FLIR DBB43TL Quick Start Manual

Contents
1 x Ultra Resolution Color Camera
1 x Sunshade Housing
1 x Sunshade Screw
3 x Mounting Screws
1 x Allen Key
Features
• Ultra Resolution 1/3" image sensor / 600TV
• True Day/Night with Mechanical ICR
• 3.6mm Wide Angle lens
• Cold climate capability (minimum operating
temperature -22°F/-30°C)
• 70ft (21m) IR Night Vision*
• IP66 Weatherproof Rating**
• Cable through bracket design
• 12V DC Operation
* IR Illumination range under ideal conditions. Objects at or beyond
this range may be partially or completely obscured, depending on
the camera application.
** Not recommended for submersion in water.

Safety Precautions

• Use an appropriate low voltage power cable to prevent
fire or electrical shock.
• Make sure to install the camera in an area that can
support the camera weight.
• There are no user serviceable parts inside the camera.
Please do not disassemble the camera.
• Do not clean the lens cover with an abrasive cleaning
material. Please use a soft cloth to clean the lens cover.
WARNING - A REGULATED UL / CSA APPROVED 12V DC power
supply is REQUIRED for use with this camera. Use of a non-regulated,
non-conforming power supply can damage this product and voids the
warranty.
IT'S ALL ON THE WEB!
Product Information Specification Sheets
Quick Start Guides
User Manuals
Latest News Video Tutorials & Demos
VISIT
www.digimerge.com
Digimerge Technologies Inc.
Copyright © 2013
As our products are subject to continuous improvement, Digimerge
reserves the right to modify product design, specifications and prices,
without notice and without incurring any obligation. E&OE
ULTRA RESOLUTION
IR NIGHT VISION CAMERA
MODEL: DBB43TL

QUICK START GUIDE

English Version 3.0
