Summary of Contents for Furious FPV PIKO F4
- Page 1 PIKO F4 Flight Controller USER MANUAL VERSION 1.0 Please contact us if you need further assistance: Tech support: tech@furiousfpv.com Sales support: sales@furiousfpv.com Website: http://furiousfpv.com/...
-
Page 2: Table Of Contents
Contents Introduction ....................... 2 Features ......................2 Connections ....................... 4 Connect with Receiver ..................4 Using SPD15 Receiver ................4 Using LR1000D Receiver ................ 5 Using XSR FrSky Receiver ............... 6 Using Spektrum Satellite Receiver ............6 Connect with Innova V4 VTX/OSD Board ............ -
Page 3: Introduction
Introduction Revolutionizing the FPV scene, Furious FPV pushes it to the max with the all new PikoF4 Flight Controller, featuring a no compromise design that is ready to immerse itself into your favorite FPV machine. Designed as a stackable unit with the feature packed INNOVA V4, the PikoF4 pushes the envelope of performance with F4 processing power that provides "on the rails"... - Page 4 Board Layout Dimensions...
-
Page 5: Connections
Connections *WARNING: Piko F4 can support up to 6s Lipo battery but make sure other devices also support Connect with Receiver: Using SPD15 Receiver: * NOTE: If you are using S.Port with firmware 3.1.7, please enter CLI mode and type the following commands:... -
Page 6: Using Lr1000D Receiver
Using LR1000D Receiver: You can buy LR1000D Receiver right here: https://goo.gl/4Cr0Hl * NOTE: If you use LR1000D Receiver please go to CLI and type the following commands: set sbus_inversion = OFF save... -
Page 7: Using Xsr Frsky Receiver
Using XSR FrSky Receiver: * NOTE: If you are using S.Port with firmware 3.1.7, please enter CLI mode and type the following commands: set sport_halfduplex = OFF save Using Spektrum Satellite Receiver:... -
Page 8: Connect With Innova V4 Vtx/Osd Board
Connect with Innova V4 VTX/OSD Board: You can buy Innova V4 right here: https://goo.gl/bNYRzT... -
Page 9: Connect With Other Devices
Connect with other devices: You can buy LED STRIP right here: https://goo.gl/TXwSwI Connect with ESC 4 in 1:... -
Page 10: Basic Setup
Please, follow carefully these next steps, and always remove your propellers when you’re configuring your quad STEP 1: Connect Piko F4 with the computer via USB cable and then Open BetaFlight STEP 2: Configure Ports. (1) Turn ON MSP of UART 1 to use OSD. -
Page 11: Tips
If you are using SBus, iBus or a Spektrum Satellite, you will need to pick your Serial Receiver Provider. Follow this table: RX Type Serial Receiver Provider DSM2 1024bit/22ms SPEKTRUM1024 DSM2 2048bit/11ms SPEKTRUM2048 DSMX 1024bit/22ms SPEKTRUM1024 DSMX 2048bit/11ms SPEKTRUM2048 FrSky RX SBUS Futaba RX SBUS... - Page 12 Then go to the Configuration tab. Under the section labeled “Receiver”, pick Serial Receiver Provider compare with your RX Type. RX Type Serial Receiver Provider DSM2 1024bit/22ms SPEKTRUM1024 DSM2 2048bit/11ms SPEKTRUM2048 DSMX 1024bit/22ms SPEKTRUM1024 DSMX 2048bit/11ms SPEKTRUM2048 Click “Save”. Finally, go to the Receiver tab. Pull down the drop down that says “Channel Map” and select the “JR / Spektrum / Graupner”...
-
Page 13: Guideline Configuration Innova V4 Vtx/Osd With True Vision Configurator V1.0
STEP 3: Please select Port COM (1) correlative with your device, then select UART 1 (2) using for OSD. STEP 4: Plug Battery for Piko F4, then click Connect icon on True Vision interface to connect and configuration OSD layout and setting. -
Page 14: How To Open Innova V4 Vtx/Osd Menu By Transmitter
How to open Innova V4 VTX/OSD menu by Transmitter To access the in-built OSD menu in MW-OSD, disarm your quadcopter first. THROTTLE MIDDLE YAW RIGHT PITCH FULL To navigate through menu in the OSD: PITCH/ROLL sticks are used to navigate ... - Page 15 Thanks for using our product...
