Frigidaire CGEF3031K Factory Parts Catalog

30-inch free-standing electric range
Hide thumbs

Advertisement

Quick Links

LGEF3031KBA.eps CFGEF3031KBA.eps VCGEF3031KBA.eps TFGEF3031KBA.eps
DLGEF3031KBB.eps
Electrolux Major Appliances
North & Latin America
5855 TERRY FOX WAY
MISSISSAUGA, ONTARIO, CANADA L5V
3E4
Product No.
CGEF3031KBA CGEF3031KWA
Series
30" f/s elec
Color
black
Market
Canada
Owner's Guide
316902301
Installation Instructions 316259203
Service Data Sheet
316905027
Publication No.
5995549093
09/08/13
(EN/SERVICE/ECL)
369
30" f/s elec
white
Canada
316902301
316259203
316905027
30-INCH FREE-
STANDING ELECTRIC
RANGE
Model No.
CGEF3031K
©
Copyright
2009 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

  Summary of Contents for Frigidaire CGEF3031K

  • Page 1 LGEF3031KBA.eps CFGEF3031KBA.eps VCGEF3031KBA.eps TFGEF3031KBA.eps STANDING ELECTRIC DLGEF3031KBB.eps RANGE Electrolux Major Appliances North & Latin America Model No. 5855 TERRY FOX WAY MISSISSAUGA, ONTARIO, CANADA L5V CGEF3031K Publication No. 5995549093 09/08/13 (EN/SERVICE/ECL) © Copyright 2009 Electrolux Home Products, Inc. All rights reserved.
  • Page 2 Publication No: 5995549093 CGEF3031K BACKGUARD 14 14 CFGEF3031KBA 08/09...
  • Page 3 CGEF3031K Publication No: 5995549093 BACKGUARD Model Index: A CGEF3031K (CGEF3031KWA) B CGEF3031K (CGEF3031KBA) POS. NO PART NO. DESCRIPTION 316557600 Shield, rear wall 13A# 316095503 Switch, infinite, warmer 316022500 Light/Lamp, indicator, 125 V 316546704 Cap, backguard, white, RH end 316546702 Cap, backguard, black, RH end...
  • Page 4 Publication No: 5995549093 CGEF3031K BODY NOTE: Oven Liner N/A Ass. du four N/A VCGEF3031KBA 08/09...
  • Page 5 CGEF3031K Publication No: 5995549093 BODY Model Index: A CGEF3031K (CGEF3031KWA) B CGEF3031K (CGEF3031KBA) POS. NO PART NO. DESCRIPTION 316401801 Panel, main back 316400116 Panel, bodyside, white, RH 316400117 Panel, bodyside, white, LH 316400118 Panel, bodyside, black, RH 316400119 Panel, bodyside, black, LH...
  • Page 6 Publication No: 5995549093 CGEF3031K TOP/DRAWER TFGEF3031KBA 08/09...
  • Page 7 CGEF3031K Publication No: 5995549093 TOP/DRAWER Model Index: A CGEF3031K (CGEF3031KWA) B CGEF3031K (CGEF3031KBA) POS. NO PART NO. DESCRIPTION 316408703 Drawer, utility 316403300 Liner, drawer 316403501 Panel, drawer front, white 316403502 Panel, drawer front, black 316407400 Glide, drawer, rear 15 # 318198846 Element, surface, 6", 1200W, (2), radiant...
  • Page 8 Publication No: 5995549093 CGEF3031K DOOR DLGEF3031KBB 08/09...
  • Page 9 CGEF3031K Publication No: 5995549093 DOOR Model Index: A CGEF3031K (CGEF3031KWA) B CGEF3031K (CGEF3031KBA) POS. NO PART NO. DESCRIPTION 5303935318 Trim kit-door, 3 sided, white, w/tape 5303935317 Trim kit-door, 3 sided, black, w/tape 316566406 Glass Assembly, outer, white, w/badge 316566408 Glass Assembly, outer, black, w/badge...

This manual is also suitable for:

Cgef3031kbaCgef3031kwa
