UTC RETAIL 2250 User Manual

2200 series pos system
Hide thumbs Also See for 2250:

Advertisement

Quick Links

Download this manual See also: Installation Manual
2200 Series POS System
2250 / 2270 User Guide
Thank you for selecting UTC RETAIL's innovative 2200 Series Point of Sale solution!
This guide is designed to acquaint you with the features and functionality of the 2200 Series
Point of Sale System.
© 2008 UTC RETAIL. All rights reserved.
11501021 Rev C

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for UTC RETAIL 2250

Summary of Contents for UTC RETAIL 2250

  • Page 1 2200 Series POS System 2250 / 2270 User Guide Thank you for selecting UTC RETAIL’s innovative 2200 Series Point of Sale solution! This guide is designed to acquaint you with the features and functionality of the 2200 Series Point of Sale System.

  • Page 2: 2200 Series Pos System User Guide

    If a unit needs to be shipped to UTC RETAIL for repairs, please return it in the original packaging material and shipping container. If you purchased the 2200 Series POS System through a dealer, and the dealer is unable to answer your questions, please call UTC RETAIL Technical Support at 1.800.349.0546.

  • Page 3: Table Of Contents

    Table of Contents 2200 Series POS System User Guide..................2 Table of Contents........................3 Product Information........................4 System Access .........................10 Hard Drive Removal........................11 Integration Tray Installation Guide.....................12 System Installation Guide ......................12 © 2008 UTC RETAIL. 11501021 Rev C All rights reserved.

  • Page 4: Product Information

    The 2200 Series POS System supports many different printers, such as the Epson H6000 or TMT88. • The 2200 Series POS System supports the UTC RETAIL 5” or 17” flat panel LCD display. The display is available with touch screen options. 11501021 Rev C ©...
  • Page 5 Operating Systems Linux® Linux® Device Drivers JavaPOS™, OPOS JavaPOS™, OPOS RS-232 2 (up to 7) 2 (up to 7) USB Interface Ports 4 (up to 10) 6 (up to 12) © 2008 UTC RETAIL. 11501021 Rev C All rights reserved.
  • Page 6 The ports located on the motherboard are defined as follows: o PS2 Keyboard o PS2 Mouse o DB9 serial COM1 o Audio o Parallel o SVGA o 10/100 LAN o USB 11501021 Rev C © 2008 UTC RETAIL. All rights reserved.
  • Page 7 An additional configurable USB port is located at the front of the unit. The front USB port maybe be configured to be exposed or not. An optional DVD is located at the front of the unit. Back Panel View 2250 2270 Front Panel View © 2008 UTC RETAIL. 11501021 Rev C All rights reserved.
  • Page 8 JP3: Select 5V/12V when the setting is VOLTAGE output. COM Port Jumper Settings (COM3 through COM6) Voltages are selectable via labeled jumpers on the boards. Removing the jumper applies no power to pin 9. 11501021 Rev C © 2008 UTC RETAIL. All rights reserved.

  • Page 9: Power Requirements

    PCI Slot Support Options The PCI slots support three standard low-profile PCI cards and one PCI express card. Depending on the configuration purchased, expansion cards may already be installed in these slots. © 2008 UTC RETAIL. 11501021 Rev C All rights reserved.

  • Page 10: System Access

    Unscrew the thumb screw from the back panel of the unit. Slide off the cover. Option Two - Lock 1. Unlock the cover of the unit from the back panel. 2. Remove the thumb screw. 3. Slide off the cover 11501021 Rev C © 2008 UTC RETAIL. All rights reserved.

  • Page 11: Hard Drive Removal

    Remove cover as outlined in the system access section. Disconnect the cabling. Remove the hard-drive thumbscrew. Remove hard-drive bracket from the unit. Remove the hard drive mounting screws. Replace hard-drive. Reconnect the cabling. © 2008 UTC RETAIL. 11501021 Rev C All rights reserved.

  • Page 12: Integration Tray Installation Guide

    RETAIL’s website at www.utcretail.com Cable Cover Installation Guide The Cable Cover Installation Guide may be downloaded from the UTC RETAIL’s website at www.utcretail.com Please call UTC RETAIL’s Technical Support at 800.349.0546, if you have any problems not addressed in the Troubleshooting Procedures or have questions about other sections of this documentation.
