Soft. Version
Log
The information in this document is the property of Automatic Systems and is confidential. The consignee withholds from using it for anything other than the use of the products or the execution of the
project to which they belong and withholds from communicating it to third parties without prior written agreement from Automatic Systems. Document subject to change without prior notice.
2 s
2 s
2 s
2 s
Note: If no error message is displayed when the machine
fails, refer to the Troubleshooting chapter.
Power was turned on.
Power Up
Power was turned off.
Power Down
Short circuit of the control board outputs (connector
Short Circuit
blocks). The short circuit is declared and the equipment
put Out of Service only after 3 unsuccessful reactivation
tries within the 2.5 seconds following a voltage drop in the
24V power supply (this is to avoid putting it out of service
at inopportune moments, as for example during a network
changeover to an emergency generator).
If one of the outputs short circuits, all of them become
inactive and the control board must be powered up again
for the outputs to be reactivated.
Time out during opening: the time allocated for opening
Open Time Out
was exceeded (TIMING menu, OpenTimeOut parameter).
Time out during closing: the time allocated for closing was
Close Time Out
exceeded (TIMING menu, CloseTimeOut parameter).
Allotted number of trials to close have been executed (as
Close Retries
defined in the TIMING menu).
Technical Manual NAM-BL4x-MT-EN-C
Display the software version used by the control unit,
following format type – evolution – version – revision –
minor index of the application.
The descriptions included in this chapter correspond to
versions 00-00-06-rr-00.
Display of the last 100 events (use ► the ▲ and keys to
view preceding events).
For the first two seconds, the event number (00 for the
last event recorded (= most recent), 01 for the preceding
event, and so on), as well as the date (year-month-day)
and time (hours-minutes-seconds) of creation are
displayed.
In the next two seconds, the event description is
displayed.
For example:
Log
00 060324 235034
Log
Out Of Service
Log
01 060324 235034
Log
Open Time Out
p 13/58
On 24 March 2006 at 23
hours (11 p.m.) 50 minutes
and 34 seconds...
...the apparatus was put out
of service.
View the preceding message
(01) using the ►▲ keys...
...we observe that it was put
out of service due to a time
out while opening.
