FORTINI F4
Flight Controller
USER MANUAL VERSION 1.2
Please contact us if you need further assistance:
Tech support:
Sales support:
Website:
http://furiousfpv.com/
tech@furiousfpv.com
sales@furiousfpv.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FORTINI F4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Furious FPV FORTINI F4

Summary of Contents for Furious FPV FORTINI F4

  • Page 1 FORTINI F4 Flight Controller USER MANUAL VERSION 1.2 Please contact us if you need further assistance: Tech support: tech@furiousfpv.com Sales support: sales@furiousfpv.com Website: http://furiousfpv.com/...

  • Page 2: Table Of Contents

    Basic setup ..........................23 Tips ............................25 4 Tips to setting up Fortini F4 FC with Damper ..............25 How to configure your Spektrum RX with your Flight Controller ........25 Guideline configuration OSD with TRUE VISION CONFIGURATOR V1.0 ......27 How to open Piggy OSD menu by Transmitter ..............

  • Page 3: Change Log

     How to set up CMS CANVAS mode on Betaflight  Change information in diagrams v1.2  Add Tips setup Fortini F4 with Damper  Connect with Lightning PDB  Assambly with ESC 4 in 1  Connect with TBS Crossfire micro receiver v2...

  • Page 4: Introduction

    Flight Controller the FPV market has ever seen. Hold on - you don't want to miss this. Enter the all new Fortini F4 - the culmination of years of research and application as we push forward into the outer limits of FPV. With a new high performance, low noise 32kHz Invensense 20602 gyro that features ultra-high sensitivity, this FC is designed for outright performance, offering ultra-crisp flight characteristics that will be felt in every move you make.
  • Page 5  LED Driver for WS2812b programmable LED  Integrated buzzer driver  Built-in BEC 5V-2A supports direct 2-6S Lipo connection  Inrush Voltage Protection Input and Output by Transient Voltage SuppressorBoard Layout  Weight: 5.5gr Dimensions...

  • Page 6: Connections

    Connections *WARNING: Fortini F4 can support up to 6s Lipo battery but make sure other devices also support it. Connect with Receiver:  Using SPD15 Receiver: * NOTE: If you are using S.Port with firmware 3.1.7, please enter CLI mode...

  • Page 7: Using Lr1000D Receiver

     Using LR1000D Receiver: You can buy LR1000D Receiver right here: https://goo.gl/4Cr0Hl * NOTE: If you use LR1000D Receiver please go to CLI and type the following commands: set sbus_inversion = OFF save...

  • Page 8: Using Xsr Frsky Receiver

    If you are using S.Port with firmware 3.1.7, please enter CLI mode and type the following commands: set sport_halfduplex = OFF save *NOTE: If telemetry of XSR is not working with FORTINI F4, please update firmware for XSR receiver Download firmware at here: https://goo.gl/t1LMT5...

  • Page 9: Using Spektrum Satellite Receiver

     Using Spektrum Satellite Receiver: NOTE: When use Spektrum Satellite for Fortini F4, you must use battery for FC's power...

  • Page 10: Using Tbs Crossfire Receiver

     Using TBS Crossfire Receiver:...

  • Page 11: Connect With Video Transmitter

    Connect with Video Transmitter:  Using Tramp HV:  With Piggy V2 OSD *NOTE: Fortini F4 can support up to 6s Lipo battery but make sure other devices also support it.
  • Page 12  With Only Camera *NOTE: Fortini F4 can support up to 6s Lipo battery but make sure other devices also support it.

  • Page 13: Using Tbs Unify Pro

     Using TBS Unify Pro:  With Piggy V2 OSD *NOTE: Fortini F4 can support up to 6s Lipo battery but make sure other devices also support it.
  • Page 14  With Only Camera *NOTE: Fortini F4 can support up to 6s Lipo battery but make sure other devices also support it.

  • Page 15: Using Fx Fx799T

     Using FX FX799T:  With Piggy V2 OSD *NOTE: Fortini F4 can support up to 6s Lipo battery but make sure other devices also support it.
  • Page 16  With Only Camera *NOTE: Fortini F4 can support up to 6s Lipo battery but make sure other devices also support it.

  • Page 17: Connect With Stack Mnova And Runcam

    Connect with stack Mnova and Runcam: * WARNING: Mnova is only compatible with 5V. Please solder only to 5V pad if using Mnova You can buy Mnova right here: https://goo.gl/JyQnds...

  • Page 18: Connect With Lightning Pdb

    Connect with Lightning PDB:...

  • Page 19: Connect With Other Devices

    Connect with other devices: *NOTE: Fortini F4 can support up to 6s Lipo battery but make sure other devices also support it. You can buy LED STRIP right here: https://goo.gl/TXwSwI...

  • Page 20: Connect With Esc 4 In 1

    Connect with ESC 4 in 1  Using Aikon SEFM 30A: *NOTE: Fortini F4 can support up to 6s Lipo battery but make sure other devices also support it. You can buy ESC Aikon SEFM 30 4 in 1 right here: https://goo.gl/IOYBEr...

  • Page 21: Using Cicada 35X4 35A

     Using Cicada 35x4 35A: *NOTE: Fortini F4 can support up to 6s Lipo battery but make sure other devices also support it. You can buy ESC Sunrise Cicada 35x4 35A right here: https://goo.gl/s08OaI...

  • Page 22: Using T-Motor F 35A 4In1-4S

     Using T-Motor F 35A 4IN1-4S: *NOTE: Fortini F4 can support up to 6s Lipo battery but make sure other devices also support it. You can buy ESC F 35A 4in1-4S right here: https://goo.gl/QyM3eh...

  • Page 23: Using Hobbywing Xrotor Micro 40A 4In1

     Using Hobbywing XRotor Micro 40A 4in1: *NOTE: Fortini F4 can support up to 6s Lipo battery but make sure other devices also support it. You can buy Hobbywing XRotor Micro 40A 4in1right here: https://goo.gl/G2E9dU...

  • Page 24: Basic Setup

    Please, follow carefully these next steps, and always remove your propellers when you’re configuring your quad STEP 1: Connect Fortini F4 with computer via USB cable and then open BetaFlight STEP 2: Configure Ports. (1) Turn on MSP of UART 1 to use OSD.
  • Page 25 STEP 3: Go to Configuration tab and choose ESC/Motor protocol in ESC/Motor Features STEP 4: Select Serial- based receiver in Receiver Mode If you are using SBus, iBus or a Spektrum Satellite, you will need to pick your Serial Receiver Provider. Follow below table: RX Type Serial Receiver Provider...

  • Page 26: Tips

    Tips 4 Tips to setting up Fortini F4 FC with Damper How to configure your Spektrum RX with your Flight Controller In Betaflight Configurator:  Go to the Ports tab  Enable “Serial RX” on the UART 3 Click “Save”.
  • Page 27 Then go to the Configuration tab. Under the section labeled “Receiver”, pick Serial Receiver Provider compare with your RX Type. RX Type Serial Receiver Provider DSM2 1024bit/22ms SPEKTRUM1024 DSM2 2048bit/11ms SPEKTRUM2048 DSMX 1024bit/22ms SPEKTRUM1024 DSMX 2048bit/11ms SPEKTRUM2048 Click “Save”. Finally, go to the Receiver tab. Pull down the drop down that says “Channel Map” and select the “JR / Spektrum / Graupner”...

  • Page 28: Guideline Configuration Osd With True Vision Configurator V1.0

    STEP 3: Please select Port COM (1) correlative with your device, then select UART 1 (2) using for OSD. STEP 4: Plug Battery for Fortini F4, then click Connect icon on True Vision interface to connect and configuration OSD layout and setting.

  • Page 29: How To Open Piggy Osd Menu By Transmitter

    How to open Piggy OSD menu by Transmitter To access the in-built OSD menu in MW-OSD, disarm your quadcopter first.  THROTTLE MIDDLE  YAW RIGHT  PITCH FULL To navigate through menu in the OSD:  PITCH/ROLL sticks are used to navigate ...

  • Page 30: How To Set Up Cms Canvas Mode On Betaflight

    How to set up CMS CANVAS mode on BetaFlight CMS activation:  Stick command to activate the BetaFlight CMS is THROTTLE MIDDLE YAW LEFT + PITCH FULL.  (Notice that MWOSD menu activation is THROTTLE MIDDLE YAW RIGHT PITCH FULL). OOS (Out-Of-Sync): MWOSD is very stable, and so is the canvas mode support.
  • Page 31 Thank you for using our product...
