Summary of Contents for UTC RETAIL 2250
- Page 1 2200 Series POS System 2250 / 2270 Installation Guide Thank you for selecting UTC RETAIL’s innovative 2200 Series Point of Sale solution! This guide is designed to help you efficiently assemble the 2200 Series POS System. © 2008 UTC RETAIL. All rights reserved.
-
Page 2: Series Pos System Installation Guide
If a unit needs to be shipped to UTC RETAIL for repairs, please return it in the original packaging material and shipping container. If you purchased the 2200 Series POS System through a dealer, and the dealer is unable to answer your questions, please call UTC RETAIL’s Technical Support at... -
Page 3: Table Of Contents
Install the UTC RETAIL PD1200 Pole Display................6 Connect the A/C Power Cord ....................6 Install the Printer (Epson H6000 Printer shown)...............6 Install the Keyboard (UTC RETAIL M700 Keyboard shown) ............7 Connect Cables to 2200 Series POS Logic Unit Ports .............7 Complete Installation of 2200 Series POS System..............7 Troubleshooting Procedures.....................8... -
Page 4: Product Information
The 2200 Series POS System supports many different printers, such as the Epson H6000 or TMT88. • The 2200 Series POS System supports the UTC RETAIL 15” or 17” flat panel LCD display. The display is available with touch screen options. © 2008 UTC RETAIL. All rights reserved. -
Page 5: Open The Point Of Sale Unit System Box
Open the point of sale box and remove the unit. Remove all packing materials. Unit Orientation: The 2250/2270 unit must be orientated with its rubber feet down. Do not mount the unit on its side. Consideration should be taken to ensure that none of the unit vents are blocked. -
Page 6: Install The Utc Retail Pd1200 Pole Display
Install the UTC RETAIL PD1200 Pole Display Open the pole display box and remove the pole display. Remove all packing materials. Take the pole assembly and insert it into the hat bracket. Route the pole display cable through the two right-hand cable clamps. -
Page 7: Connect Cables To 2200 Series Pos Logic Unit Ports
Note: The green LED above the ATX push-button switch begins to glow when the logic module is activated. You have completed the installation of UTC RETAIL’s 2200 Series Point of Sale System. If you experience problems with any of the components of the 2200 Series POS System, see the “Troubleshooting Procedures”... -
Page 8: Troubleshooting Procedures
COM port 1. If there is no +5 on pin 9 of this port. Use COM port 2-6. Please call UTC RETAIL’s Technical Support at 800.349.0546, if you have any problems not addressed in the Troubleshooting Procedures or have questions about other sections of this documentation.
