7.3 Acyclic Operation

This section provides information on objects, instances,
and attributes for acyclic operation. It also lists the
requirements related to acyclic services for the EtherNet/IP
Module.

7.3.1 Class 0X01 Identity Object

The EtherNet/IP Module supports the attributes for identity
objects listed in Table 7.8.
Attribute Function Description
1 Vendor Supported
2 Device type The attribute value is 12d
3 Product code Supported
4 Revision: Major, Revision value set in the EDS file
minor
5 Status Status of the netIC module
6 Serial number Serial number of the netIC
module
7 Product name Supported
Table 7.8 Identity Object Attributes

7.3.2 Vendor-specific Objects

The EtherNet/IP Module supports vendor-specific class
objects 100, 101, 103, and 104.

7.3.2.1 Class 100 Objects (Read/Write)

Object name
Motor full load current
Locked rotor time
Start mode
Current limit
Initial current
Start ramp time
Kickstart level
Kickstart time
Excess start time
Stop mode
Stop time
Adaptive control gain
Adaptive start profile
Adaptive stop profile
Brake torque
Brake time
Phase sequence
Current imbalance
Current imbalance delay
Undercurrent
Undercurrent delay
MG17Q102
Installation Guide
Class Instance Attribute
100 101 100
100 102 100
100 103 100
100 104 100
100 105 100
100 106 100
100 107 100
100 108 100
100 109 100
100 110 100
100 111 100
100 112 100
100 113 100
100 114 100
100 115 100
100 116 100
100 117 100
100 118 100
100 119 100
100 120 100
100 121 100
Danfoss A/S © 05/2017 All rights reserved.
Object name
Instantaneous overcurrent
Instantaneous overcurrent delay
Frequency check
Frequency variation
Frequency delay
Restart delay
Motor temperature check
Local/remote
Comms in remote
Input A function
Input A name
Input A trip
Input A trip delay
Input A initial delay
Remote reset logic
Relay A function
Relay A on delay
Relay A off delay
Relay B function
Relay B on delay
Relay B off delay
Relay C function
Relay C on delay
Relay C off delay
Low current flag
High current flag
Motor temperature flag
Analog output A
Analog A scale
Analog A maximum adjustment
Analog A minimum adjustment
Auto-start type
Auto-start time
Auto-stop type
Auto-stop time
Auto-reset action
Maximum resets
Reset delay groups A&B
Reset delay group C
Motor FLC-2
Locked rotor time-2
Start mode-2
Current limit-2
Initial current-2
Start ramp-2
Kickstart level-2
Kickstart time-2
Excess start time-2
Stop mode-2
Stop time-2
Adaptive control gain-2
Adaptive start profile-2
Adaptive stop profile-2
Class Instance Attribute
100 122 100
100 123 100
100 124 100
100 125 100
100 126 100
100 127 100
100 128 100
100 129 100
100 130 100
100 131 100
100 132 100
100 133 100
100 134 100
100 135 100
100 136 100
100 137 100
100 138 100
100 139 100
100 140 100
100 141 100
100 142 100
100 143 100
100 144 100
100 145 100
100 146 100
100 147 100
100 148 100
100 149 100
100 150 100
100 151 100
100 152 100
100 153 100
100 154 100
100 155 100
100 156 100
100 157 100
100 158 100
100 159 100
100 160 100
100 161 100
100 162 100
100 163 100
100 164 100
100 165 100
100 166 100
100 167 100
100 168 100
100 169 100
100 170 100
100 171 100
100 172 100
100 173 100
100 174 100
