FLIR DNB13TF2 Quick Connection Manual

PACKAGE CONTENTS:

1 x IP Camera 1 x Mounting Template
3 x Drywall Anchors 3 x Mounting Screws
1 x CD Quick Start Guides
(includes software & manual)
Fo r s u p p o rt , v i s it
ww w. di gi merge.co m
w ww.f lir.com/security
Information in this document is subject to change without
notice. As our products are subject to continuous improvement,
Digimerge Technologies Inc., a FLIR company, and our subsidiaries
reserve the right to modify product design, specifications and
prices, without notice and without incurring any obligation.
E&OE © 2013 FLIR / DIGIMERGE. All rights reserved.
Quick Connection Guide
1

Installing the Camera

A
Use the included mounting template to mark
holes for the screws.
B
Drill holes for the mounting screws.
NOTE:
Use the included drywall anchors if
installing into drywall.
C
Connect cables as shown in the section

"Connecting the Camera".

D
Mount the camera to the surface using
the included mounting screws (3x).
Mounting Screws
Drywall Anchors
Mounting Template
Mounting Surface
Weights & Dimensions
6.3" / 160mm
2.6" / 66mm
3.3" / 85mm
Weight
1.1lbs
2.6" / 66mm
0.5kg
2.1MP HD Mini-IR Bullet IP Camera
ENGLISH
2
Adjusting the Camera
1 A
Use a Philips head screwdriver (not included) to
loosen the adjustment screw.
B Adjust the position of the camera as needed:
1. Rotate the camera base 360°.
2. Twist the camera around the stand 360°.
3. Tilt the camera on the stand up to 90°.
2.
1.
Adjustment Screw
C
Tighten the adjustment screw when finished.

Safety Precautions

• If using DC power, use an appropriate low voltage
power cable to prevent fire or electrical shock.
• Make sure to install the camera in an area that can
support the camera weight.
• There are no user serviceable parts inside the camera.
Please do not disassemble the camera.
• Do not clean the lens cover with an abrasive cleaning
material. Please use a soft cloth to clean the lens cover.
• Camera is rated for outdoor use (IP66), but is not
intended for submersion in water.
DNB13TF2
3
Connecting the Camera
Ethernet Port
DC12V Input
Option 1
Connect the camera to a PoE port on your NVR using Cat5e or
better Ethernet cable (not included).
3.
Option 2
Connect the camera to a PoE switch* on your network.
* 8-port PoE switch accessory sold separately (model: ACCDPS281).
Option 3
A. Connect the camera's Ethernet port to a router (not included)
or switch (not included) on your LAN.
B. Connect the camera's DC12V input to a local power outlet
using a 12V DC power adapter (not included; 350mA or higher).
FCC Notice
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference when the equipment is operated in a
commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. Operation of this equipment in a
residential area is likely to cause harmful interference
in which case the user will be required to correct the
interference at his own expense.
DNB13TF2_QCG_TRILINGUAL_R1
