PROFIBUS-DP Interface Module
Type AJ71PB92D/A1SJ71PB92D
,
User
s Manual
Mitsubishi Programmable Logic Controller

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi A1SJ71PB92D

Summary of Contents for Mitsubishi A1SJ71PB92D

  • Page 1 PROFIBUS-DP Interface Module Type AJ71PB92D/A1SJ71PB92D User s Manual Mitsubishi Programmable Logic Controller...

  • Page 3: Safety Precautions

    When using Mitsubishi equipment, thoroughly read this manual and the associated manuals introduced in this manual. Also pay careful attention to safety and handle the module properly. These precautions apply only to Mitsubishi equipment. Refer to the CPU module user’s manual for a description of the PLC system safety precautions.

  • Page 4: Installation Precautions

    [INSTALLATION PRECAUTIONS] CAUTION Use the module in the environment given in the general specifications of the CPU module’s User’s Manual. Using the module outside the range of the general specifications may result in electric shock, fire or malfunctioning, or may damage or degrade the module. Insert the tabs at the bottom of the module into the mounting holes in the base unit before installing the module.

  • Page 5: Operating Precautions

    CAUTION Never disassemble or modify the module. This may cause breakdowns, malfunctioning, injury and/or fire. Switch all phases of the external power supply off before mounting or removing the module. If you do not switch off the external power supply, it will cause breakdowns or malfunction of the module. Set the ON/OFF select switch of the terminal resistor before the operation.
  • Page 6 Japanese Manual Version SH-3330-G This manual does not imply guarantee or implementation right for industrial ownership or implementation of other rights. Mitsubishi Electric Corporation is not responsible for industrial ownership problems caused by use of the contents of this manual.

  • Page 7: Table Of Contents

    Introduction Thank you for purchasing the Mitsubishi Programmable Controller MELSEC-A Series. Before using the equipment, plese read this manual carefully to develop full familiarity with the functions and performance of the graphic operation terminal you have purchased, so as to ensure correct use.
  • Page 8 Appendix 1 Differences between AJ71PB92D/A1SJ71PB92D Software Versions ..........A- 1 Appendix 1.1 Differences between A1SJ71PB92D Software Versions............A- 1 Appendix 1.2 Restrictions on Use of A1SJ71PB92D Software Versions in the Same System ....... A- 2 Appendix 1.3 Differences between AJ71PB92D Software Versions ............... A- 2 Appendix 1.4 Restrictions on Use of AJ71PB92D Software Versions in the Same System ......

  • Page 9: About This Manual

    Manual Name Article No. MELSEC ProfiMap Configuration System for Open Networks Software Manual 65778-B * Inquiries can be made to : MITSUBISHI ELECTRIC EUROPE Factory Automation Gothaer Strasse 8 D-40880 Ratingen Germany Phone : +49(21 02)486-0 Fax : +49(21 02)486-717...

  • Page 10: Overview

    FMA1/2 Layer 1 Physical layer The AJ71PB92D/A1SJ71PB92D has a physical layer, data link layer, DDLM, and user interface that conform to PROFIBUS-DP, and communicates data with the PLC CPU by using a buffer memory. The main application of PROFIBUS-DP is networks that execute high-speed communication at the level of sensors and actuators, and the AJ71PB92D/A1SJ71PB92D has been designed with this in mind: its functions are mainly related to data I/O with slave stations.

  • Page 11: Aj71Pb92D/A1Sj71Pb92D Features

    (3) Supports 3M, 6M, 12M [bps] network communication speeds in addition to the 9.6k, 19.2k, 93.75k, 187.5k, 500k, and 1.5M [bps] supported by the AJ71PB92D/A1SJ71PB92D. These can be selected using a configurator. (4) Station Nos. from 0 to 125 can be set using the configurator.

  • Page 12: System Configuration

    2. SYSTEM CONFIGURATION MELSEC-A 2. SYSTEM CONFIGURATION This section explains system configuration for the AJ71PB92D/A1SJ71PB92D Whole System Configuration (1) For the A1SJCPU A1SJCPU (S3) A1SJ71PB92D A1SJHCPU Extension cable A1SC[ ]B Extension base unit A1S6[ ]B(S1)/A1S5[ ]B(S1) (2) For the compact building block type CPU...

  • Page 13: System Configuration Example

    System Configuration Example The following describes the A1SJ71PB92D system configuration example. A communication parameter file is created in Windows using the Configurator software package, this parameter file can then be down-loaded via an RS-232C cable to the AJ71PB92D/A1SJ71PB92D. Via RS-232C AJ71PB92D Personal computer supporting Windows 3.1 or 95...

  • Page 14: Applicable Cpu Modules

    2. SYSTEM CONFIGURATION MELSEC-A Applicable CPU Modules The following table shows the CPUs that the AJ71PB92D/A1SJ71PB92D can use. (1) AJ71PB92D Applicable CPU Modules A1SCPUC24-R2 A1SJHCPU, A1SHCPU, A2SHCPU, A2SHCPU-S1, A1NCPU, A1NCPUP21, A1NCPUP21-S3, A1NCPUR21, A2NCPU, A2NCPUP21, A2NCPUP21-S3, A2NCPUR21, A2NCPU-S1, A2NCPUP21-S1, A2NCPUP21-S4, A2NCPUR21,...

  • Page 15: Installable Base Units

    QA1S68B *1: The no power supply module extension base unit A1S5 [ ] B (S1) may not have sufficient power supply capacity, so use the A1S6 [ ] B (S1) when installing a AJ71PB92D/A1SJ71PB92D in the extension base unit. When the A1S5 [ ] B (S1) must be installed, do so after referring to the chapter covering power supplies in the respective CPU Module User’s Manual.

  • Page 16: Precautions For Configuring A System

    *1: The software version usable by the AJ71PB92D/A1SJ71PB92D is AJ71PB92D (A or later) or A1SJ71PB92D (E or later). When A1SJ71PB92D (software version D or earlier) is used, write is disabled and the max. data length is 32 bytes each for input and output.
  • Page 17 (5) Do not make simultaneous access to the AJ71PB92D/A1SJ71PB92D from multiple ProfiMap's. If such access is made, the AJ71PB92D/A1SJ71PB92D may not be accessed properly. (6) If remote parameter setting is performed from MELSEC ProfiMap to the AJ71PB92D/A1SJ71PB92D which is making data exchange, note that PROFIBUS data exchange will stop during parameter setting.

  • Page 18: Specifications

    3. SPECIFICATIONS MELSEC-A 3. SPECIFICATIONS This section explains the AJ71PB92D/A1SJ71PB92D the general specifications, performance specifications, and transmission specifications. General Specification This section explains the AJ71PB92D/A1SJ71PB92D general specifications. Table 3.1 General Specification Item Specification Usage environment ° 0 to 55 temperature Storage environment °...

  • Page 19: Performance Specifications

    5VDC Internal current consumption 0.54 A 0.56 A Noise durability, dielectric withstand voltage Depending on the AJ71PB92D/A1SJ71PB92D installation system power supply module insulation resistor specifications. (refer to the CPU Module User's Manual.) 250 mm (9.84 in.)(H) × 37.5 mm (1.48 in.)(W) 130 mm (5.12 in.)(H) ×...

  • Page 20: Network Configuration

    Communications can be conducted via a maximum of 3 repeaters from an arbitrary master or arbitrary slave to an arbitrary master or arbitrary slave (Not 3 units in the entire network). The maximum number of slaves that can be connected to 1 AJ71PB92D/A1SJ71PB92D is 60 stations.

  • Page 21: Applicable Configuration

    3. SPECIFICATIONS MELSEC-A 3.3.2 Applicable configuration When 1 master (class 1) station is connected Master (class 1) AJ71PB92D A1SJ71PB92D CPU mlodule Configurator Slave Slave Slave Station No. 1 Station No. 2 Station No. 31 *: A maximum of 32 stations can be connected to 1 segment.
  • Page 22 3. SPECIFICATIONS MELSEC-A When 1 master (class 1) station and 3 repeaters are connected Master (class 1) AJ71PB92D A1SJ71PB92D CPU module Configurator Repeater Slave Slave Slave Station No. 1 Station No. 2 Station No. 18 Repeater Slave Slave Station No. 19 Station No.
  • Page 23 3. SPECIFICATIONS MELSEC-A When 126 master (class 1) and slave stations are connected (When 60 or more slaves are connected) 2nd master 1st master (class 1) (class 1) 3rd master CPU module (class 1) Repeater Slave Slave Slave Slave Station No. 1 Station No.
  • Page 24 3. SPECIFICATIONS MELSEC-A Point In configurations that use multiple master stations (multimaster configuration), when reconnecting a cable after disconnecting a PROFIBUS cable for 1 master that is exchanging data at a low baud rate, the communications of the master for which the cable is not disconnected could stop and the slave output could be turned off.

  • Page 25: Number Of Connectable Slaves

    (b) Make setting on the slave station side to shorten the maximum data length of the error information. (If possible) (c) Using two or more AJ71PB92D/A1SJ71PB92D, reduce the number of slave stations per module. (2) Restrictions on parameter data length of slave station The parameter size which can be set in AJ71PB92D/A1SJ71PB92D should meet the following formula.
  • Page 26 3. SPECIFICATIONS MELSEC-A The number of parameter blocks for each station is decided by the parameter size of the station as follows. Parameter size of each Number of blocks of each slave station slave station 246 bytes or less 1 block 247 to 480 bytes 4 blocks 481 to 720 bytes...
  • Page 27 (example) When the system is constructed using only the stave stations with 520 bytes parameter, AJ71PB92D/A1SJ71PB92D can be connected up to the following number of the slave stations. When the parameter size is 520 bytes, the number of the parameter block is five.

  • Page 28: Functions

    PROFIBUS-DP network. The method used for this exchange is to read/write the I/O image in the buffer memory using FROM/TO instructions. A schematic drawing of this exchange function is as follows. AJ71PB92D/ A1SJ71PB92D (Class 1 master) CPU module Buffer memory Input...

  • Page 29: Global Control Functions

    The group No. of the group containing the slaves is set by the configurator. In the AJ71PB92D/A1SJ71PB92D the group can be arbitrary specified and the global control commands transmitted using multicast communication. This makes is possible to select a slave and conduct global control.
  • Page 30 4. FUNCTIONS MELSEC-A (2) Service FREEZE, UNFREEZE Master (FREEZE transmission to group 3) Input data FREEZE (Group 8) (Group 3) (Group 3) (Group 3) Slave 1 Slave 2 Slave n Slave 3 Input image memory: The data is always refreshed by polling. <during FREEZE cancel/default>The actual input is input to the input memory unchanged (normal condition) <during FREEZE execute>The actual input is input once into the input image memory at the FREEZE...
  • Page 31 4. FUNCTIONS MELSEC-A (4) Procedure for issuing a global service. Sequence AJ71PB92D program A1SJ71PB92D Slave TO global control area Turn on the global control request signal (Y04). Turn on the global control end signal (X04). Global control service Time...

  • Page 32: I/O Signal

    4. FUNCTIONS MELSEC-A I/O Signal 4.2.1 I/O signal list The I/O signal configuration used in the AJ71PB92D/A1SJ71PB92D and the data communications with the PLC CPU are described below. → → → → → → → → Signal direction: AJ71PB92D/A1SJ71PB92D PLC CPU...

  • Page 33: I/O Signal Detail Description

    (b) The exchange start end signal (X00) turns off in either of the following cases. • When the exchange start request signal (Y00) is turned off • When the parameters are written from the configurator to the AJ71PB92D/A1SJ71PB92D Maximum 200 ms...
  • Page 34 4. FUNCTIONS MELSEC-A (3) Communication trouble area clear request (Y02), communication trouble area clear end (X02) (a) The communication trouble area clear request (Y02) is turned on by the sequence program when all of the communication trouble areas and extension trouble areas are cleared. (b) The communication trouble clear end signal (X02) is turned on after all of the communication trouble area and extension trouble areas are cleared by turning on the communication trouble area clear request signal (Y02).
  • Page 35 Initial type (12) Restart request signal (Y0D) (a) When the AJ71PB92D/A1SJ71PB92D goes down for some reason (when the FAULT LED turns on and X1D is off) then turning Y0D from off to on to off again will make it possible to restart the AJ71PB92D/A1SJ71PB92D.

  • Page 36: Buffer Memory List

    This area indicates the operation mode of the AJ71PB92D/A1SJ71PB92D when it has started up. 2255/ 8CFh Operation mode change request area (Description) In this area, set the operation mode of the AJ71PB92D/A1SJ71PB92D which you want to choose. 2256/ 8D0h Operation mode change result area (Description) This area indicates the execution result of the operation mode change request.

  • Page 37: Buffer Memory Detailed Description

    The input data of the slave station, which was disabled from communication during normal communication and whose corresponding bit of the communication status area*1 turned ON (1), is not stored into the input area of the AJ71PB92D/A1SJ71PB92D. In the input area of the corresponding slave station, the data before communication failure is held.
  • Page 38 The input data of the slave station, which was disabled from communication during normal communication and whose corresponding bit of the communication status area*1 turned ON (1), is not stored into the input area of the AJ71PB92D/A1SJ71PB92D. In the input area of the corresponding slave station, the data before communication failure is held.
  • Page 39 4. FUNCTIONS MELSEC-A (2) OUTPUT area Either normal service mode or extended service mode can be selected via the mode switch on the main unit. (a) Normal service mode (MODE Switch : No. 0) This is the area that stores the output data to the slave station. This area is fixed to an allocation of 32 bytes (16 words) per station for a total of 60 stations worth.
  • Page 40 4. FUNCTIONS MELSEC-A (3) Address information area This area shows the station address, input byte length, and output byte length for each slave station. This allocation is set by the configurator. The station addresses for the 1st through the 60th stations are stored in the order of registration in the configurator. (Station addresses: 1 to 126, do not need to be sequential numbers.) The address information area configuration is shown below.
  • Page 41 (4) Example address information area, INPUT area, and OUTPUT area The AJ71PB92D/A1SJ71PB92D reads the slave station address and I/O byte length set by the parameter file which is set by the configurator and stores these in the buffer memory address information area.
  • Page 42 MELSEC-A (5) Communication trouble area When some kind of trouble occurs during communication the AJ71PB92D/A1SJ71PB92D stores the contents of the trouble in this area. Fixed type or ring type can be selected for this area by turning the communication trouble area type selection (Y03) on or off (refer to Section 4.2.2 (9)).
  • Page 43 Refer to the above Refer to errors 1300h, 1121h above. 1300h, 1121h errors. 2) Otherwise An unexpected error has occurred. For 2) Contact the nearest Mitsubishi Electric branch office or dealer. ×: Exchange stops after the error occurs. : Exchange continues. 4-16...
  • Page 44 4. FUNCTIONS MELSEC-A (c) When the trouble code = 0200h For a slave trouble information occurrence (error code = 0200h), the slave trouble information is stored in the detailed data. The communication trouble area configuration for this case is shown below. In addition, the expansion communication trouble information is stored in buffer memory 2096 to 2110 for only the latest trouble information of the error code = 0200h trouble information.
  • Page 45 4. FUNCTIONS MELSEC-A (6) Expansion communication trouble area This area shows the latest expansion trouble information for only one of the latest expansion trouble information in the error code 0200h error information stored in buffer memory K2040 to K2079 communication error area (Refer to Section 4.3.2 (5)). Expansion trouble information area Communication trouble area Address...
  • Page 46 4. FUNCTIONS MELSEC-A (b) Buffer memory K2097 Only bit 7 is valid. Other bit is fixed in 0. Bit 7 is turned on when the slave sends expansion trouble information that is 27 bytes or more. Bit position 0 fixed 0 fixed (c) Buffer memory K2098 to K2110 The following informations are stored in this area:...
  • Page 47 4. FUNCTIONS MELSEC-A 2) Identifier related trouble information For module type slave stations, this stores as bit information whether or not a module is outputting an error. The identifier related trouble information can be divided into header and trouble information. This area stores a 2 bit value that is the identifier related trouble information in the header, including the header (1 byte), and the device related trouble information for this area.
  • Page 48 4. FUNCTIONS MELSEC-A 3) Channel related trouble information When a module type slave station, this area stores the trouble information for each module that is outputting an error. This area does not have a header and stores this information at the end of the identifier related trouble information. Each channel trouble information consists of an identifier No., channel No., and error type of 3 bytes.
  • Page 49 4. FUNCTIONS MELSEC-A 4) Identifier No., channel No. The slave identifier No. and channel No. are discussed below. The identifier No. is the No. that is attached from the header of each slave module. Each module can have multiple channels. Refer to the each slave specifications regarding to the channel numbering method.
  • Page 50 4. FUNCTIONS MELSEC-A (7) Example expansion communication trouble area Buffer memory Expansion communication trouble information length (byte length) 2096/830h Header (length 4) 2098/832h Device : Vendor independent trouble information Header (length 4) Identifier Identifier Nos. 0 and 2 have trouble information. Identifier No.0 and Channel channel No.
  • Page 51 4. FUNCTIONS MELSEC-A (8) Slave trouble information cancel area This stores the value that masks the slave trouble information (error code = 0200h detailed data 2). Even if the slave trouble information corresponding to this area bit occurs the slave trouble information detection signal (X01) and RSP ERR.
  • Page 52 4. FUNCTIONS MELSEC-A (9) Global control area The buffer memory (2081/821h) value and corresponding command table are shown below. Value Command Description position (valid/invalid) 8 to 15 Group 1 to 8 selection Bits 8 to 15 correspond respectively to groups 1 to 8 and shows that the bit value is transmitted by the global control command to the 1 group (refer below).
  • Page 53 4. FUNCTIONS MELSEC-A (10) Trouble no information time setting area Set the time at seconds unit, which does not inform the communication trouble after the exchange start. Default value is 20 seconds so the communication trouble is not informed for 20 seconds after the exchange start.
  • Page 54 4. FUNCTIONS MELSEC-A (12) I/O start address area (Extended service mode only) This area stores the start addresses of I/O areas for each slave station. • This area is used while in the extended Address service mode (MODE switch: No. E) only. 2128 Input start address for 1st station When in the normal service mode (MODE...
  • Page 55 4. FUNCTIONS MELSEC-A (13) Current operation mode This area stores the value which indicates the operation mode of the AJ71PB92D/A1SJ71PB92D when it has started up. Value Description The module started up in the normal service mode which was temporarily 0000h selected from the CPU module.
  • Page 56 MELSEC-A (14) Operation mode change request area You can change the operation mode of the AJ71PB92D/A1SJ71PB92D by writing the required operation mode to this area and turning on the operation mode change request signal Y11. You can also specify whether that setting is registered onto E PROM or not.

  • Page 57: While-Run Operation Mode Changing Function

    MELSEC-A 4.4 While-Run Operation Mode Changing Function This function enables the operation mode of the AJ71PB92D/A1SJ71PB92D to be changed using the I/O signals X/Y and buffer memory, without resetting the CPU module. The following I/O signals and buffer memory are used.

  • Page 58: Aj71Pb92D/A1Sj71Pb92D's Remote Parameter Setting Function Using Melsec Profimap Configuration Software

    4.5 AJ71PB92D/A1SJ71PB92D's Remote Parameter Setting Function Using MELSEC ProfiMap Configuration Software When the AJ71PB92D/A1SJ71PB92D and MELSEC ProfiMap (Ver. 3.0 or later) are used together, MELSEC ProfiMap enables remote parameter setting via the RS-422/RS-232 connector of the CPU module and via the MELSECNET/10.

  • Page 59: E 2 Prom Initialization Function

    PROM initialization function This function clears the parameters stored in the E2PROM of the AJ71PB92D/A1SJ71PB92D. When the LED of the AJ71PB92D/A1SJ71PB92D indicates an error (FAULT LED: on, RSP ERR. LED: off), initialize the parameters with this function. Re-set the AJ71PB92D/A1SJ71PB92D parameters after executing this function.

  • Page 60: Procedures Before System Operation

    5. PROCEDURES BEFORE SYSTEM OPERATION MELSEC-A 5. PROCEDURES BEFORE SYSTEM OPERATION Procedures before Operation The procedure for newly connecting AJ71PB92D/A1SJ71PB92D to an existing PROFIBUS-FMS network is explained below. Start Set the CPU module to STOP. Start the self-diagnosis of the AJ71PB92D/ Refer to Section 5.4.

  • Page 61: Parameter Setting Procedure

    5. PROCEDURES BEFORE SYSTEM OPERATION MELSEC-A 5.1.1 Parameter setting procedure The procedure for setting the AJ71PB92D/A1SJ71PB92D parameters is described below. Product available AJ71PB92D Write ProfiMap editor A1SJ71PB92D (RS232C) DDB file (text) Max ST delay resp (Max Tsdr), Quiet Time (Tqui), Setup Time (Tset) in the parameter to be set by the configurator ProfiMap must be match the maximum value connected to the network, including master station.

  • Page 62: Handling Precautions

    A failure to do so can cause the module to fail or malfunction. (1) The AJ71PB92D/A1SJ71PB92D’s case is made of resin, so be careful not to drop it or strike it hard. (2) The module fixing screw (M4) fastening torque should be tighten within the range of...

  • Page 63: Part Names And Settings

    Description Remark Displays the AJ71PB92D/A1SJ71PB92D status. Name Display description Displays the AJ71PB92D/A1SJ71PB92D operation status. ON: During normal operation OFF: When there is an error SD/RD Flashing during communication with the slave station on the PROFIBUS network. The flashing interval is the one set to Data control time of the Master Parameter.
  • Page 64 5. PROCEDURES BEFORE SYSTEM OPERATION MELSEC-A Name Description Remark Mode setting switch This sets the AJ71PB92D/A1SJ71PB92D operation status. (at time of shipment: 0) Switch No. MODE ONLINE 1 (Normal service mode) (refer to Section 4.3.2(1), (2)) Parameter setting mode Self-diagnosis mode (refer to section 5.4) ...

  • Page 65: Execution Method For Self-Diagnosis

    5. PROCEDURES BEFORE SYSTEM OPERATION MELSEC-A Execution Method for Self-diagnosis This section covers the procedure for entering the self-diagnosis mode and the LED displays descriptions. A self-diagnosis is automatically performed by setting the rotary switch to 2 and starting up (using the power supply on or reset switch).

  • Page 66: Wiring

    Disconnects terminal resistor (setting at time of shipment) (2) When the AJ71PB92D/A1SJ71PB92D's bus termination switch is set to on (has terminal resistor), do not remove the PROFIBUS cable from the AJ71PB92D/A1SJ71PB92D during PROFIBUS-DP network operation. If the cable is removed, then the terminal resistor in the...

  • Page 67: Precautions Against Wiring

    Precautions against external wiring of AJ71PB92D/A1SJ71PB92D is described below. (1) Do not route the wire of AJ71PB92D/A1SJ71PB92D close to or bundle it together with the main circuit and high-tension lines, or the load-carrying lines from other than the PLC.
  • Page 68 5. PROCEDURES BEFORE SYSTEM OPERATION MELSEC-A (3) Grounding (a) When using the AJ71PB92D/A1SJ71PB92D, ground the FG and LG terminals of the power supply module of the PLC. (b) If communication cannot be performed after grounding because of abnormal voltage applied to the FG terminal, the module may be used without grounding.

  • Page 69: Maintenance And Inspection

    MELSEC-A Maintenance and Inspection For the AJ71PB92D/A1SJ71PB92D, eliminate the check of cable connection and looseness and do not include it as an inspection item. Otherwise, follow the inspection item instructions in the PLC CPU User’s Manual to always use the system in good condition.

  • Page 70: Communication Time

    An explanation of the transmission delay time when there is one master station is given in the following diagram. The following diagram (Fig. 6.1) shows an example for when there are 3 slave stations. Time CPU module TO instruction FROM instruction AJ71PB92D/ A1SJ71PB92D Buffer memory AJ71PB92D/ A1SJ71PB92D Internal buffer Slave1 Slave2 Slave3...
  • Page 71 [s] = (Request/response processing time [T of master station (AJ71PB92D/A1SJ71PB92D)) *4 / (transmission speed[bps]) *4: Tsdi value described in the GSD (DDB) file of the AJ71PB92D/A1SJ71PB92D. The Tsdi value varies as described below depending on the transmission speed. Refer to *3 for the unit [T Transmission speed [bps] 9.6k...
  • Page 72 + 0.081 = 0.247 = 0.247 = 0.276 (c) Tsdi [s] value Request/response processing time [T ] of master station (AJ71PB92D/A1SJ71PB92D) Tsdi [s] = 150 / (1.5 ) = 0.1 (d) Lr[s] value Lr[s] = 1.2 + (3 ) = 1.20...
  • Page 73 6. COMMUNICATION TIME MELSEC-A Bc[s] = Max (MSI, + Tsdi ) + Lr + From/To_time) i =1 = Max (2.0 , 8.87 = 8.87...

  • Page 74: Transmission Delay Time When There Are Multiple Master Stations

    6. COMMUNICATION TIME MELSEC-A Transmission Delay Time When There are Multiple Master Stations The follow explains the transmission delay time when multiple master stations are connected to the same network. The following diagram (Fig. 6.2) shows the example where two master stations are connected to the same network.

  • Page 75: Ddb File

    7. DDB FILE The DDB file for the AJ71PB92D/A1SJ71PB92D is required to create the communication parameter for the AJ71PB92D/A1SJ71PB92D with the configurator. A product available editor is used to create the following contents for the DDB file. File name: PB92F036.GSD ;*****************************************************************************...
  • Page 76 7. DDB FILE MELSEC-A Trdy_9.6 Trdy_19.2 Trdy_93.75 Trdy_187.5 Trdy_500 Trdy_1.5M Trdy_3M Trdy_6M Trdy_12M Tqui_9.6 Tqui_19.2 Tqui_93.75 Tqui_187.5 Tqui_500 Tqui_1.5M Tqui_3M Tqui_6M Tqui_12M Tset_9.6 Tset_19.2 Tset_93.75 Tset_187.5 Tset_500 Tset_1.5M Tset_3M Tset_6M Tset_12M = 16 LAS_Len = 127 Tsdi_9.6 = 10 Tsdi_19.2 = 15 Tsdi_93.75 = 15...

  • Page 77: Programming

    8. PROGRAMMING A programming example is detailed below. In this example, the AJ71PB92D/A1SJ71PB92D is attached to the No.0 slot on the base unit. When diverting the program example introduced in this chapter to the actual system, fully check that there are no problems in the controllability of the system.

  • Page 78: Data I/O With Slave

    RST reset instruction Point Pay attention to the increase of the scan time since it will take at least 3.3ms to process the FROM/TO instruction. It is recommended to perform the FROM/TO instruction for the AJ71PB92D/A1SJ71PB92D only once in each sequence scan.

  • Page 79: Extend Service Mode (Mode Switch : No. E)

    It is recommended to perform the FROM/TO instruction for the AJ71PB92D/A1SJ71PB92D only once in each sequence scan. (2) If the network configuration allows the power supplies to the A1SJ71PB92D and to the slave station to be on simultaneously, there may be cases in which the slave side is not completely started at the time the X1B turns on.

  • Page 80: Communication Trouble Area And Expansion Communication Trouble Area Clear

    8. PROGRAMMING MELSEC-A Communication Trouble Area and Expansion Communication Trouble Area Clear Communication trouble area clear instruction Communication trouble area and expansion SET Y02 communication trouble Communication area clear Communication Module trouble area READY READY clear end RST Y02 RST " Communication trouble area clear instruction"...

  • Page 81: Global Control

    8. PROGRAMMING MELSEC-A Global Control Following is shown an example of when a global control service (SYNC) is transmitted to each slave station in groups 1 and 2. (For information regarding service commands refer to Section 4.3.2.9.) H03** shows groups 1 and 2. H**20 shows the SYNC.

  • Page 82: While-Run Operation Mode Changing

    8. PROGRAMMING MELSEC-A 8.6 While-Run Operation Mode Changing The operation mode is changed by writing "0000h" (the operation mode is changed to the normal operation mode without the mode registered onto E PROM) to the operation mode change request area of the buffer memory. Operation Exchange mode change...

  • Page 83: Troubleshooting

    9. TROUBLESHOOTING MELSEC-A 9. TROUBLESHOOTING This chapter explains the troubleshooting for the use of the A1SJ71PB92D. Definition Measures   Normal Abnormal The watchdog timer timed out. Contact the nearest service center or dealer.   READY Normal in mode 0 or E Abnormal in other than Offline or did not enter the self-diagnosis mode.
  • Page 84 9. TROUBLESHOOTING MELSEC-A The following table indicates the error definitions of the AJ71PB92D/A1SJ71PB92D that change depending on the combination of the RSP ERR. LED and FAULT LED states. RSP ERR. FAULT Definition Measures There is a slave station that has the same address as that of the master station Correct the parameter.

  • Page 85: Appendix

    E" was added to the MODE setting switch. If the MODE setting switch on the A1SJ71PB92D of the software version D or earlier is set to No. E, we cannot guarantee its operation. Do not set the MODE setting switch of the software version D or earlier to No.

  • Page 86: Appendix 1.2 Restrictions On Use Of A1Sj71Pb92D Software Versions In The Same System

    (1) Differences between the software versions are whether new functions were added or not. Use of the A1SJ71PB92D software versions in the same system will pose no problems. In addition, replacing the old software version with a new software version will pose no problems.

  • Page 87: Appendix 2 Precautions For Replacing Aj71Pb92 With A(1S)J71Pb92D

    APPENDIX MELSEC-A Appendix 2 Precautions for Replacing AJ71PB92 with A(1S)J71PB92D Pay attention to the following points when replacing the AJ71PB92 with the A(1S)J71PB92D. (1) The sequence programs and cable wiring prepared for the AJ71PB92 can be used for the A(1S)J71PB92D. (2) The parameters for the AJ71PB92 cannot be used for the A(1S)J71PB92D due to a file format difference.
  • Page 88 However, since the both values of the A(1S)J71PB92D are smaller than those of the AJ71PB92, power supply module replacement, base unit mounting screw reinforcement, etc. are not necessary. LED Name AJ71PB92 AJ71PB92D A1SJ71PB92D 5VDC internal current 1.3A 0.54A 0.56A consumption Weight 0.5kg...
  • Page 89 APPENDIX MELSEC-A Remarks The following functions have been added to the A(1S)J71PB92D. (a) Mode As compared to the AJ71PB92, the extended service mode (mode E) has been added*1 to the A(1S)J71PB92D. In the extended service mode, up to 244 bytes of data can be sent/received per slave station.
  • Page 90 APPENDIX MELSEC-A (e) Buffer memory As compared to the AJ71PB92, the following buffer memory areas have been added or modified to the A(1S)J71PB92D. Buffer Memory Address Addition/Modification Explanation (Decimal/hexadecimal) 0 / 0h Modification Input area In the A(1S)J71PB92D, the layout of the input areas of the slave stations changes depending on the received data length in the extended service mode 959 / 3BFh only.

  • Page 91: Appendix 3 Extended Trouble Information Of Mitsubishi's Slaves

    APPENDIX MELSEC-A Appendix 3 Extended Trouble Information of Mitsubishi's Slaves (1) AJ95TB2-16T AJ95TB2-16T notifies device-related trouble information to the master. The information consists of seven bytes including the header (one byte) as shown below: Header Always set to 00h (Fixed to 07h)

  • Page 92: Appendix 4 External Dimensions

    APPENDIX MELSEC-A Appendix 4 External Dimensions (1) AJ71PB92D (0.17) AJ71PB92D SD/RD TOKEN READY FROM/TO PRM SET RSP ERR. FAULT TEST 0:ONLINE 1 MODE 1:PRM SET 2:TEST E:ONLINE 2 RS-232-C PROFIBUS BUS TERMINATION 106 (4.17) 37.5 (1.48) (0.17) Unit : mm (inch)
  • Page 93 APPENDIX MELSEC-A (2) A1SJ71PB92D A1SJ71PB92D TEST SD/RD TOKEN READY FROM/TO PRM SET RSP ERR. FAULT MODE 0:ONLINE 1 1:PRM SET 2:TEST E:ONLINE 2 RS-232-C PROFIBUS BUS TERMINATION A1SJ71PB92D 93.6 (3.69) 34.5(1.36) (0.26) (0.16) Unit : mm (inch)
  • Page 94 APPENDIX MELSEC-A MEMO A-10...
  • Page 95 6. Failure caused by reasons unpredictable by scientific technology standards at time of shipment from Mitsubishi. 7. Any other failure found not to be the responsibility of Mitsubishi or that admitted not to be so by the user. 2. Onerous repair term after discontinuation of production (1) Mitsubishi shall accept onerous product repairs for seven (7) years after production of the product is discontinued.
  • Page 96 Microsoft, Windows, Windows NT are registered trademarks of Microsoft Corporation in the United States and other countries. Other company names and product names used in this document are trademarks or registered trademarks of respective companies.
  • Page 98 PROFIBUS-DP Interface Module Type AJ71PB92D/A1SJ71PB92D User s Manual A1SJ71PB92D-U-S-E MODEL MODEL 13JL20 CODE IB(NA)-66773-G(0408)MEE HEAD OFFICE : 1-8-12, OFFICE TOWER Z 14F HARUMI CHUO-KU 104-6212,JAPAN NAGOYA WORKS : 1-14 , YADA-MINAMI 5-CHOME , HIGASHI-KU, NAGOYA , JAPAN When exported from Japan, this manual does not require application to the Ministry of Economy, Trade and Industry for service transaction permission.
