RealPresence
Cable No. Description QTY From
C.1 Left speaker audio 1 abox
C.2 Left speaker power 1 abox
C.3 Right speaker audio 1 abox
C.4 Right speaker power 1 abox
C.5 abox to screen video 1 abox
C.6 abox to screen power 1 abox (R)
C.7 Mains input cable (US) 1 Plug (US)
C.8 Network input cable 1 wall
RealPresence Medialign 155 Codec And Bracket Set
Cable No. Description QTY From
C.9 codec content in 1 abox
C.10 codec audio in 1 abox
C.11 codec audio out 1 codec
C.12 codec network 1 abox
C.13 codec control 1 abox
C.14 screen input 1 codec (1)
C.15 codec power 1 abox (right) PSU (right side) IEC C13
C.16 Producer Power 1 abox (left) PSU (left side)
RealPresence Medialign interface-s Cable Set
Cable No. Description QTY From
IN.1 Interface-s to abox 1 interface-s
IN.2 HDMI Input 1 interface-s
IN.3 VGA Input 1 interface-s
IN.4 Audio Input 1 interface-s
Medialign 155 Core Cable Kit
® ™
Connectors
To
From Color To
Left Speaker XLR-5pin Black XLR-3pin
Left Speaker C7 Black C8
Right Speaker XLR-5pin Black XLR-3pin
Right Speaker C7 Black C8
screen HDMI Purple HDMI
screen M12 Yellow M12
abox US Plug Black IEC
abox RJ45 Black RJ45
Connectors
To
From Color To
codec HDMI Green HDMI
codec 3.5mm Green 3.5mm
abox 3.5mm Blue 3.5mm
codec RJ45 Blue RJ45
codec D9 Red DIN
Screen HDMI Blue DVI
Black IEC C14
IEC C13 Black IEC C14
Connectors
To
From Color To
abox DVI-I Black DVI-I
User Laptop HDMI Black HDMI
User Laptop VGA Black VGA
User Laptop 3.mm Jack Black 3.mm Jack
Length
Part Number
m
Color
Black 1.00 ABC-506-040738-8274
Black 0.90 ABC-506-027694-8494
Black 1.80 ABC-506-040738-8304
Black 1.80 ABC-506-040738-8311
Brown 1.5 ABC-506-032414-8616
Yellow 1.65 ABC-506-027694-8197
Black 3.00 ABC-506-046660-0928
Black 3.00 ABC-506-027694-9569
Length
Part Number
Color m
Green 1.10 ABC-506-040738-8342
Green 1.05 ABC-506-040738-8366
Blue 1.05 ABC-506-040738-8380
Blue 0.90 ABC-506-040738-8403
Red 0.90 ABC-506-040738-8427
Green 1.30 ABC-506-040738-8441
Black 1.00 ABC-506-040738-8472
Black 1.50 ABC-506-040738-8373
Length
Part Number
Color m
Black 5.00 ABC-506-027694-8265
Black 1.00 ABC-506-027694-8715
Black 1.00 ABC-506-046660-0782
Black 1.00 ABC-506-032414-8630
