Directions For Use
7. Directions for Use Important: Prior to every measurement, fit a new un- damaged Probe Cover on the measuring probe. Failure to do so may result in incorrect temperature readings. Press the ON/OFF button. The display is activated to show all symbols for 2 seconds. -
Page 9: Changing From Fahrenheit To Celsius
If you are not confident with readings obtained, confirm temperature with a standard digital thermometer. 8. Changing from Fahrenheit to Celsius and vice-versa The ADC ® Digital 424 Thermometer can display temperature measurements in either Fahrenheit or Celsius. To switch the display between °F and °C, turn the unit off. Press and hold the Start buttonfor 5 seconds, the display will show ---°C or ---°F. -
Page 10: Error Messages
9. Error Messages Possible Cause & Display Problem Display Meaning Remedy Measured temperature higher Measured Temperature too than 108.0 °F or 42.2 °C. high *Caution! Measured temperature lower than 32 Measured Temperature °C or 89.6 °F. See section 7 for too low proper technique. -
Page 11: Cleaning And Storage
Please Note: Ear wax or dirt on the lens will result in aninaccurate read- ing. Clean the lens as indicated above. 11. Replacing the Battery The ADC ® Digital 424 Ear Thermometer is supplied with one lithium battery, type CR2032. -
Page 12: Warranty
12. Warranty This product was manufactured with the utmost care according to international quality standards. This product is warranteed for 2 years against manufacturing defects. Claims beyond this, including claims for damages, are excluded. The warranty covers the instrument and the batteries. The packaging is not included. - Page 13 Memory: Automatically displays the last measured temperature. Illuminated Display: a. The display will be lighted for 4 seconds when (Back-Lite) the unit is turned ON. b. The display will be lighted again for 5 seconds when the measurement has been completed. Operating Temperature: 10°C to 40 °C (50.0 °F to 104 °F)
-
Page 14: Contact Information
1 800 232 2670 American Diagnostic Corporation 55 Commerce Drive, Hauppauge, New York 11788 Telephone: 631-273-9600 • Fax: 631-273-9659 Email: info@adctoday.com Dist. by: ADC ® Hauppauge, NY 11788 Inspected in the USA Onbo Electronic (Shenzhen) Co., Ltd. Made in China No.
