UTC RETAIL 3100 Series Nstallation Manual

Touch screen pos workstation

Hide thumbs Also See for 3100 Series:

See also: User Manual , Installation Manual

INSTALLATION GUIDE: MAGNETIC STRIPE READER (MSR)

Congratulations on your purchase of UTC RETAIL's

innovative 3100 Series Touch Screen POS Workstation with its

Magnetic Stripe Reader (MSR). The 3100 Series MSR installs

quickly and easily on the side of the main workstation unit.

This Installation Guide was prepared by UTC RETAIL for use

by technical experts who assemble POS systems using 3100

Series products.

This document may not be used for any purpose other than its

intended use. This document must be downloaded in its

entirety; it may not be reproduced, stored or transmitted in part

without the prior written permission of UTC RETAIL. All

attempts have been made to ensure that the information

presented in this document is correct. No liability, expressed or

implied, will be assumed by UTC RETAIL, its dealers, or

affiliates, for damage resulting from the use of this information.

Safety Precautions for Installation

WARNING: Access to Internal Components

All access to internal components of the 3100 Series unit is restricted to Authorized Service Personnel only. Opening

the case or service by anyone else will automatically void the warranty on this product.

CAUTION

Damage to the logic module components may occur if AC power is not removed from the product prior to attaching

any accessories.

CAUTION

Once installed, DO NOT use the MSR as a carrying handle when moving the 3100 Series from location to location.

3100 Series™ is a registered trademark of UTC RETAIL

Touch Screen POS Workstation

3100 Series

11680012 Rev A

Table of Contents

Do you have a question about the 3100 Series and is the answer not in the manual?

Page 1 Damage to the logic module components may occur if AC power is not removed from the product prior to attaching any accessories. CAUTION Once installed, DO NOT use the MSR as a carrying handle when moving the 3100 Series from location to location. 3100 Series™ is a registered trademark of UTC RETAIL 11680012 Rev A...
Page 2 1. Prepare the Machine If Windows is running, shut it down as you would shutdown a PC. When the 3100 Series is off, unplug the power cord. Rotate the unit 90° clockwise so its left side is facing you. Lay the 3100 Series Workstation face down on a soft surface, being careful not to scratch the LCD monitor or its bezel.
Page 3 MSR can be downloaded from the UTC RETAIL website at www.utcretail.com. Look for “Drivers and Support” under the Hardware Solutions tab. The drivers and test software are also on the 3100 Series hard drive in the Drivers folder within the My Documents folder.
Page 4 Assistance and customer service are available from your dealer or authorized service provider. If your dealer or service provider cannot answer your questions or provide satisfactory service, call UTC RETAIL Technical Support. When calling for assistance or service information, please be ready to provide the model number and serial number of the Magnetic Stripe Reader. This information is found on a sticker located on the inside of the MSR device by its USB cable.
