IMPORTANT SAFEGUARDS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. GRAPHIC SYMBOL EXPLANATION The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"...
Page 3
CAUTION Do not drop or strike this equipment. Sensitive electronics inside are vulnerable to excessive shock. Do not install the equipment near any naked flames or heat sources. Excessive heat could damage this unit. Do not expose this unit to rain or excessive moisture, avoid smoke and dust.
Page 4
CONGRATULATIONS Thank you for purchasing this D/N 720P HD Vandal Resistant Dome IP Camera. You now own one of the many fine network products we manufactured. This product has been carefully inspected under rigid quality control and should reach you in perfect condition.
Page 5
Executive Summary IPD312S4.3 is an D/N 720P HD Vandal Resistant Dome IP Camera, built-in H.264 AVC(Advanced Video Coding) video compression. H.264 AVC video compression engine supports high definition video quality, 720P(1280x768) resolution, bandwidth efficiency with PPPoE and DDNS. Also it provides higher bit rate of internet and diverse alarm functions such as movement video detection e-mail or FTP.
PART DESCRIPTION & DIMENSION Unit: mm ± DC12V Power Input Jack (DC12V 10%) RJ-45 Network Connector Reset Cable To restore the server to factory default setting. Bottom Chassis Outer Cover Camera Body Network Indicator LEDs Green(LINK): Network cable connected, this LED lit. Orange(ACT): Data communications, this LED flashes.
INSTALLATION 1. Please use the enclosed hexagon screw driver to untighten the 2 screws on the bottom chassis (FIG.1). FIG. 1 │ 2. Rotate the bottom chassis and outer cover until both " " marks are align, then separate them (FIG.2 & FIG.3). FIG.
Page 8
3. Put the provided screws (M3.0*25, wooden screw) through the holes marked as "a", and fix the bottom chassis in the desired area (FIG.4 & FIG.5). 120° FIG. 4 FIG. 5 4. Plug the network cable and power cable to RJ-45 network connector and DC power input jack of the IP camera (FIG.6).
Page 9
FIG. 7 FIG. 8 6. Loosen the screws on the outer cover to rotate the camera body to the desired angle and then tighten the screws (FIG.9 & FIG.10). FIG. 9 FIG. 10...
Page 10
Instr uction Manual 3. CD Software Pack 4. Power Adaptor SYSTEM ARCHITECTURES For connecting IPD312S4.3 to the network, please follow one of the system architectures: (1). Use DC12V power adapter and network switch connected to a network. LAN / Internet Non-PoE Switch IPD312S4.3...
(2). Use with PoE-powered network switch and the PoE splitter connected to a network. LAN / Internet PoE Switch PoE Splitter IPD312S4.3 (DC12V) EMERGENCY FACTORY DEFAULT Use hardware to restore factory default settings, follow these steps: 1. The "RESET" cable short 10 seconds, then release.
SPECIFICATIONS D/N 720P HD VANDAL RESISTANT DOME IP CAMERA Model No. IPD312S4.3 Focal Length 4.3mm Lens Iris F1.8 ° ° ° Angle of view 49.8 (H), 36.8 (V), 63.6(D) Pick Up Element 1/4" Progressive scan CMOS sensor Effective Pixels 1280(H) x 800(V) = 1,024,000(pixel) Chip Size 3.88mm(H) x 2.43mm(V)
Page 13
DHCP, PPPoE, DNS, RTSP, RTCP, Telnet Mobile Phone and PDA iPad, iPhone and Android support Support System Integration ONVIF Free CMX HD3.2 support Video Display LILIN Universal ActiveX Embedded Linux 2.4.19 Design and specification are subject to change without notice. 66-IPD31CSE-1...
