Technical Specifications - Automatic Systems BL40 Technical Manual

7. TECHNICAL SPECIFICATIONS

Electrical power supply:
Nominal Power consumed:
Ambient operating temperature:
Average relative humidity:
Maximum wind speed (without disrupting the operation):
Protection index:
Net weight (without arm):
The information in this document is the property of Automatic Systems and is confidential. The consignee withholds from using it for anything other than the use of the products or the execution of the
project to which they belong and withholds from communicating it to third parties without prior written agreement from Automatic Systems. Document subject to change without prior notice.
Technical Manual NAM-BL4x-MT-EN-C
120V~ (± 10%)/60Hz
450 W
20°C to +50°C [-4°F to 122°F]
-
(-25°C [-13°F] with optional 250W heater
(-45°C [-49°F] with optional 500W heater)
95% without condensation
120km/h [74.6 mi/h]
IP44
220 kg (BL40)
230 kg (BL41)
250 kg (BL43)
250 kg (BL46)
p 51/58
