Evaluation Board for the AD7176-2—24-Bit, 250 kSPS Sigma-Delta ADC with

FEATURES

Full featured evaluation board for the
PC control in conjunction with the system demonstration
platform (EVAL-SDP-CB1Z)
PC software for control and data analysis (time domain)
Standalone capability

ONLINE RESOURCES

Evaluation Kit Contents
EVAL-AD7176-2SDZ
evaluation board
Evaluation software CD for the
Documents Needed
AD7176-2
data sheet
UG-478
user guide
Required Software
EVAL-AD7176-2SDZ
evaluation software

EQUIPMENT NEEDED

EVAL-AD7176-2SDZ
evaluation board
EVAL-SDP-CB1Z
system demonstration platform
External 7 V to 9 V power supply
DC signal source
USB cable
PC running Windows with USB 2.0 port
ADA4940-1
AD8656
ON-BOARD
NOISE TEST
AIN0
AIN1
AIN2
AIN3
AIN4
TO AD7175-2
REFOUT PIN
AD8656
AD8475
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
20 μs Settling
AD7176-2
AD7176-2

FUNCTIONAL BLOCK DIAGRAM

7V TO 9V
VIN
ADP1720
ADR445
5V LDO
5V VREF
1.8V
CROSSPOINT
LDO
MULTIPLEXER
ADC
XTAL AND INTERNAL
I/O
CLOCK OSCILLATOR
CONTROL
AVSS
GPIO0 GPIO1
Figure 1.
EVAL-AD7176-2SDZ
Rev. 0 | Page 1 of 40
Evaluation Board User Guide

GENERAL DESCRIPTION

The
EVAL-AD7176-2SDZ
24-bit, 250 kSPS analog-to-digital converter (ADC). A 7 V to
9 V external bench top supply is regulated to 5 V and 3.3 V to
supply the
AD7176-2
The
EVAL-AD7176-2SDZ
the PC by connection to the
The
EVAL-AD7176-2SDZ
AD7176-2
device register functionality and provides dc time
domain analysis in the form of waveform graphs, histograms,
and associated noise analysis for ADC performance evaluation.
The
EVAL-AD7176-2SDZ
designed to allow the user to evaluate the features of the ADC.
The user PC software executable controls the
the USB through the system demonstration platform board
(EVAL-SDP-CB1Z).
ADP1720
3.3V LDO
1.8V
PRECISION
LDO
REFERENCE
INT
REF
CS
SCLK
DIN
DIGITAL
FILTER
DOUT/RDY
SYNC/ERROR
CIRCUITRY
AD7176-2
XTAL1 CLKIO/XTAL2
DGND
Block Diagram
evaluation kit features the
and support all necessary components.
board connects to the USB port of
EVAL-SDP-CB1Z
motherboard.
software fully configures the
is an evaluation board that is
AD7176-2
ADP7104
5V LDO
USB
ADSP-BF527
POWER
SDP-B
LED
STATUS
UG-478
AD7176-2
over
