1. Optidrive Eco Parameter Set Overview

1.1. About this section

This document provides a list of the available parameters, and a description of their respective functions, for the Optidrive Eco.

1.2. Parameter Structure Overview

The parameter set is arranged in Groups according to the following structure
Parameter Group Range
Group 0 P0-01 to P0-50
P0-51 to P0-80
Group 1 P1-01 to P1-14
Group 2 P2-01 to P2-40
Group 3 P3-01 to P3-18
Group 4 P4-01 to P4-14
Group 5 P5-01 to P5-15
Group 6 P6-01 to P6-30
Group 7 P7-01 to P7-19
Group 8 P8-01 to P8-20
Group 9 P9-01 to P9-44
Access to all parameter groups is controlled by setting P1-14 as follows
P1-14 = P2-40 (Factory setting: 101) Allows Extended Parameter Access
P1-14 = P6-30 (Factory Setting: 201) Allows Advanced Parameter Access
Name
Basic Monitoring
Advanced Monitoring
Quick Start Menu
Extended Parameters
PID Controller
Motor Control
Communications
Advanced Functions
Advanced Motor Data
Application Specific Group
Programmable Logic
Access Level Access Type
Extended Read Only
Advanced Read Only
Basic Read / Write
Extended Read / Write
Extended Read / Write
Extended Read / Write
Extended Read / Write
Advanced Read / Write
Advanced Read / Write
Advanced Read / Write
Advanced Read / Write
