30" ELECTRIC SLIDE-IN RANGE INSTALLATION INSTRUCTIONS
8.
Range
Installation
Important Note:
Door removal is not
a requirement for
installation of the
range, but is an added
convenience. Refer to
the Use and Care Guide
for oven door removal
instructions.
Standard Installation
8.1
The range cooktop overlaps the countertop at
the sides and the range rests on the floor. The
cooktop is 31½" (80 cm) wide.
8.2
Install base cabinets 30" (76,2 cm) apart. Make
sure they are plumb and level before attaching
cooktop. Shave raised countertop edge to clear
31½" (80 cm) wide range top rim.
8.3
Install cabinet doors 32" (81,3 cm) min. apart so
as not to interfere with range door opening.
8.4
Cutout countertop exactly as shown on page 4.
For models equipped with Leveling Device:
Make sure the front leveling legs and the rear
8.5
leveling device are setup higher than the height
of the cabinet.
8.6
Install the anti-tip bracket at
this point before placing the range at its final
position. Follow the installation instructions
on page 12 or on the anti-tip bracket template
supplied with the range.
To provide an optimum installation, the top
8.7
surface of the countertop must be level and
flat (lie on the same plane) around the 3 sides
that are adjacent to range cooktop. Proper
adjustments to make the top flat should be made
or gaps between the countertop and the range
cooktop may occur.
8.8
To reduce the risk of damaging
your appliance, do not handle or manipulate it by the
ceramic glass. Manipulate with care.
8.9
Position range in front of the cabinet opening.
Make sure the cooktop glass that overhangs the
8.10
countertop clears the countertop before sliding
range into position. If necessary, raise the unit by
lowering the leveling legs.
8.11
Slide the range into the cutout opening and
center it before leveling it.
8.12
Level the range (see section 9). The floor
where the range is to be installed must be level.
Follow the instructions under "Leveling the
8.13
For models equipped with Leveling Leg only (no
Figure 15
leveling device):
8.5
8.6
8.7
8.8
8.9
8.10
8.11
8.12
11
Range- Models Equipped with Leveling Device".
On models with a leveling device, remove the
rear legs and discard. Adjust the leveling legs
on the front of the appliance so that the cooktop
glass clears the countertop. Level the appliance
(see Leveling the range: Models Equipped
with Leveling Device). The glass should not be
supported by the countertop or any hatched or
shaved areas of the countertop.
Make sure the four leveling legs (front and rear)
are setup higher than the height of the cabinet.
Install the anti-tip bracket at
this point before placing the range at its final
position. Follow the installation instructions
on page 13 or on the anti-tip bracket template
supplied with the range.
To provide an optimum installation, the top
surface of the countertop must be level and
flat (lie on the same plane) around the 3 sides
that are adjacent to range cooktop. Proper
adjustments to make the top flat should be made
or gaps between the countertop and the range
cooktop may occur.
To reduce the risk of damaging
your appliance, do not handle or manipulate it
by the ceramic glass. Manipulate with care.
Position range in front of the cabinet opening.
Make sure that the glass which overhangs the
countertop clears the countertop. If necessary,
raise the unit by lowering the leveling legs.
Level the range (see section 9). The floor
where the range is to be installed must be level.
Follow the instructions under "Leveling the
Range-Models Equipped with Leveling Legs".
Slide the range into the cutout opening.
If Accessories Needed :
IMPORTANT
Installation With Backguard
The cutout depth of (21 3/4" (55,2 cm) Min., 22 1/8"
(56,2 cm) Max.) needs to be increased to 24" (61
cm) when installing a backguard.
Installation With End Panel
A End Panel kit can be ordered through a Service
Center.
Installation With Side Panels
A Side Panels kit can be ordered through a Service
Center. Note: Install cabinet doors 32" (81,3 cm) min.
apart so as not to interfere with range door opening.
