2.2. Operating principle

The indicators in this chapter refer to the illustrations in Ch. 2.1.
The opening of the arm (18) is controlled by the user (through a lockable switch, a push-button, a radio
transmitter), presence detector loops buried under the road, or through an outside unit.
Closing is controlled in the same way, or automatically after a time delay.
The motion generated by the gear motor (9) is transmitted to the arm by means of pinion and sector gears
(15 + 11).
The speed of the arm movement, controlled by the variable speed controller (17), can be adjusted for both
opening and closing. The movement parameters are adjusted in the factory in order to offer brisk acceleration
and gentle deceleration at the end of the movement.
The 2 inductive position sensors (7) indicate the extreme arm positions (open and closed) to the control
board (16). The latter coordinates the barrier's activity: Management of movements, options, processing of
incoming and outgoing information, etc (see Ch. 3. ). This information can, however, be transferred and
processed by an external terminal (not supplied by Automatic Systems).
There are one to six preloaded balancing springs (12) to help the motor open and close the barrier.
For barrier models with the automatic lifting option during power cuts, the preloading of springs is
increased in order for the latter to ensure the lifting of the arm in the event of power outages.
In normal operation condition a mechanical locking system holds the arm in its closed positions. Also, the
variable speed controller compensate for any effort made to move the barrier manually when the arm is in the
open, closed or stopped position.
In order to increase protection against vandalism (forcing the arm), the mechanical locking system can be
modified to act in power outage situation and also to lock the open position (see Ch 2.3. ).
The following table summarises the various possible combinations:
Locking situation
Locking in power outage and
operation.
(For barrier without automatic lifting
of the arm)
Locking in operation only
(For barrier with automatic lifting of
the arm)
NC: Normally Closed
NO: Normally Open
Note: The open and close position lock can only work in matching locking situation.
