- Page 1 F-35 LIGHTNING FLIGHT CONTROLLER USER MANUAL VERSION 1.1 Please contact us if you need further assistance: Tech support: tech@furiousfpv.com Sales support: sales@furiousfpv.com Website: http://furiousfpv.com/...
-
Page 2: Table Of Contents
Contents Manual user log ......................3 Introduction ........................4 Features .......................... 4 Pinouts ..........................5 Dimensions ........................5 Connections ........................6 Connection With ESCs and Servos: ................. 6 1. Flying Wing: ......................6 2. Airplane: ....................... 6 Connection With Receivers: ................... 9 TBS Receiver ....................... - Page 3 4. Using with TBS Unify 2G4: ................19 Connection With Furious AirSpeed Sensor ..............19 Connection With Furious FPV GPS Module (Plug and Play with GPS Cable) ....20 Connection With RadioLink M8N GPS ................21 Connection With Camera (Plug and Play with CAM Cable) ......... 22 1.
-
Page 4: Manual User Log
Manual user log V1.1: Update connections for Airspeed Please note: In this manual, BLUE Texts have hyperlinks to check out guideline. -
Page 5: Introduction
Introduction Furious FPV F-35 Lightning FC - Elevate Your Horizons. Step into the all new F-35 Lightning FC - Furious FPV's 1st dedicated wing flight controller, ready and waiting to open all new worlds to winged FPV. Encompassed by a robust aluminum case for maximum levels of protection and strength, the F-35 FC offers the ultimate levels of FPV capability that is dedicated &... -
Page 6: Pinouts
Pinouts Dimensions... -
Page 7: Connections
Connections Connection With ESCs and Servos: 1. Flying Wing: Location ESC: 1, 2 Location Servos: 3, 4 Ex: Reptile S800 Sky Shadow Flying Wing 2. Airplane:... - Page 8 Location ESC: 1, 2 Location Servos: 3, 4, 5, 6 Ex1: Volantex Ranger Ex2: Twin Dream Open INAV Configurator Go to CLI tab and paste this strings as the picture above. Then, hit Enter: # mixer mixer CUSTOMAIRPLANE mmix reset mmix 0 1.000 0.000 0.000 0.300 #Left motor mmix 1 1.000 0.000 0.000 -0.300 #Right motor...
- Page 9 Ex 3: V-Tail Open INAV Configurator Go to CLI tab and paste this strings. Then, hit Enter: # mixer mixer CUSTOMAIRPLANE mmix reset mmix 0 1.0 0.0 0.0 0.0 # motor smix reset smix 0 2 0 -100 0 # servo 2 takes Stabilised ROLL smix 1 3 0 -100 0 # servo 3 takes Stabilised ROLL...
-
Page 10: Connection With Receivers
Connection With Receivers: *Warning: Only support power is 5V for receiver I. TBS Receiver 1. TBS Crossfire Micro Rx V2 (Plug and play with Micro Rx Cable) 2. TBS Crossfire Micro Rx V2 (Plug and Play with Micro Rx and TBS-Ext Cable for Wireless Connection) Video: Wireless connection to INAV via TBS Crossfire Tx + TBS Micro Rx V2... -
Page 11: Tbs Crossfire Diversity Rx Only Use Crsf Protocol
3. TBS Crossfire Diversity Rx Only Use CRSF Protocol... -
Page 12: Tbs Crossfire Diversity Rx Use Ppm + Serial Tx-Rx
4. TBS Crossfire Diversity Rx Use PPM + Serial TX-RX To using PPM, you need to open INAV Configurator Go to Configuration *Note: tab and drag to Receiver Mode. Then, select PPM RX input as the picture below... -
Page 13: Frsky Receiver
II. FrSky Receiver XSR (Plug and Play with F-RX Cable) -
Page 14: R9 Slim
3. R9 Slim 4. L9R... -
Page 15: Spd15
5. SPD15 6. XM+... -
Page 16: Futaba Receiver
II. Futaba Receiver III. Spektrum Receiver... -
Page 17: Dragon Link Micro Uhf Receiver
IV. Dragon Link Micro UHF Receiver *Note: Verify that PPM pin on the receiver converted to SBUS by Dragon Link Software... -
Page 18: Connection With Vtx
Connection With VTX: 1. Using with Stealth Long Range VTX (Plug and Play with VTX Cable) -
Page 19: Using With Tramp Hv
2. Using with Tramp HV *Note: If using our VTX Cable, please swap wires the same as pinouts of this VTX 3. Using with TBS Unify Pro 5G8 HV:... -
Page 20: Using With Tbs Unify 2G4
4. Using with TBS Unify 2G4: Connection With Furious AirSpeed Sensor Check out How to assembly silicone tube for Airspeed sensor... -
Page 21: Connection With Furious Fpv Gps Module (Plug And Play With Gps Cable)
Connection With Furious FPV GPS Module (Plug and Play with GPS Cable) *Warning: For the first time set up and whenever you change your location. You need to leave the Wing or Airplane on the field for approximately 5 minutes so that the GPS is updated Open INAV Configurator ... -
Page 22: Connection With Radiolink M8N Gps
Connection With RadioLink M8N GPS Open INAV Configurator Click Configuration tab Drag to GPS and configure as the picture below:... -
Page 23: Connection With Camera (Plug And Play With Cam Cable)
Connection With Camera (Plug and Play with CAM Cable) 1. RunCam Eagle 2 2. RunCam Swift 2... -
Page 24: Runcam Split 2
3. RunCam Split 2 4. Foxeer Arrow Mini... -
Page 25: How To Set Up Wing With Inav Configurator
How To Set Up Wing With INAV Configurator Step1: Calibrate Sensor (Click double to go to How to calibrate Sensor page) INAV requires you to follow the accelerometer calibration steps. These steps are different to Cleanflight & Betaflight. So don't skip reading this section, it's vitally important. -
Page 26: How To Calibrate Sensor
Set Failsafe How To Calibrate Sensor After building new an Airplane, you must calibrate Magnetometer and Accelerometer sensor. With F-35 Lightning FC, we don't need to plug USB cable that can use wireless connection with FuriousFPV Bluetooth Module TBS Crossfire... - Page 27 2. Compass Calibrate: Please click Calibrate Magnetometer then You have 30 seconds to hold the copter in the air and rotate it so that each side (front, back, left, right, top and bottom) points down towards the earth. 3. Board Orientation: If you have your board rotated in any way, change board alignment to match- please check the below pictures:...
-
Page 28: How To Connect Inav Wireless To F-35 Via Tbs Crossfire Tx
How To Connect INAV Wireless To F-35 Via TBS Crossfire TX The Device: TBS Micro RX V2 + TBS Crossfire TX Micro RX cable for F-35 + TBS-External Cable for F-35 (Include in the package) App: INAV Configurator on PC, EZ-Gui on Android. ... - Page 29 Now you can do anything with a wireless connection same when you connect with USB cable. Option2: Connect with EZ-Gui on Android app: 1. Download and install app at here: DOWNLOAD 2. Turn On Bluetooth on your mobile 3.
-
Page 30: How To Connect Smartphone To F-35 Lightning Fc Via Furiousfpv Bluetooth Module
Video: Calibrate sensor with wireless connection Via Bluetooth module Step 1: Plug FuriousFPV module into F-35 Lightning FC. Then, go into Ports tab on the INAV Configurator and configure as the pictures below: Step 2: Connect with EZ-Gui on Android app 1. - Page 31 3. Open EZ Gui: Click icon 3 Vertical dots the Top-Right screen and click Settings to go to page setting and configure for Connections. At here, we will select connection is Bluetooth then click SELECT BT DEVICE to search you TBS Crossfire module and select it when detected your module.
-
Page 32: How To Setup Failsafe
Click next icon and select Firmware is Cleanflight/Betaflight/INAV. Click next and select option same as units or another options. After app will come back home screen. 4. At Home Screen, please click CONNECT to connect your app to FC. How To Setup Failsafe Setting up Return Home for Failsafe to purpose: when Wing lost signal with Transmitter, Wing will auto return home afterward... -
Page 33: How To Use Nav Launch (Auto Take Off) Function
How To Use NAV LAUNCH (Auto Take Off) Function Video: How to use NAV LAUNCH (Auto Take off) with F-35 Lightning FC Step1: Open “INAV Configurator” Select “Mode” tab drag to NAV LAUNCH function, click Add Range and select CH channel for switch that you want to use this... -
Page 34: Inav Mode
Step4: Put throttle stick to desired throttle value to be set after launch is finished. Step5: Throw the airplane. *Note: It must be thrown leveled or thrown by slinging it by wingtip Step6: Launch sequence will finish when pilot switch off the NAV LAUNCH mode or move the sticks INAV MODE Mode Name... -
Page 35: How To Assembly Silicone For Airspeed Sensor
Wireless connection to INAV via TBS Crossfire Tx + TBS Micro Rx V2 Video 2: Calibrate sensor with wireless connection Via Bluetooth module Video 3: How to use NAV LAUNCH (Auto Take off) with F-35 Lightning FC Thanks for using our product...
