  • Page 1 Advantech PCI-6881FG Half-Sized Single Board Computer Module 1395 In Stock Qty Available: 1 Used and in Excellent Condition Buy Today! https://www.artisantg.com/86790-3 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
  • Page 2 PCI-6886 ® ® PCI Intel Celeron M 600MHz 0L2 Half-sized SBC with VGA/ LVDS/LAN/USB2.0/SATA and User’s Manual...
  • Page 3 SMI is a trademark of Silicon Motion, Inc. Creative is a trademark of Creative Technology LTD. All other product names or trademarks are properties of their respective owners. For more information on this and other Advantech products, please visit our websites at: http://www.advantech.com http://www.advantech.com/epc For technical support and service, please visit our support website at: http://service.advantech.com.tw/eservice/...

  • Page 4: Packing List

    Before you begin installing your card, please make sure that the following materials have been shipped: • 1 PCI-6886 all-in one single board computer • 1 startup manual • 1 CD-ROM or disks for utility, drivers, and manual (in PDF format) •...

  • Page 5: Additional Information And Assistance

    PCI Celeron M 600M 0L2 Slot PC W/852GM,Giga LAN Additional Information and Assistance Visit the Advantech web site at www.advantech.com where you can find the latest information about the product. Step 1. Contact your distributor, sales representative, or Advantech's cus- tomer service center for technical support if you need additional assistance.
  • Page 6 This device complies with the requirements in part 15 of the FCC rules: Operation is subject to the following two conditions: 1.This device may not cause harmful interfer- ence, and 2. This device must accept any interference received, including interference that may cause undesired operation This equipment has been tested and found to comply with the limits for a Class A digital device,...
  • Page 7 PCI-6886 User’s Manual...

  • Page 8: Table Of Contents

    Contents Chapter 1 General Information ........2 Introduction ............... 2 Features ................2 Specifications ..............3 1.3.1 Standard SBC Functions..........3 1.3.2 Display Interface............. 4 1.3.3 DVI ................. 4 1.3.4 Solid State Disk .............. 4 1.3.5 PCI bus Ethernet interface ..........4 1.3.6 Mechanical and Environmental ........
  • Page 9 Figure 4.9:Frequency/Voltage Control ......37 4.2.10 Load Optimized Defaults..........38 Figure 4.10:Load BIOS defaults screen......38 4.2.11 Set Password ..............38 Figure 4.11:Set password..........39 4.2.12 Save & Exit Setup............40 Figure 4.12:Save to CMOS and EXIT......40 PCI-6886 User’s Manual viii...
  • Page 10 4.2.13 Exit Without Saving............41 Figure 4.13:Quit without saving ........41 Chapter 5 PCI SVGA Setup ..........44 Introduction ..............44 5.1.1 Chipset ................44 5.1.2 Display memory............44 5.1.3 Display types..............44 Installation of the SVGA Driver ........45 5.2.1 Installation for Windows 2000/XP .......
  • Page 11 Table C.2:1st MB memory map ........85 DMA channel assignments..........85 Table C.3:DMA channel assignments ......85 Interrupt assignments ............86 Table C.4:Interrupt assignments ........86 Appendix D Intel Speedstep Technology ......88 Intel® Pentium® M SpeedStep instruction..... 88 PCI-6886 User’s Manual...
  • Page 12 General Information This chapter gives background information on the PCI-6886. Sections include: • Introduction • Features • Specifications • Board layout and dimensions Chapter 1 General Information...

  • Page 13: Chapter 1 General Information

    Chapter 1 General Information 1.1 Introduction The PCI-6886 series is a half-sized PCI bus CPU card designed with powerful Intel Celeron M processor, with Intel 852GM and 6300ESB chipset, which supports enhanced Intel "SpeedStep" technology and Dynamic Video Memory Technology. For maximum performance, PCI- 6886 also supports two 200PIN SODIMM socket that Non-ECC DDR memory up to 2GB.

  • Page 14: Specifications

    • Supports 4 x USB2.0 port • Supports 2 Channel 36bits LVDS for LCD • Supports 400MHz Front Side Bus • Supports 200-MHz, and 266-MHz DDR SDRAM 1.3 Specifications 1.3.1 Standard SBC Functions • CPU:Intel Celeron M 600MHz(0 KB) onboard:(PCI-6886F- M0A1,PCI-6886FG-M0A1).

  • Page 15: Display Interface

    • Power supply voltage: +5 V, +5V STB, +12V • Power requirements: Max:(Run Kpower under Win2000+SP4) 2.42A@5V,0.32A@12V,(w/CeleronM 600M0L2+512M) Typical:(Run Kpower under Win2000+SP4) 1.91A@5V,0.31A@12V,(w/CeleronM 600M0L2+512M) • Operating temperature: 0 ~ 60°C (32 ~ 140°F),operation • Operating humidity: 0% ~ 90% Relative Humidity, Non condensing PCI-6886 User’s Manual...

  • Page 16: Board Layout: Dimensions

    1.4 Board layout: dimensions Figure 1.1: Board layout: dimensions (component side) Chapter 1 General Information...
  • Page 17 Figure 1.2: Board layout: dimensions (solder side) PCI-6886 User’s Manual...
  • Page 18 Installation This chapter explains the setup procedures of PCI-6886 hardware, including instruc- tions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all safety precautions before you begin the installation procedure. Chapter 2 Installation...

  • Page 19: Chapter 2 Installation

    Chapter 2 Installation 2.1 Jumpers The PCI-6886 has a number of jumpers that allow you to configure your system to suit your application. The table below lists the functions of the various jumpers. Table 2.1: Jumpers Label Function COM2 RS232/422/485 Selection...

  • Page 20: Connectors

    2.2 Connectors On-board connectors link the PCI-6886 to external devices such as hard disk drives, a keyboard, or floppy drives. The table below lists the func- tion of each of the board’s connectors. Table 2.2: Connectors Label Function Front Pannel Connector...

  • Page 21: Locating Connectors(Component Side)

    2.3 Locating Connectors(component side) Figure 2.1: Jumper&Connector Locations PCI-6886 User’s Manual...

  • Page 22: Locating Connectors(Solder Side)

    2.4 Locating Connectors(solder side) Figure 2.2: Connectors (component side) Chapter 2 Installation...

  • Page 23: Setting Jumpers

    A pair of needle-nose pliers may be helpful when working with jumpers. If you have any doubts about the best hardware configuration for your application, contact your local distributor or sales representative before you make any changes. Generally, you simply need a standard cable to make most connections. PCI-6886 User’s Manual...

  • Page 24: Com2 Rs232/422/485 Select(Jp1)

    2.6 COM2 RS232/422/485 Select(JP1) Table 2.3: COM2 RS232/422/485 Select *1-2 RS232 RS422 RS485 * : Default setting 2.7 Clear CMOS (JP2) Warning! To avoid damaging the computer, always turn off the power supply before setting “Clear CMOS.” Before turning on the power supply, set the jumper back to “3.0 V Battery On.”...

  • Page 25: Lvds Panel Power Select(Jp3)

    The procedure for installing SODIMMs appears below. Please follow these steps carefully. 1. Make sure that all power supplies to the system are switched off 2. Install the SODIMM card. Install the SODIMM so that its gold pins PCI-6886 User’s Manual...

  • Page 26: Atx Power Control Connector (Cn5)

    The SODIMM should not move around in its socket. 2.11 ATX power control connector (CN5) The PCI-6886 support ATX power. CN5 supplies main power (+5V, +12V, 5VSB), and it is a 6 x 2 power connector, w/Fixed Lock, type: 4200-WS-A1.

  • Page 27: Printer Port Connector (Cn6)

    BIOS settings. 2.14 Floppy drive connector (CN4) You can attach up to two floppy drives to the PCI-6886’s on-board con- troller. You can use any combination of 5.25” (360 KB and 1.2 MB) and/ or 3.5” (720 KB, 1.44 MB, and 2.88 MB) drives.

  • Page 28: Ide Connector(Cn3,Cn7)

    Appendix B. 2.15 IDE connector(CN3,CN7) The PCI-6886 provides two IDE channels to which you can attach up to four Enhanced Integrated Device Electronics hard disk drives or CDROM to the PCI-6886’s internal controller. The PCI-6886's IDE con- troller uses a PCI interface.

  • Page 29: Vga/Lvds Interface Connections

    Digital Visual Interface (DVI) is the standard interface for high-perfor- mance connection between PCs and Flat Panel Displays, Digital CRT dis- plays, Projectors, and HDTV. The PCI-6886 is able to drive a DVI connector display at a pixel rate of up to 165MHz, supporting UXGA res- olution displays and hot plug detection.

  • Page 30: Ethernet Configuration

    RJ-45 connectors(CN12). PCI-6886F series supports 10/100Base-T LAN, PCI-6886FG series supports 1000Base-T LAN. 2.18.1 LAN connector (CN12) 10/100 or 1000 Base-T connects to the PCI-6886 via a cable to a standard RJ-45 connector. 2.18.2 Network boot The Network Boot feature can be utilized by incorporating the Boot ROM image files for the appropriate network operating system.

  • Page 31: Power Led (Pin 3 & Pin 4)

    This allows no-keyboard operation in embedded system applications, without the system halting under POST. 2.22 External KB Connector(CN18) In addition to the Mini keyboard connector on the PCI-6886’s rear plate, there is an additional onboard external keyboard connector, allowing for greater flexibility in system design.

  • Page 32: Ac'97 Interface Connector (Cn17)

    PCI-6886 can support separate independent PCI functions for Audio and Modem, which is compliant to AC'97 Version 2.2 standard. The AC'97 interface is a 5 x 2 pin box header. The PCI-6886 can support Audio with the addition of optional PCM-231A-00A1. Detailed pin assignment refer to Appendix B.
  • Page 33 PCI-6886 User’s Manual...
  • Page 34 Software Configuration This chapter details the software con- figuration information. It shows you how to configure the card to match your application requirements. Award System BIOS will be covered in Chapter 4. Sections include: • Introduction • VGA display software configuration...

  • Page 35: Chapter 3 Software Configuration

    BIOS simply by reprogramming the Flash chip. NOTE: Due to Intel would not support Win98, Windows ME driver, PCI-6886 is not recommended to install Win98, Windows ME. 3.2 VGA display firmware configuration The board’s on-board VGA interface supports a wide range of popular LCD, flat panel displays and traditional analog CRT monitors.
  • Page 36 At the prompt, type AWDFLASH.EXE and press <Enter>. The VGA configuration program will then display the following: Figure 3.1: VGA setup screen At the prompt, enter the new BIN file which supports your display. When you are sure that you have entered the file name correctly press <Enter>.
  • Page 37 PCI-6886 User’s Manual...
  • Page 38 Chapter 4 Ducks that Need Love! Award BIOS Setup This chapter describes how to set BIOS configuration data.

  • Page 39: Chapter 4 Award Bios Setup

    The CMOS memory has lost power and the configuration informa- tion has been erased. The PCI-6886 Series' CMOS memory has an integral lithium battery backup. The battery backup should at least three years in normal service, but when it finally runs down, you will need to replace the complete unit.

  • Page 40: Award Bios Setup

    4.2 Award BIOS setup Award’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. 4.2.1 Entering setup Power on the computer and press <Del>...

  • Page 41: Standard Cmos Features Setup

    Setup Menu allows users to configure system components such as date, time, hard disk drive, floppy drive and display. Once a field is high- lighted, on-line help information is displayed in the right top of the Menu screen. Figure 4.2: Standard CMOS Features setup PCI-6886 User’s Manual...

  • Page 42: Advanced Bios Features Setup

    4.2.3 Advanced BIOS Features setup By choosing the Advanced BIOS Features Setup option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCI-6886 Series. Figure 4.3: Advanced BIOS Features setup...

  • Page 43: Advanced Chipset Features Setup

    4.2.4 Advanced Chipset Features setup By choosing the Advanced Chipset Features option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCI-6886 Series. Figure 4.4: Advanced Chipset Features setup PCI-6886 User’s Manual...

  • Page 44: Integrated Peripherals

    4.2.5 Integrated Peripherals Choosing the Integrated Peripherals option from the Initial Setup Screen menu should produce the screen below. Here we see the manufacturer’s default values for the PCI-6886 Series. Figure 4.5: Integrated Peripherals...

  • Page 45: Power Management Setup

    4.2.6 Power Management Setup By choosing the Power Management Setup option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCI-6886 Series. Figure 4.6: Power Management Setup PCI-6886 User’s Manual...

  • Page 46: Pnp/Pci Configurations

    4.2.7 PnP/PCI Configurations By choosing the PnP/PCI Configurations option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCI-6886 Series. Figure 4.7: PnP/PCI Configurations...

  • Page 47: Pc Health Status

    4.2.8 PC Health Status The PC Health Status option displays information such as CPU and moth- erboard temperatures, fan speeds, and core voltage. Figure 4.8: PC Health Status PCI-6886 User’s Manual...

  • Page 48: Frequency/Voltage Control

    4.2.9 Frequency/Voltage Control By choosing the Frequency/Voltage Control option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCI-6886 Figure 4.9: Frequency/Voltage Control Caution Incorrect settings in Frequency/Voltage Control may damage the system CPU, video adapter, or other hardware.

  • Page 49: Load Optimized Defaults

    ROM. If the stored record created by the Setup program should ever become corrupted (and therefore unusable), these defaults will load auto- matically when you turn the PCI-6886 Series system on. Figure 4.10: Load BIOS defaults screen 4.2.11 Set Password...
  • Page 50 Choose the Set Password option from the CMOS Setup Utility main menu and press <Enter>. When you see “Enter Password,” enter the desired password and press <Enter>. At the “Confirm Password” prompt, retype the desired password, then press <Enter>. Select Save to CMOS and EXIT, type <Y>, then <Enter>. Figure 4.11: Set password To Change Password Choose the Set Password option from the CMOS Setup Utility...

  • Page 51: Save & Exit Setup

    <Enter>. At the “Confirm Password” prompt, again don’t type in anything; just press <Enter>. Select Save to CMOS and EXIT, type <Y>, then <Enter>. 4.2.12 Save & Exit Setup Figure 4.12: Save to CMOS and EXIT PCI-6886 User’s Manual...

  • Page 52: Exit Without Saving

    If you select this option and press <Y> then <Enter>, the values entered in the setup utilities will be recorded in the chipset’s CMOS memory. The microprocessor will check this every time you turn your system on and use the settings to configure the system. This record is required for the system to operate.
  • Page 53 PCI-6886 User’s Manual...
  • Page 54 PCI SVGA Setup Introduction Installation of SVGA drivers -for Windows 2000/XP Further information...

  • Page 55: Chapter 5 Pci Svga Setup

    The board has an onboard interface. The specifications and features are described as follows: 5.1.1 Chipset The PCI-6886 uses a Intel 852GM + 6300ESB chipset for its graphic con- troller. It supports LVDS LCD displays, conventional CRT monitors. 5.1.2 Display memory...

  • Page 56: Installation Of The Svga Driver

    5.2 Installation of the SVGA Driver Complete the following steps to install the SVGA driver. Follow the pro- cedures in the flow chart that apply to the operating system that you are using within your board. Notes: 1. The windows illustrations in this chapter are intended as examples only.
  • Page 57 Press the "Next" button. Press the "Next" button. PCI-6886 User’s Manual...
  • Page 58 In order to continue setup, you must accept the agreement, press the "Yes" button and wait a minute. Choose the option "Yes, I want to restart my computer now." and press the "Finish" button. Chapter 5...

  • Page 59: Further Information

    5.3 Further Information For further information about the AGP/VGA installation in your PCA- 6886, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: Intel website: www.intel.com. Advantech websites: www.advantech.com www.advantech.com.tw PCI-6886 User’s Manual...
  • Page 60 PCI Bus Ethernet Inter- face This chapter provides information on Ethernet configuration. • Introduction • Installation of Ethernet drivers for Windows XP • Further information...

  • Page 61: Chapter 6 Pci Bus Ethernet Interface

    MS-DOS or Windows. Note: The windows illustrations in this chapter are examples only. Follow the steps and pay atten- tion to the instructions which appear on your screen. 6.2.1 Installation for Windows XP PCI-6886 User’s Manual...
  • Page 62 Select “ Ethernet Controller” from Device Manager. Select “Update Driver”. Chapter 6...
  • Page 63 Click the “Next” button. Click the “Next” button. PCI-6886 User’s Manual...
  • Page 64 Please choose “Continue Anyway”. Click the “Finish” button Chapter 6...
  • Page 65 PCI-6886 User’s Manual...
  • Page 66 Audio Setup • Introduction • Installation of audio driver for Win- dows XP Chapter 7...

  • Page 67: Chapter 7 Audio Setup

    7.2.1 Before you begin Please read the instructions in this chapter carefully before you attempt installation. The audio drivers for the PCI-6886 board are located on the audio driver CD. Run the supplied SETUP program to install the drivers; don't copy the files manually.
  • Page 68 1. Select the path: D:\wdm_a357, then double click to run "Install Shield Wizard". 2. Press the "Next" button and wait for a moment. Chapter 7...
  • Page 69 3. Choose the option "Continue Anyway”. 4. Choose the option "Yes, I want to restart my computer now", then click "Finish" button to reboot your computer. PCI-6886 User’s Manual...
  • Page 70 Programming GPIO & Watchdog Timer The board is equipped with a watchdog timer that resets the CPU if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned environments.

  • Page 71: Appendix A Programming Gpio & Watchdog Timer

    Extended Function Index Registers (EFIRs) The EFIRs are write-only registers with port address 2Eh or 4Eh on PC/ AT systems. Extended Function Data Registers(EFDRs) the EFDRs are read/write registers with port address 2Fh or 4Fh on PC/ AT systems. PCI-6886 User’s Manual...

  • Page 72: Gpio Example Program-1

    A.1.2 GPIO Example program-1 ------------------------------------------------ Enter the extended function mode, interruptible double-write ------------------------------------------------ MOV DX,2EH MOV AL,87H OUT DX,AL OUT DX,AL --------------------------------------------------------------- Configurate logical device 7(GP10~GP17), configuration register CRF0,CRF1,CRF2 --------------------------------------------------------------- MOV DX,2EH MOV AL,07H ; point to Logical Device Number Reg. OUT DX,AL MOV DX,2FH MOV AL,07H ;...

  • Page 73: Watchdog Programming

    2, Set Watchdog Timer to 20 Second Outportb (0x2e,0x87); Outportb (0x2e,0x87); //Entry Configuration Mode Outportb (0x2e,0x07); //Select Register Index 0x07 Outportb (0x2f,0x08); //Select LDN 8 Outportb (0x2e,0xf6); //Select LDN 8 Register Index 0x30 Outportb (0x2f,0x20); //Set 20 second PCI-6886 User’s Manual...
  • Page 74 Outportb (0x2e,0xaa); //Exit Configuration Mode 3, Disable Watchdog Outportb (0x2e,0x87); Outportb (0x2e,0x87); //Entry Configuration Mode Outportb (0x2e,0x07); //Select Register Index 0x07 Outportb (0x2f,0x08); //Select LDN 8 Outportb (0x2e,0x30); //Select LDN 8 Register Index 0x30 Outportb (0x2f,0x00); //Disable Watchdog Timer Device Outportb (0x2e,0xaa);...
  • Page 75 PCI-6886 User’s Manual...
  • Page 76 Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • Floppy Drive Connector • Primary IDE Connector • LPT Connector • Secondary IDE(Slave) Connector • ATX Power Connector • COM3/COM4 output • USB1, 2 Connector •...

  • Page 77: Appendix B Pin Assignments

    Appendix B Pin Assignments B.1 ATX power connector (CN5) Table B.1: ATX power connector(CN5) Signal 5VSB PSON# +12V PCI-6886 User’s Manual...

  • Page 78: Floppy

    B.2 Floppy connector (CN4) Table B.2: Floppy Connector (CN4) Signal Signal RWC# Index# MOA# DSB# DSA# MOB# DIR# STEP# Track0# RDATA# HEAD# DSKCHG# *low active Appx. B...

  • Page 79: Primary Ide Connector (Cn3)

    B.3 Primary IDE Connector (CN3) Table B.3: Primary IDE connector (CN3) Signal Signal IDE RESET READY Cable Select DACK IRQ14 ATA check CS1# CS3# Active PCI-6886 User’s Manual...

  • Page 80: Secondary Ide Connector(Slave) (Cn7)

    B.4 Secondary IDE Connector(Slave) (CN7) Table B.4: Secondary IDE connector (CN7) Signal Signal IDE RESET READY Cable Select DACK IRQ14 ATA check CS1# CS3# Active Appx. B...

  • Page 81: Compactflash Connector(Cn21)

    B.5 CompactFlash connector(CN21) Table B.5: CompactFlash Connector (CN21) Signal Signal #CD1 #CE2 #VS14 #IORD #IOWR #IRQ #CSEL #VS2 RESET #WAIT #INPACK #REG BVD2 BVD1 IOCS16 #CD2 PCI-6886 User’s Manual...

  • Page 82: Lan,Rj45 Connector(Cn12)

    B.6 LAN,RJ45 connector(CN12) Table B.6: LAN,RJ45 connector(CN12) 10/100M Signal Signal 10/100/1000M MDI0- MDI2+ MDIO+ MDI2- MDI1+ MDI3+ MDI- MDI3+ B.7 USB1, 2 connector(CN10) Table B.7: USB 1, 2 connector(CN10) Signal Signal USB0- USB1- USB0+ USB1+ USB GND USB GND Appx. B...

  • Page 83: Usb 3, 4 Connector(Cn9)

    Table B.8: USB 3, 4 connector(CN9) Signal Signal USB0- USB1- USB0+ USB1+ USB GND USB GND B.9 LCD INV power connector(CN20) Table B.9: LCD INV power connector (CN20) Signal +12V output Back-light enable signal output Back-light VBR signal output +5V output PCI-6886 User’s Manual...

  • Page 84: Dio Connector(Cn2)

    B.10 DIO connector(CN2) Table B.10: DIO connector(CN2) Signal Signal Appx. B...

  • Page 85: Lvds Connector(Cn15)

    B.11 LVDS connector(CN15) Table B.11: LVDS connector (CN15) Signal Signal +5V/3.3V +5V/3.3V +5V/3.3V +5V/3.3V LVDS0_N0 LVDS1_N0 LVDS0_P0 LVDS1_P0 LVDS0_N1 LVDS1_N1 LVDS0_P1 LVDS1_P1 LVDS0_N2 LVDS1_N2 LVDS0_P2 LVDS1_P2 LVDS0_C0N LVDS1_C0N LVDS0_C0P LVDS1_C0P LVDS_DDC LVDS_DDCPDATA OCLK NC/LVDS1_N3 LVDS0_N3 NC/LVDS1_P3 LVDSS0_P3 +0.3V Reference PCI-6886 User’s Manual...

  • Page 86: Lpt Connector(Cn6)

    B.12 LPT connector(CN6) Table B.12: LPT connector(CN6) Signal Signal STB# AFD# INIT# SLIN ACK# BUSY SLCT Appx. B...

  • Page 87: Com 1, 2 Connector (Cn13, Cn14)

    B.13 COM 1, 2 Connector (CN13, CN14) 9 8 7 Table B.13: COM connector (CN 13, CN14) COM1 connector (CN13) COM2 connector (CN14) Signal Signal Signal Signal SOUT SOUT DTR- N.C. TXD422+/ TXD422-/ 485+ 485- RXD422+ RXD422- PCI-6886 User’s Manual...

  • Page 88: Com 3, 4 Connector (Cn8)

    B.14 COM 3, 4 Connector (CN8) Table B.14: COM3,4 Connector(CN8) Signal Signal DCD3 DSR3 SIN3 RTS3 SOUT3 CTS3 DTR3 DCD4 DSR4 SIN4 RTS4 SOUT4 CTS4 DTR4 B.15 Audio I/F connector(CN17) Table B.15: Audio I/F connector(CN17) Signal Signal BitCLK DATA IN Sync DATA OUT ACRST...

  • Page 89: D-Sub Vga Connector(Cn11)

    B.16 D-SUB VGA connector(CN11) Table B.16: D-SUB VGA connector(CN11) Signal Signal S-DATA HSYNC VSYNC S-CLK B.17 MINI PS/2_KB/Mouse connector(CN19) Table B.17: MINI Keyboard connector(CN19) Signal KBDATA MSDATA KBCLK MSCLK PCI-6886 User’s Manual...

  • Page 90: Ext_Kb Connector(Cn18)

    B.18 EXT_KB connector(CN18) Table B.18: EXT_KB/Mouse connector(CN18) Signal KBCLK KBDATA B.19 HDD LED/Reset/Power Button(CN1) Table B.19: HDD LED/Reset/Power Button(CN1) Signal Signal HDD_LED SUSPEND 5VSB RESET PWR_Button Appx. B...

  • Page 91: Dvi Connector (Cn16)

    B.20 DVI connector (CN16) Table B.20: DVI connector(CN16) Signal Signal TDC0- TDC0+ TDCCLK- TDCCLK+ TDC1- TDC1+ MDVICLK MDVIDATA TDC2+ HOT_DETECT TDC2+ MI2CDATA MI2CCLK B.21 CPU FAN connector (FAN1) Table B.21: CPU FAN connector (FAN1) Signal +12V FAN SPEED DETECT PCI-6886 User’s Manual...

  • Page 92: Serial Ata (Sa1,Sa2)

    B.22 Serial ATA (SA1,SA2) Table B.22: Serial ATA (SA1, SA2) Signal Appx. B...
  • Page 93 PCI-6886 User’s Manual...
  • Page 94 System Assignments This appendix contains information of a detailed nature. It includes: • System I/O ports • 1st MB memory map • DMA channel assignments • Interrupt assignments Appx. C...

  • Page 95: Appendix C System Assignments

    Secondary IDE Control 1F0-1F8 Primary IDE Control 200-20F Game Port 295-296 Hardware Monitor 2E8-2EF COM4 2F8-2FF COM2 378-37F Parallel Port(Standard & AFF) 3C0-3CF 3D0-3DF 3E8-3EF COM3 3F0-3F1 Configuration Index/Data 3F0-3F7 Floppy Controller 3F8-3FF COM1 778-77A Parallel Port(ECP Extensions)(Port 378+400) PCI-6886 User’s Manual...

  • Page 96: 1St Mb Memory Map

    Table C.1: System I/O ports Addr. range (Hex) Device CF8-CFB PCI Configuration Address CFC-CFF PCI Configuration Data D00-FFFF -available for system use- C.2 1st MB memory map Table C.2: 1st MB memory map Addr. range (Hex) Device F0000h - FFFFFh System ROM *D0000h - EFFFFh Unused (reserved for Ethernet ROM)

  • Page 97: Interrupt Assignments

    IRQ 7 LPT1 IRQ 8 IRQ 9 Reserved (audio) IRQ 10 COM3 IRQ 11 Reserved for watchdog timer IRQ 12 PS/2 mouse IRQ 13 INT from co-processor IRQ 14 Primary IDE IRQ 15 Secondary IDE for CFC PCI-6886 User’s Manual...
  • Page 98 Intel Speedstep Tech- nology • Introduction and Installation...

  • Page 99: Appendix D Intel Speedstep Technology

    CPU and memory unavailability time, which optimizes its power and performance according to demand. ® ® Advantech’s product with Intel Pentium M processors support speed stepping feature at Windows XP, To implement the speed stepping feature under Windows XP, please follow the listed steps: Step 1.
  • Page 100 Appendix D...
  • Page 101 Step 3. Discover the different CPU freq. by using FrequencyDisplay util- PCI-6886 User’s Manual...
  • Page 102 The Result of Pentium M speed stepping: ® ® 1.1G---600MHz / 800MHz / 1.1GHz( Intel Pentium ® 1.6G---600MHz / 800MHz / 1.0GHz /1.2GHz / 1.4GHz / 1.6GHz( Intel ® Pentium Appendix D...
  • Page 103 PCI-6886 User’s Manual...

This manual is also suitable for:

Pci-6881fg
