Advantech PCM-9342 Startup Manual

PCM-9342 EVA-X4150 3.5" SBC with PC/104, VGA/
TTL/LVDS Ethernet/USB 2.0 and SSD
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 PCM-9342 SBC
• 1 Startup Manual
• 1 Utility CD
• 1 Mini jumper pack
• 1 SATA cable
• 1 Keyboard/Mouse cable
• 2 COM3/COM4 cable
• 1 Parallel port cable
• 1 COM2 cable
• 1 USB 2 port cable
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1:
For detailed contents of the PCM-9342, please
refer to information on the enclosed CD-ROM (in
PDF format).
Note 2:
Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
www.adobe.com/Products/acrobat/readstep2.
html (Acrobat is a trademark of Adobe
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support/
This manual is for the PCM-9342 series Rev. A1
Part No. 2006934200
Printed in China
p/n: 9689000002
p/n: 1700008894
p/n: 1700060202
p/n: 1700100250
p/n: 1700260250
p/n : 1701140201
p/n: 1703100121
)
®
1st Edition,
Nov. 2008
Specifications
General
• CPU: Advantech EVA-X4150 SoC
• System Chipset: Advantech EVA-X4150 SoC
• System Memory: 64 MB onboard SDRAM
• BIOS: Award 4-Mbit Flash BIOS
• Watchdog Timer: 255 level timer interval
• Expansion Interface: PC/104
• Battery: Lithium 3 V/210 mAH
• SATA interface: Two SATA ports (100 MB/s transfer from
IDE)
• Parallel port: One parallel port, supports SPP/EPP/ECP-
mode, shared with FDD
• Keyboard/mouse connector: Supports one standard
PC/AT keyboard and a PS/2 mouse
• USB: Two USB 2.0 compliant universal serial bus ports
• GPIO: 8-bit general purpose Input/Output
Solid State Disk
• Supports one 50-pin socket for CFC type I/II
VGA/LVDS Interface
• Chipset: SMI SM712 2D Graphic Chip
• Memory Size: built-in 4 MB display memory on SM712
• Resolution:
- CRT display mode: pixel resolution up to 1024 x 768
@85 Hz
- LVDS display mode: 1024 x 768 at 65 MHz
• TTL LCD: supports 24-bit TTL LCD
• LVDS LCD: supports 18-bit LVDS LCD
• Dual Simultaneous Display:
- CRT + LVDS
- CRT + TTL
Ethernet Interface
• Chipset supports: 10/100 Mbps - Realtek RTL8100CL
(With Wake on LAN)
• Ethernet interface: IEEE 802.3u (100 BASE-T) protocol
compatible
• Built-in boot ROM
• RJ45 connector equipped
PCM-9342 Startup Manual
